Summary of Contents for AGSTECH 100L
- Page 1 ON LINE DC OUTPUT UPS 100W-300W Rack Mount 19” 1U User’s Manual (DC12V/24V/48V with 2~6 channels) Models: 100L / 150L / 200L / 300L Page 1 of 7 VER.: 1.1...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Functional Description Page 3 2. Installation Instructions Page 4 3. Communication Interface Page 5 4. Block Diagram Page 5 5. LED Indications Page 6 6. Specification Page 7 Page 2 of 7 VER.: 1.1... -
Page 3: Functional Description
1. Functional Description Charging & Power Device design Zero interruption On-line structure design to provide the constant power without interruption. Utility power (normal mode) backup mode (battery mode) Soft start design to protect SPS When AC is connect, SPS will turn on by soft start, then SPS in stable state, It means if connect battery, there will be an inrush current to cause SPS, soft start design will protect SPS. -
Page 4: Installation Instructions
2. Installation Instructions ● The DC UPS may only be installed by trained personnel or qualified engineers. ● Connect DC UPS to the batteries with correct polarity. ● Check all connections for correct polarity! ● Upon starting up the DC UPS with system monitoring, an automatic self-test is carried out. -
Page 5: Communication Interface
3. Communication Interface Dry contact signal: The definition and setup for RS-232 is as following: Baud Rate : 2400 bps Data Length : 8 bits Stop Bit : 1 bit Parity : None 5 4 3 2 1 9 8 7 6 Pin #6 : RS-232 data Tx out. -
Page 6: Led Indications
5. LED Indications The system monitoring provides 8 LEDs to indicate the status of the DC UPS. Front Panel Display LED SIGNAL LED# COLOR Operating Status ① Green AC Normal I/PWR ② (Input Power) Yellow Power Failure ③ Green DC Normal O/PWR ④... -
Page 7: Specification
6. Specification Model AGS-100L AGS-150L AGS-200L AGS-300L Power Rating 100W 150W 200W 300W Input Voltage 135 ~ 285VAC Input Current @220VAC Approx.1A Approx.1.5A Approx.2A Approx.3A Frequency 50/60Hz Output Voltage 44Vdc ~ 56 Vdc (48Vdc) Charge Close Voltage at 20°C 55.20VDC, with temperature compensation Max.
