Summary of Contents for MSTRONIC MIT-904P
- Page 1 MIT-904P/908P/912P Multiport Passive PoE Injector USER’S MANUAL MSTRONIC CO., LTD.
-
Page 2: Hardware Description
Front Panel Figure 2-1. The Front panel of MSE MIT-904P/908P/912P The Front Panel of the MSE MIT-904P/908P/912P consists of 4/8/12 x RJ-45 Ethernet ports (data), 4/8/12 x RJ-45 PoE ports (data + power), 4/8/12 x LED port indicators, each LED indicates the individual port power status. -
Page 3: Led Indicators
Table 2-1. The Description of LED Indicators Rear Panel The C20 AC inlet, and 4 Ventilation fans are located at the rear panel of MIT-904P/908P/912P. The device will work with AC in the range 100-240V AC, 50-60Hz. Power On Connect the power cord to the power socket on the rear panel of the unit. The other side of power cord connects to the power outlet. -
Page 4: Technical Specification
Per port: Green: PoE active Indicator Red: over current Off: no power Operating Temperature: -20℃~60℃ Environment Storage Temperature: -40℃~85℃ Humidity: 10%~95%RH (non condense) Dimensions 430mm(L) x 403mm(W) x 44mm(H), 19” Rack-Mount / 1U Weight 3.6kg 4.9kg 6.5kg MSTRONIC CO., LTD.
