BLACKHAWK! LAN560 Quick Start Manual

5 CCStudio
Setup
A.) Importing a Pre-defined Import or Factory Board
These instructions apply to CCStudio v2.2 - v3.3, but the import dialog varies slightly between ver-
sions. Refer to the
LAN560 Installation Guide
1. Run CCStudio Setup. And for CCStudio v3.0 and earlier, start the "Import a Configuration"
dialog.
2. Find and select "bh-lan560 emulator" from the "Platform" pull down menu located at
the top of the middle CCSetup window or in the center of the import dialog box (this will list
the imports).
LAN560
3. You can narrow down the import options further by using the "Family" pull down (i.e. select
"C55xx" to list all TMS320C55x device imports).
4. When you find your target, or an import close to it, highlight the entry and choose the op-
tion to "add it to your system".
5. If this import setup does not completely match your target, you can edit the properties
manually (i.e. to add or change a GEL file).
6. When finished, save the setup and start CCStudio.
B.) Using Create Board for CCStudio v3.1 and later
1. Run CCStudio Setup.
2. Select the "Create Board" tab and drag the "BH LAN560 Emulator Connection" to My
System on the left. This will prompt you for a connection name. You can enter any string
you want, but at a minimum, it typically includes the emulator name and target DSP or
board name (i.e. "Blackhawk LAN560 - C5509 Emulator").
3.
Now, highlight the new connection name you added under My System and add the avail-
able processor(s) from the middle window to match
4. Save your setup and start CCStudio.
C.) Changing an XDS560 PCI import for CCStudio v2.2-v3.0
1. Run CCStudio Setup and import a setup for the TI XDS560 PCI card that matches your
target (refer to section (A.) above for importing).
2. Highlight the board you added under My System, right click with the mouse and choose
properties.
3. Locate the Emulator Name field under board properties tab and change the name from
"XDS560 0" to "BH560ETH 0". If you need to change other properties (GEL, DSP, etc.) ,
you can do that too.
4. Save CCSetup and start CCStudio.
6 Quick Diagnostic
The is a network device, so when it is powered and connected to your network, you can use the stan-
LAN560
dard Windows PING command to test if the emulator is accessible from your PC. Just enter the command
shown below, which uses the default address. Your
check with your network administrator if you did not originally configure the device.
C:\>ping 10.0.9.1
Blackhawk
123 Gaither Drive, Mt. Laurel, NJ 08054-1701
4
www.blackhawk-dsp.com
if more information is needed.
your hardware.
may be configured with a different address, so
LAN560
Blackhawk is a registered trademark of EWA Technologies, Inc.
LAN560-QSe-04
QUICK
START
GUIDE
ETHERNET DEBUG INSTALL
This ETHERNET debug installation portion of the
ries is intended to show how to configure the
with Code Composer Studio using its LAN port.
For emulator network administration or debugging via the USB interface, please refer
to those specific Quick Start Guides also included with the
Inventory of Items Included
1. Blackhawk LAN560 JTAG Emulator POD
(LAN560) and 12 inch JTAG cable.
2. High-Speed USB 2.0 Compliant Cable
3. Ethernet RJ45 Patch Cable
4. 5 Volt DC power supply
5. AC power cord (s)
6. 20-pin cTI JTAG cable.
7. 20e_cTI-14t_TI Pin Converter
8. 20e_cTI-20t_ARM Pin Converter
9. Installation CD
10. Warranty and Product Registration Cards.
11. Quick Start Guide.
Other Items Required
1. Target Board System—a self-powered
board with a TI DSP and compatible JTAG
header connection conforming to IEEE
1149.1 Standard.
2. Copy of Code Composer Studio Version
†
2.2 or later.
Installation Requirements
•
PC or Notebook computer with one free USB v1.1 or v2.0 port for USB debug or
administration and/or free Ethernet port for LAN debug†.
•
Windows® 2000 or XP/Vista Operating System
•
Texas Instruments Code Composer Studio Version 2.2 or later.
•
CD-ROM Drive.
†
Ethernet connections to a local area network from the LAN560's Ethernet port is made using a standard RJ45
patch cable (supplied). For direct connection (PC to LAN560) an RJ45 cross-over cable is required (not supplied).
administration of TCP/IP address and subnet mask is done via USB port on the emulator.
LAN560
Blackhawk™
LAN560
JTAG
Emulator
(LAN560)
Quick Start Guide se-
LAN560
Emulator for operation
LAN560
JTAG Emulator.
LAN560
I
MPORTANT
E
NVIRONMENTAL
C
ONSIDERATIONS
This equipment is designed to be
operated under the following envi-
ronmental conditions:
Temperature between 0°C –55°C.
Relative Humidity of 20% - 70%
non-condensing.
Operation of the unit outside of the
above range may affect structual
and mechanical integrity and
cause permanent damage.
Caution is necessasry to minimize
ESD (Electro-stactic Discharge)
which can damage electronic
components. Use in a controlled
environment where ESD materials
and practices are employed is
highly recommended.
LAN560
