- Page 1 FAST TRACK TANK GEN 4B INSTALLATION AND PARTS MANUAL 8295RT, 8320RT, 8345RT 8310RT, 8335RT, 8360RT 8320RT, 8345RT, 8370RT Fast Global Solutions 4130 Commerce Boulevard Windom, MN 56101...
-
Page 2: General Information
General Information All rights, especially copying and distribution rights are reserved. No part of this publication may be reproduced in any form or by any means, electronic or mechanical, including photocopying, without express written permission from Fast Distributing, Inc. Parts information in this manual represents components installed when product was manufactured based upon the best available information. -
Page 3: Table Of Contents
Contents General Information ....................2 Remove Hydraulic Filter Cover, Step Assembly And Tool Box ......4 Remove Center Link Bracket And Radar .............. 5 Install Rear Tank Supports ..................5 Install Receiver Mounting Brackets ..............6 Install Setscrews ..................... 6 Install Radar ...................... -
Page 4: Remove Hydraulic Filter Cover, Step Assembly And Tool Box
Remove Hydraulic Filter Cover, Step WARNING Assembly And Tool Box Step assembly weighs approximately 300 lbs. 1. Remove hydraulic filter cover (1) and set aside. Cover Use an appropriate lifting device to prevent will not be re-installed with tanks installed on tractor. injury. -
Page 5: Remove Center Link Bracket And Radar
Install Rear Tank Supports 7. Remove tool box (8) from bracket. Tool box bracket does not need to be removed. 1. Install right hand tank mount (1) with three M16 x 40mm GR8.8 bolts and three M16 flat washers. Repeat on left side using left hand tank mount, three M16 x 40mm GR8.8 bolts and three M16 flat washers. -
Page 6: Install Receiver Mounting Brackets
Install Receiver Mounting Brackets WARNING WARNING Receiver mounting tube weighs approximately 105 lbs. Use an appropriate lifting device to prevent injury. Receiver mounting bracket weighs approximately 105 lbs. Use an appropriate 6. Raise receiver mounting tube (7) into position with radar lifting device to prevent injury. -
Page 7: Install Radar
2. Install two setscrews (1) in each receiver on left and right- hand tanks. Verify setscrews do not extend inside tubes. Install Radar 1. Attach radar (1) to mounting bracket (2) with existing hardware. -
Page 8: Install Tanks
Install Tanks WARNING Each tank weighs approximately 1100 lbs. Use an appropriate lifting device to prevent injury. 1. Connect an appropriate lifting device to left-hand tank. Tank will balance when strap is 77” from center. Typical Lifting Device 3. Raise tank and guide into position on rear support 2. - Page 9 5. Verify that tube (2) does not extend past front receiver on right-hand side of tractor. 6. Install right-hand side tank using steps 1 and 2. 7. With right-hand tank (3) aligned with front receiver, push tube (2) through right-hand tank. 8.
-
Page 10: Install Straps And Nylon Protector
Install Windshield Washer Reservoir Install Straps And Nylon Protector And DEF Fill Bracket 1. Position strap (1) into place and insert nylon web (2) between strap and tank. Insert studs on straps through 1. Install windshield washer reservoir with supplied holes in tank supports. -
Page 11: Install Step Assembly
Install Step Assembly WARNING 1. Install top step bracket (1) with four 5/8 x 1.5'' carriage Step assembly weighs approximately 300 lbs. bolts (2) and (3), and flange nuts. Refer to torque charts Use an appropriate lifting device to remove in this instruction for bolt torque values. -
Page 12: Tanks And Hardware
Tanks And Hardware 21 22 19 20 13 14 15 16 17 18... - Page 13 Item Vendor Part # Fast Part # Description Quantity ½ Nut Centerlock 1 " Zp ½ Washer " Zp ½ ½ Bolt Hex Head X 1- Zp Gr5 ½ Nut Centerlock 3/8 " Zp M100G 530068 Gasket Manifold 1" FC100 540000 Clamp Manifold 1"...
-
Page 14: Plumbing
Plumbing... - Page 15 Item Vendor Part # Fast Part # Description Quantity M100MPT 530069 1'' Manifold x 1'' MPT HB100 530041 1’’ MPT x 1’’ Hose Barb UV100FP 500009 Valve, 1'' 64016H 540014 Clamp, 1'' HBT100 530056 1'' Hose Barb Tee 1BH200 510016...
- Page 16 • • • • • •...
- Page 17 • N • N • N • N • N • N • N • N...
- Page 18 Fast Global Solutions 4130 Commerce Boulevard Windom, MN 56101 1-800-772-9279 Toll Free 1-507-427-3861 Voice 1-507-427-3030 Fax 12-10-2018 rt Number 989 R ev C Fast Track Tank Gen 4B Part Number 984 Fast Track Tank 8294,8320,8345RT Released 10/1/2010...
