Page 1 Welch Allyn Connex ® Central Station Install Guide Platform CPU...
Page 2 Welch Allyn. Welch Allyn assumes no responsibility for any injury to anyone, or for any illegal or improper use of the product, that may result from failure to use this product in accordance with the instructions, cautions, warnings, or statement of intended use published in this manual.
Page 3: Table Of Contents
Equipment Staging and Inspection ................10 Setup ............................. 14 General Setup......................... 14 Setup a Video Display ......................15 Setup a Welch Allyn Printer ....................15 Setup a Customer Supplied Printer ..................15 Warm Spare installation ......................15 Central Station Startup ......................18 Different startup ........................
Page 4 Welch Allyn Connex CS Central Station Install Guide Troubleshooting ........................... 28 CPU Startup ..........................28 Configuration Details ......................... 30 General Configuration - Warm Spare ................. 30 Overview .......................... 31 Add a Station .......................... 31 Add a Master bed list ......................34 Create a New Unit ......................
Page 5 Configure AGS priority filter ....................89 After all changes are complete .................... 90 Network, Printer, Date & Time config..................92 Connex CS Shell versus Windows Shell ................92 Network Changes........................94 Add a Customer Supplied Printer ..................94 Install from an executable file (.exe) ................94 Install from a setup info file (.inf) ..................
Page 6 Welch Allyn Connex CS Central Station Install Guide Configure for use with Active Directory ................122 Order the security providers ....................126 Delete a security provider ....................126...
Page 7: Quick Reference Guide
Quick Reference Guide The quick reference guide provides a high level sequence overview to the process of installing a Connex CS system and milestone checklist to measure progress. Complete details can be referenced within this document as needed. Overall Sequence 1.
Page 8: Milestone Checklist
Note: Complete this task on the Connex server if present (backs up all systems to 1 file). Complete all tests as applicable to verify the Central Station or Warm Spare station installation. Refer to the Connex CS Install Verification Guide for instructions.
Page 9: Introduction
Introduction About this manual This Connex CS Central Station Install Guide provides information needed to plan and perform the installation of the central station CPU and it’s peripheral components. This information describes how to:  Plan and stage the equipment ...
Page 10: Related Documents
20012794 Connex CS Server Install Guide 20012800 Connex CS Install Verification Guide 80017306 Connex CS Customer Project Req. Form 80018045 Connex CS Pre-Install Checklist Symbols used in this manual WARNING Warning statements identify conditions or practices that could result in personal injury.
Page 11: Definitions
Also performs POST functions and error reporting. Client-Server A topology in Connex CS with a central station PC (client) and a Connex server (hardware or virtual server). In the client-server model, data is replicated between the client and the server via the Welch Allyn Connex Data Synchronization Service.
Page 12 Introduction Virtual Connex Server A server instance which has been virtualized to an appliance form (includes Operating System, Connex Applications, and Database) and installed within the customer’s Virtual Server environment.
Page 14: Overview And Planning
The Connex CS system consists of a central station that receives and displays information from connected devices. In this configuration, continuous and episodic devices communicate over the network to the central station.
Page 15: Planning For The Install
Connex CS Customer Project Req Form detailing the planned implementation. Install system components as described within the Connex CS Customer Project Req Form. Site Preparation and Inspection First locate the equipment and the accompanying documentation package.
Page 16: Equipment Staging And Inspection
3. As you unbox each component, visually inspect for damage which may have been sustained during shipment. 4. Contact the field Project Coordinator, via Welch Allyn technical support as necessary, to report damaged or missing components. 5. Move the following components to the central station location: ...
Page 17 Figure 2-2: CPU Front Panel controls and connectors Power LED Power Switch. Press and release to turn on the CPU. Push and hold to turn off. Hard disk LED. Turns on when the computer read or writes data to the hard disk. Front Panel USB ports (Qty.
Page 18 Overview and Planning Figure 2-3: CPU Rear Panel connectors AC Power inlet (100 - 240 Network RJ45 VAC) USB 2.0 ports (Qty. 3) Audio out (Green) On-board VGA video HD15 DisplayPort Video connector (for repeater display) USB 2.0 ports (Qty. 2)
Page 20: Setup
Setup Setup General Setup 1. Place the CPU, keyboard, mouse, and video display in their intended locations. 2. Remove the plastic covers from the CPU panels if not already done. CAUTION Do not operate the CPU with the protective covers attached. Reduced airflow from partially blocked vents may result in the CPU overheating and internal damage.
Page 21: Setup A Video Display
4. Power on the laser printer. 5. Refer to the network information table from the Connex CS Customer Project Req Form, Appendix B1, to confirm network settings for laser printer if known.
Page 22 Setup Install the Warm Spare in the same manner as a Central Station. It requires power, a network connection with link to the Connex server, keyboard, mouse, and a display (for administration). Consult with the facility Biomedical Engineering team as needed to determine the location for placing the Warm Spare station.
Page 24: Central Station Startup
A Warm Spare is part of a network environment, with a sever as well. It is preferred that the Connex server be started first. Central stations, including a warm spare should be started after the Connex server is running. Refer to the Connex CS Server Install Guide for additional information and startup behavior for the Connex server.
Page 25: Power On The System
Power on the system Once all peripheral items have been attached to the central station CPU, complete these final steps to finish the install. 1. Ensure that all components are connected to a AC power outlet. 2. Power on the displays and any other peripherals which require power. 3.
Page 26: Standard Central Station Startup
Central Station Startup Standard central station startup 1. Upon successful start-up of the Connex CS application, the main screen is displayed. An example is shown in “Figure 4-2: Connex CS main screen example”. 2. Some additional configuration may be required on site. Refer to “Configuration Details” for additional information on that subject.
Page 27: Warm Spare Station Startup
Warm Spare station startup If the station is configured as a Warm Spare: 1. Upon successful start-up of the Connex CS application, the Warm Spare screen is displayed. Figure 4-1: Warm Spare main screen example. An example is shown in 2.
Page 28: Connex Cs Configuration
Some additional steps may be required to configure the Central Station or network to meet some customer needs. 1. Refer to “Configuration Details” for more specific instructions on tasks related to the following list of Connex CS configuration topics.  General Configuration - Warm Spare ...
Page 30: Final Steps
Final Steps Before placing the system into use by clinicians, the system installation must be verified. Confirm proper configuration and operation by completing steps detailed in the Connex CS Install Verification Guide. See “Related Documents” for additional information. Backup users and configuration The Administration tool tab has functionality to backup and restore configuration information for the system and users.
Page 31 Figure 6-1: Export data settings users and configuration window 6. Select Export data. 7. Navigate to the USB flash drive. Choose a folder location for the backup. 8. Chose a file name for the saved file. By default, the file will be called WAConfigurationSettings.xml, but should be changed to the following format for consistency: ...
Page 32 Final Steps 9. Also save a local copy on the system at the following location:  C:\ProgramData\Welchallyn\@Config.Backup. Note ProgramData is typically a hidden file. You may need to type location by hand into the folder location bar using the keyboard. The folder @Config.Backup may not exist if this is a new installation.
Page 34: Troubleshooting
CPU or vented covers. Press the POWER ON control in the front bezel to restart the CPU. Connex CS Central Station Ensure that the power is turned on for the display. screen are blank or frozen.
Page 36: Configuration Details
Configuration Details Configuration Details The configuration details section includes information for configuring Connex CS Central Stations, and is not intended to be followed in exact sequence. Instead refer the specific task area or section to accomplish configuration changes as needed. Chapter titles and main topic titles are listed within the Table of Contents at the beginning of this document.
Page 37: Overview
Overview During the configuration of the system, the following sequence or steps will be performed:  “Add a Station”  “Add a Master bed list”  “Add a covered area”  “Configure Network Rendezvous Services”  “Configure the License pool” ...
Page 38 7. To add a new station, click in the Add station field and type a name for the station. Refer to the Connex CS Customer Project Req Form, Appendix B1 and B2 as needed to determine the proper entry for the station.
Page 39 Figure B-4: Newly added station example 9. Click Save when finished. 10. Click on the Back button in the window header.
Page 40: Add A Master Bed List
Central Station and associated patient monitors. In a networked environment with more than one Central Station, the Master bed list controls this information for all systems. Always Connex CS Customer Project Req Form, Appendix B2 when entering information in these fields.
Page 41: Create A New Unit
Create a New Unit 1. In the Units window, click in the Facility field and enter the facility name. 2. Continue for the Building, Floor, and Unit fields. An example is shown below in “Figure B-6: Facility, Building, Floor and Unit entry field examples”. 3.
Page 42: Add A New Room And Bed
Configuration Details Add a New Room and Bed In the Units window, click on the newly created Unit name, 3SMS in the above example. The Unit name appears in the header for the lower Rooms and Beds windows. There are a number of different methods that can be used to add a room and bed including: ...
Page 43 Figure B-9: Newly added Room and Bed examples...
Page 44 Configuration Details To add a range of rooms and beds: 1. In the Master bed list window, click Edit to make changes. 2. Click on the expander to the left of Advanced options. Two additional windows appear. An example is shown in “Figure B-10: Advanced options default”. Figure B-10: Advanced options default 3.
Page 45 To change room or bed values: Note When making changes to rooms and beds ensure that the bed is not currently in use or assigned to a patient. 1. In the Master bed list window, click Edit to make changes. 2.
Page 46 Configuration Details To copy from a CSV file to add rooms and beds This feature is available beginning in Connex CS v1.2 and higher. 1. In the Master bed list window, click Edit to make changes. 2. Click on the expander to the left of Advanced options.
Page 47: When Complete
When complete... 1. Confirm that all information listed in the Master bed list is complete, and matches the information contained in the Connex CS Customer Project Req Form, Appendix B2. 2. Click Save when finished. 3. Click on the Back button in the window header. The Location management menu appears.
Page 48: Add A Covered Area
Configuration Details Add a covered area The Covered area window contains configuration tools that bind all of the previously entered location information together with a station. The process described in this section includes:  Add a new covered area  Assign default location ...
Page 49 4. Create a new covered area if there are none present. CAUTION The covered area name will appear in the upper left corner of the Connex CS display screen. Always refer to the Connex CS Customer Project Req Form, Appendix B2 when entering information in these fields.
Page 50 Note Refer to the Connex CS Customer Project Req Form, Appendix B2 as needed for additional information about specific units, bed and rooms per covered area. Figure B-17: Assign beds to covered area window example 13.
Page 51 16. Click on the Back button in the window header. The Location management menu appears. CAUTION Anytime changes are made to the Central Station Covered area, the system must be rebooted for changes to take complete effect.
Page 52: Configure Network Rendezvous Services
Configuration Details Configure Network Rendezvous Services 1. From the Settings > Admin tools > Stations menu, click on Networked Rendezvous Services. The Network Rendezvous Services (NRS) window appears. An example is show below in “Figure B-19: Network Rendezvous Services window example”. 2.
Page 53 Figure B-19: Network Rendezvous Services window example 4. In the Services to be resolved by DCP Network Rendezvous window, click on the entry with the Connex server’s old IP Address info and then select Delete. a. Create an entry for episodic data with the following attributes: Ordinal 8 - Patient spot upload connection request - WACP over TCP Host (If stand-...
Page 54: Change Server Ports
Rendezvous listener should never be changed. Note Refer to the Connex CS Customer Project Req Form for port number information as needed. In general, these port numbers will never need to change. These port numbers should only be changed if: ...
Page 55: When Nrs All Settings Are Complete
NRS settings information. Configure the License pool Licenses for Connex CS are distributed from Welch Allyn as a pool model for an entire network and assigned as needed during configuration. 1. From the Settings > Admin tools, click on Pool Configuration nested under Licensing. The Pool Configuration window appears.
Page 56: Automatically Assign Per Covered Area Licenses
1. Identify the column associated with the Covered Area name for the central station. 2. Double click in a field for the Unit, and enter a quantity of licenses to be allocated for each feature. Refer to the Connex CS Customer Project Req Form, Appendix B2 as needed for additional information.
Page 57 Figure B-21: Per Covered Area Licenses assignment example 4. Licenses are automatically removed from the UNASSIGNED column. 5. Repeat steps 1 through 4 for each Covered Area on the network.
Page 58: Assign Per Care Unit Licenses
1. Identify the column associated with the Unit name for the central station. 2. Click in the box for the Unit, to enable a license for each feature. Refer to the Connex CS Customer Project Req Form, Appendix B2 as needed.
Page 59: Assign A Warm Spare
Assign a Warm Spare Once a complete profile has been created for a station, a warm spare can be assigned to fill the role of hosting station. This is a key step where all configuration information will be bound to a host CPU.
Page 60 Configuration Details 5. A pop-up window appears asking to confirm the assignment. An example is shown in “Figure B-23: Confirm warm spare assignment example” below. Figure B-23: Confirm warm spare assignment example 6. Click Yes to continue. Click No to cancel. 7.
Page 61: Create A View
More information about view configuration can be found in the Directions of Use. 1. Upon completion, the Connex CS application should start automatically and come up with default view. 2. If the station was newly assigned to the CPU (from a warm spare) there will be no view present.
Page 62 Configuration Details Figure B-26: Views window with no views created yet example 7. Click Add to create a new view. The window changes to display the View Configuration fields. An example is shown below in “Figure B-27: View creation starting window example”.
Page 63 Figure B-27: View creation starting window example 8. Enter a descriptive name for the view or tile layout in the top field. 9. Use the drop down menu to select the number of patient tiles the layout will display. Patient tiles can be displayed in 8-, 12-, 24-, 36-, or 48-tile grids. 10.
Page 64 Configuration Details Figure B-28: View configuration example 13. Once a view has been saved, it will appear in the View Configuration window. An example with multiple views is shown below in “Figure B-29: View configuration with multiple views created example”. a.
Page 65 Figure B-29: View configuration with multiple views created example...
Page 66: View Customizations For Mapped By Patient Location
Configuration Details View Customizations for Mapped by patient location As previously described, some additional steps are required when creating a view which is to be organized for Mapped by patient location. 1. Customization windows appear when this view organization is chosen. An example is shown below in “Figure B-30: Mapped by patient location view configuration example”.
Page 67 d. The next room and bed are automatically selected in the bed list and ready to be placed. An example is shown in “Figure B-31: Mapping a bed to a tile layout example” below. e. Click on another tile to place the next bed from the list. Figure B-31: Mapping a bed to a tile layout example Repeat until all desired beds are placed into a tile location.
Page 68: Managing Device Assignments
Configuration Details Managing Device Assignments Connex central stations keep track of which devices are assigned to which station. In the stand-alone environment, this fairly simple as there is only one central station for devices to connect to. In a multi-system environment, devices are typically configured to connect with an assigned central station.
Page 69 Figure B-32: Devices tab example with one device. 8. Click Edit near the bottom of the window. 9. Click on the Serial Number of the recently connected device. The Device Configuration window populates with information from the selected device. a. Devices which are currently in use appear with a wave symbol on the left side.
Page 70: Changing Device Assignments
Configuration Details Figure B-33: Device Location assignment drop down menu example 11. If the device will always be located to a specific room, use the location drop down menu to select a Unit, Room and Bed location. Check the Assigned box to designate the monitor as permanently assigned to the select bed.
Page 71 Figure B-35: Location drop down menu with multiple units example 5. In the example above, the device is currently assigned to the WIRED unit. Note Typically assignments for devices are made on an Unit basis. This allows clinical user flexibility to move the device from any room/bed location throughout the covered area.
Page 72 Configuration Details Figure B-36: Device Location for a Bolted room and bed example 7. Repeat steps 1 through 6 to change locations for additional continuous mode devices. 8. Select Save when finished to store all updated device assignments. 9. Click Back to return to the Station Setting tab main menu.
Page 73: Localize Stations For The Clinical Environment
4. Select the Back button to return to the previous menu. 5. By default, all Vital Signs modifiers are enabled and available at Connex CS. If changes for Vital Signs modifiers are requested, such as disabling modifiers, select each desired parameter and navigate to the appropriate screen menus, make changes and save as desired.
Page 74: To Change Patient Management Settings
Configuration Details Figure B-37: Vital Signs General Parameters configuration window example To change Patient Management settings 1. From the Settings > Admin tools > Settings menu, click on Stations. The Station Settings window appears. 2. Select Patient management. 3. Select the General setting to control how hone a discharged patient is retained in the patient list.
Page 75 6. Additionally, on-screen helper text can be modified for a tag value by double-clicking on the text field and typing in a new string. Figure B-38: General Patient management configuration window example 7. Use the Back button, and select Patient tags to control settings for Fall Risk, Bio Hazard, and Diet symbols.
Page 76: To Change Display And Sound Settings
Configuration Details 11. Select Save when finished, and Back to return to the Station Settings menu. To change Display and Sound settings 1. From the Settings > Admin tools > Settings menu, click on Stations. The Station Settings window appears. 2.
Page 77: To Configure Alarm Audio
(on / off) without having to login with their user credentials. See “Figure B-42: Settings > Patient rest mode control screen composite example” for a sample of controls available. The “Advanced settings” button takes users to the login control window to manage Connex CS settings on the central station.
Page 78 Configuration Details Figure B-42: Settings > Patient rest mode control screen composite example From the Settings > Stations Settings tab, click on Patient rest mode. The Patient rest mode configuration window appears. 1. Select the Edit to make changes. 2. The Patient rest mode allowed checkbox enables this feature. 3.
Page 79 Figure B-44: Central station patient tiles in normal state (left) and rest state (right) Additionally, all enabled devices that connect to the central station inherit the current rest state. Refer to the Welch Allyn Connex CS Directions for Use section titled “Patient rest mode” for additional information about this feature.
Page 80 Configuration Details and an alarm condition occurs.
Page 81: Configure Continuous Vital Signs Outbound
Note Only change the port number if directed by Welch Allyn Applications Engineering. This port is used for internal communication only between the central station and the Connex server Corepoint integration engine. This is not the port used for external communication with the facility’s HIS application.
Page 82: Configure Units Of Measure
Configuration Details Configure units of measure Changes to the Connex CS units of measure may be required as driven by customer preferences. CAUTION Making changes to Units of measure on a live system or network will require a reboot of the Central Station / ALL Central Stations and all attached devices to ensure that all affected systems and devices are operating with the new settings.
Page 83 Figure B-47: Units of measure window 6. Use the drop down to select available units of measure for specific parameters. 7. Make changes as needed, and click on Save when complete. Note The Central Station controls the units of measure for connected devices, upon startup and connection to the Central Station.
Page 84: Configure Auto Discharge Settings
Configuration Details Configure auto discharge settings The Welch Allyn ADT Task Scheduler Service provides a configurable service that runs automatically in the background to assist in managing the Patient List contents and remove old entries. Note The automatic discharge feature is only applied to patients that are not currently being monitored on the Central Station.
Page 85 5. There are 3 different areas within auto discharge functions that can be managed, and are described in the tables below. 6. Refer to the Welch Allyn Connex CS Directions for Use, section titled “Automatic discharge” for general clinical information about this feature.
Page 86 Configuration Details Auto discharge settings for confirmed patients 1. Settings starting with “AUTODISCHARGE” control automatic discharge behavior for confirmed patients. Figure B-50: Confirmed patients auto discharge related settings 2. The following table describes the function of each setting. Table B-5: AUTODISCHARGE setting functions and default values Setting Label Function Default value...
Page 87 CAUTION Do not change settings for EXECUTION SEQUENCE unless directed by Welch Allyn Engineering. Late ADT settings 1. Settings starting with “LATEADT” control behavior for patients which have been under Continuous Monitoring or Spot Vitals taken, but the ADT message arrived late or after the fact.
Page 88: Configure A Custom Facility Logo
Welch Allyn Engineering. Configure a custom facility logo It may be desired to place the facility logo on some printouts from Connex CS. Custom logos are available for use on printouts from the Patient Review and Station Review functions.
Page 90: Configure Alarm Gateway Service
This section is only applicable to systems which are configured and licensed for the Alarm Gateway Service (AGS) interface, available in Connex CS v1.5 and higher. For a stand-alone central station, all of the configuration takes place on the local system. In the client / server environment, configuration of the AGS takes place on both the local central station (client) and the Connex server.
Page 91: Input / Output Configuration For Ags, Client / Server Topology
Figure C-1: Client side alarm gateway input / output configuration window example 3. Output configuration settings will vary depending on the central station topology, (stand alone central station versus client/server). Identify which type of central station is being configured and follow the respective sections below. Input / output configuration for AGS, client / server topology The AGS configuration example shown above in “Figure C-1: Client side alarm gateway input /...
Page 92: Input / Output Configuration, Stand-Alone Topology
Configure Alarm Gateway Service Configure client side AGS Input / Output connections 1. Refer to the Input configuration area first. Confirm that the configuration settings are as follows. Input Type (CHECKED) CCS Inputs IP Address 127.0.0.1 Port 51500 DO NOT USE AGS Inputs (Covered areas (UNCHECKED) grayed out)
Page 93 Figure C-2: Stand alone central station alarm gateway input / output configuration window example...
Page 94 2. Review Output configuration settings next. Confirm that the configuration settings are as follows. Output Type IHE ACM IP Address <customer defined> Refer to Appendix B1 of Connex CS Customer Project Req. Form Port <customer defined> Refer to Appendix B1 of Connex CS Customer Project Req. Form...
Page 95: Configure Ags Priority Filter
Figure C-3: Alarm gateway priority filter window example 2. Confirm settings for All covered areas match those desired by the facility. Refer to the Connex CS Customer Project Req. Form as needed. 3. For All covered areas, use the drop-down arrow to view available settings and change...
Page 96: After All Changes Are Complete
By default, each covered area will inherit the global setting applied to all covered areas. b. In some situations, an individual covered area may require different settings from the default value. Refer to the Connex CS Customer Project Req. Form as needed for additional input data.
Page 98: Network, Printer, Date & Time Config
The Connex Central Station is intended and designed to support automatic startup of the Connex CS application when the CPU starts. To support this, the system is configured to operate in the Connex CS Shell mode. This shell mode blocks general users access to Windows functions, such as the Windows key, Ctrl+Alt+Delete, and Alt+Tab.
Page 99 Figure D-1: Shell Mode configuration screen example...
Page 100: Network Changes
Network, Printer, Date & Time config. Network Changes The change in the IP Address of one or more systems involved in Connex CS network will cause many components to break. This requires updating the specific configurations in the system used by such components.
Page 101: Change Date And Time
If the desired printer is found using search: 1. Select Stop when the printer appears in the search window. 2. Click on the printer, and then select Next. 3. Change the name of the printer as desired and select Next. 4.
Page 102 Network, Printer, Date & Time config. 6. Use the Time zone: drop-down menu to choose an available setting. 7. Check the box for “Automatically adjust for Daylight Saving Time” to enable for the local as needed. This is on by default. 8.
Page 104: Repeater Display Install
Repeater Display Install Repeater Display Install A repeater display option, available with Connex CS v1.5 and higher, provides a method for data displayed at the Central Station to be replicated at another location. Repeater displays provide a view only, with no local control over the data or content being shown.
Page 105: Before You Begin
Before you begin... The steps included here require that the central station is completely installed, configured, and ready to use. CAUTION Always complete installation of the central station and confirm basic functional operation before attaching any repeater display components. If possible, it is recommended to temporarily set up the Repeater Display near the Central Station so that configuration can be observed on both screens simultaneously.
Page 106: Type 1 - Single Repeater Via Standard Copper Hdmi Cable
100 Repeater Display Install Type 1 - single repeater via standard copper HDMI cable The cooper HDMI cable, as pictured below, can carry video and audio signals over a short distance to enable a direct one-connector hookup between the central station and the repeater display.
Page 107: Type 2 - Single Repeater Via Hdmi Cable With Signal Boosters
Type 2 - single repeater via HDMI cable with signal boosters Another solution for a single repeater display includes the use of an HDMI cable with a signal booster. The usual specification length of the maximum run for HDMI cable is about 50 feet due to the fact that when HDMI cable length gets too long the signal starts to lose strength which results in a picture distortion.
Page 108: Type 3 - Single Repeater Via Fiber Optic Hdmi Cable
102 Repeater Display Install 6. Proceed to “Central Station configuration for repeater display” to complete the installation process. Type 3 - single repeater via fiber optic HDMI cable As an alternative for long HDMI cable, a fiber-optic HDMI cable can also be used for a single repeater display.
Page 109: Type 4 - Multiple Repeater Display With Hdmi Video Splitter
4. The RX connector has hard-wired or detachable USB cable. 5. If repeater display / TV has a USB port, connect the USB plug to an available USB port on the display. This provides power to the fiber optic HDMI connector without the need for an external power supply.
Page 110 104 Repeater Display Install Figure E-5: 4 port HDMI video splitter example. Plug & Play Instructions 1. Ensure that all displays and the central station are turned on. 2. Make sure that all the required HDMI cables (one HDMI cable for each display plus a short HDMI cable) are available.
Page 111: Central Station Configuration For Repeater Display
Central Station configuration for repeater display Configuration at the Central Station is required to complete the installation process for a repeater display. If possible, it is recommended to set up the Repeater Display near the Central Station so that configuration can be observed on both screens simultaneously. As these configuration changes are part of the Windows 7 operating system, changes must be made in Windows Shell Explorer.
Page 112 106 Repeater Display Install Figure E-6: Shell Mode configuration screen example...
Page 113: Screen Resolution Setup
Screen Resolution Setup The additional display or television should be added as duplicated display by default. To ensure the same, open the “Intel HD Graphics Control Panel” then select “Display”. Figure E-7: Intel HD Graphics control panel example Set the resolution to 1680x1050. Then drop down the “Display” sub menu and select “Multiple Displays”.
Page 114: Monitor/Television. Select "Clone" For The Display Mode
108 Repeater Display Install Set the Primary (Top) Display to be the name of the main Central Station Monitor. Set the repeater display (bottom) to be the name of the repeater monitor/television. Select “Clone” for the display mode. Figure E-9: Screen settings example Select “Apply”...
Page 115: Audio Setup
Audio Setup Below are the steps to adjust the sound setting with a repeater display. Navigate to the Sound control panel. Under the “Playback” tab, right click “Speakers” and set them to the default device. Figure E-10: Sound control panel Playback example Under the “Recording”...
Page 116 110 Repeater Display Install Right click on “Stereo Mix” again and select properties. Under the Listen Tab, Select “Listen to this device” then select the repeater display in the “Playback through this device” dropdown. Figure E-12: Sound control panel Stereo Mix example Under the “Levels”...
Page 117 Select Power Usage “On Battery” and “Plugged in” e. Enable Automatic Adjustment Select Application “ConnexCS”. Note: if ConnexCS is not in the list of Applications, use the “Browse” function and select it from C:\Program Files (x86)\Welch Allyn\Connex\CS\1.7\ConnexCS g. Save Figure E-14: Finalizing profile example...
Page 118 112 Repeater Display Install On the Windows desktop task bar, click on the Sound icon. Two sound slider controls appear. One is for the Central Station and another is for the display. Try changing these, the sound should be produced at the Central Station and/or from the repeater display. Figure E-15 Setting Windows volume levels Note It is recommended to make sure that volume is set to highest for both the Central...
Page 119: Restore The Cs Shell
4. Click on Shell. The shell mode window appears. Select Edit to make changes. An example is shown below in “Figure E-18: Shell Mode configuration screen example”. 5. Select the corresponding radio button for Connex CS <version number>. 6. Additionally, select the check box to Disable Windows And Ctrl+Alt+Delete Keys option.
Page 120 114 Repeater Display Install Figure E-18: Shell Mode configuration screen example...
Page 122: Configure Clinician Authentication
General process Authentication type can be selected and configured using the Connex Admin tools. Launch Admin tools and select Settings > Device Clinician Authentication. Refer to the Connex CS Customer Project Req. Form, Appendix B1 for detailed settings. “Figure F-1: Basic workflow to configure Device Clinician Authentication” contains a basic workflow to configure an use this feature.
Page 123: View Device Clinician Authentication Settings
Figure F-1: Basic workflow to configure Device Clinician Authentication Multiple Security Providers The Admin Tools tab supports creation of multiple security providers of type ConnexDatabase and Microsoft Active Directory service. View Device Clinician Authentication settings 1. From the central station, navigate to the Settings > Advanced settings (if required) >Admin Tools tab >...
Page 124: Configure For Use With Connex Database
3. A Provider Name listed with a “check” in the status column indicates it is currently in use. Configure for use with Connex Database 1. Select ConnexDatabase to authenticate against the Connex CS Database This is the default setting. See “Figure F-3: ConnexDatabase default settings example”.
Page 125 Figure F-3: ConnexDatabase default settings example Configure Clinician Identifier for Connex CS Database The list of clinician identifiers are available when authenticating against the Connex CS Database are shown below in the table below. Table F-1: Connex CS Database Clinician ID...
Page 126 1. Check each group that applies. 2. Key in additional group names as needed and press the Add button. 3. Each new group must already exist in the Connex CS database Figure F-5: Configure Group membership details, Connex CS Database example...
Page 127 EMR ID is mapped to clinician middle name. But, not all clinicians have a middle name. The Connex CS security provider returns an empty EMR ID to the device when that clinician authenticates at the device. The clinician takes many episodic tests from many patients and attempts to upload.
Page 128 122 Configure Clinician Authentication Configure for use with Active Directory Add a provider for Active Directory 1. On the main window, in the “Add provider” area, select ActiveDirectory from the drop-down list. An example is shown highlighted below. Figure F-7: Select active directory screen example...
Page 129 Enter a user name which has privileges for accessing the active directory. b. This is the account name which will be used by the Connex CS system to make the connection to the facility’s active directory service. Refer to the Connex CS Customer Project Req.
Page 130 Identifier with test vitals and outbound ORU messages to the EMR. 1. Select the clinician identifier for use as the EMR identifier. Refer to the Connex CS Customer Project Req. Form, Appendix B1 as needed for input data in these fields.
Page 131 The admin tool supports capture of other attribute and custom attribute usage. See “Figure F-11: Add a Custom active directory example” below. Refer to the Connex CS Customer Project Req. Form, Appendix B1 as needed for input data in these fields.
Page 132 126 Configure Clinician Authentication Figure F-11: Add a Custom active directory example When changes are complete 1. Click on the Save button at the bottom of the working window. 2. Restart ECS for all changes to take effect. Order the security providers The admin tool provides the capability to reorder the security providers.

Welch Allyn Connex CS Install Manual

1 Introduction

2 Overview and Planning

3 Setup

4 Central Station Startup

5 Connex CS Configuration

6 Final Steps

Quick Links

Need help?

Questions and answers

Related Manuals for Welch Allyn Connex CS

Summary of Contents for Welch Allyn Connex CS

Table of Contents
