Summary of Contents for Risecomm ZNLY-201
- Page 1 User Manual Smart Router ZNLY-201...
-
Page 2: Preface About This Manual
Risecomm reserves the right to revise this publication and to make changes in content from time to time without obligation on the part of Risecomm to provide notification of such revision or change. Risecomm provides this guide without warranty of any kind, implied or expressed, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. -
Page 3: Table Of Contents
Table of Contents Preface About This Manual......................ii Table of Contents..........................iii Safety and Regulatory Information Important Safety Instructions....................iv FCC STATEMENT........................v FCC Radiation Exposure Statement..................v CHAPTER 1 Overview Package Contents........................1 Introduction..........................1 Features............................. 1 Product Application and Functions..................1 CHAPTER 2 Hardware Features Front Panel.......................... -
Page 4: Safety And Regulatory Information
Safety and Regulatory Information Important Safety Instructions When using your equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: » Read all of the instructions listed here and/or in the user manual before you operate this device. -
Page 5: Fcc Statement
perform safety checks to determine that the device is in safe operating condition. » This device should not be used in an environment that exceeds 60 ºC. FCC STATEMENT This device complies with Part 15 of the FCC Rules Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may... -
Page 6: Chapter 1 Overview
» AC power adapter (plug varies by region) » User Manual » Warranty If any parts are incorrect, missing, or damaged, contact your Risecomm dealer. Keep the carton and original packing materials, in case you need to return the product for repair. Introduction Smart Router ZNLY-201 is specifically designed to centralize management of air conditioners. - Page 7 Smart Router in air conditioning centralized management system is shown in Figure 1: Figure 1 Air conditioning Centralized Management System In the system, the Smart Router ZNLY-201 has the following main functions: » Collects and records the running status of the air conditioners and the room environment data through A/C Manager.
-
Page 8: Chapter 2 Hardware Features
total) , etc. » Remote controls and manages air conditioners. Administrator through the smart router issues a variety of commands to A/C Manager for remote control air conditioners. The smart router can be set up by Administrator to achieve automatic management air conditioners Administrator can also set up the smart router to automatic management air conditioners, such as air conditioner switch, sleep mode, air conditioner operating temperature, working... -
Page 9: Back Panel
Figure 3 Front Panel LEDs Description A blinks light indicates that the PLC/Wireless receiving segment is working. This LED blinks PLC/Wireless receiving LED during data receiving. A blinks light indicates that the PLC/Wireless sending segment is working. This LED blinks PLC/Wireless Sending LED during data transmission. -
Page 10: Reset To Factory Default Settings
Antenna CAUTION: Using a power supply with a different voltage rating than the one included with the Smart Router ZNLY-201 will cause damage and void the warranty for this product. Reset To Factory Default Settings You can reset the router to its factory settings using the reset button. If your router has become unmanageable, or you have forgotten the password and you need to log into it, you may wish to restore it to a factory default condition and reset your router settings. -
Page 11: Chapter 3 Hardware Setup And Getting Started
How to switch STA / AP mode, the specific switching steps are as follows: 1. Disconnect the power supply of the Smart Router; 2. Push the STA/AP button to the STA or AP end; 3. Restart Smart Router. If the button at the STA ends, Smart Router is STA mode. If the button at the AP ends, Smart Router is AP mode. -
Page 12: Getting Started
Plug the power cord into the power port on the Smart Router. 3. Restart Power Plug the other end of the power cord into an electrical wall outlet, and then your network cables are connected. You are ready to start your network. It is important that you start your network in the correct sequence (first power on the Smart Router, and after it finishes starting up, power on the computer). -
Page 13: Wire Network Login And Access
Wire Network Login and Access Log into the web based Smart Router software system through wire network, please do the following: » Launch the web browser from a computer or other device that is connected to the router. » Type in the IP Address of the Router (Default: 192.168.8.18) in the web browser address bar, press the Enter key, and then login window display. -
Page 14: Chapter 4 Product Specifications
Risecomm or from an authorized Risecomm reseller. Risecomm’s sole and exclusive obligation under this limited warranty for retail sales shall be to repair or replace any product or software that does not meet this limited warranty. - Page 15 Risecomm owned trademark, trade name or product identification logos affixed to the product. Risecomm does not warrant to you, the end user, or to anyone else that the software will perform error free or without bugs. Risecomm is not responsible for, and provides “as is”...
- Page 16 Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
