- Page 1 PIKA T1/E1 (HMP) PCIe Board Copyright (c) 2010. All rights reserved.
-
Page 3: Table Of Contents
PIKA T1/E1 (HMP) PCIe Board Table of Contents Copyright Information Contacting PIKA Technologies Preface Related Documentation Introduction Compliance Board Description Block Diagram Board Dimensions and Component Layout Jumper Settings Expansion Boards Connector Pinouts Technical Specifications Glossary Index... -
Page 5: Copyright Information
This document is provided to you for informational purposes only and is believed to be accurate as of the date of its publication, and is subject to change without notice. PIKA Technologies Inc. assumes no responsibility for any errors or omissions in this document and shall have no obligation to you as a result of having made this document available to you or based upon the information it contains. -
Page 6: Contacting Pika Technologies
PIKA T1/E1 (HMP) PCIe Board Contacting PIKA Technologies Customer Care For support issues, phone or e-mail our Customer Care department at the following: Tel: +1-613-591-1555 FAX: +1-613-591-9295 Email: support@pikatech.com International Headquarters PIKA Technologies Inc. 535 Legget Drive, Suite 400 Ottawa, Ontario, Canada K2K 3B8... -
Page 7: Preface
PIKA T1/E1 (HMP) PCIe Board Preface Organization The document is divided into several sections, each of which covers a particular section of the PIKA Digital T1/E1 PCIe hardware. Regulatory Warnings Industry Canada (IC) Equipment Attachment Limitations NOTICE: The Industry Canada label identifies certified equipment. This certification means the equipment meets certain telecommunications network protective, operational safety requirements. -
Page 8: Related Documentation
If so, you will be given advance notice of the change to give you an opportunity to maintain uninterrupted service. Related Documentation The following documents are related to the PIKA Digital T1/E1 PCIe Board Hardware Manual. These documents are linked together and constitute the complete set of documentation for the AoH SDK product. Software... -
Page 9: Introduction
Introduction The PIKA Digital T1/E1 PCIe card provides a solution for voice and data applications with four spans available for use with T1 or E1 connectivity (SW configurable). The card is part of the HMP family of PIKA cards; all digital signal processing is done on the host processor. - Page 10 PIKA T1/E1 (HMP) PCIe Board 4.1 Compliance NOTE: The term self-declared indicates the card was tested by a third-party test facility, but does not require an official approval number by a country or region’s approval standard authority. For the TBR21 Telecom specification, testing was performed by an in-house test facility.
- Page 11 Approval Approval Description Number United States / Canada CSA C22.2 No. 950 Safety standard for IT and telecom equipment. NRTL/C Europe EN60950 Self-declared Safety of IT and electrical business equipment. ROHS The Digital T1/E1 PCIe board is 2002/95/RoHS 6 compliant.
-
Page 12: Board Description
• Connector pinouts ( see page 10) – description of each electrical connection on all connectors Block Diagram The following figure is a high-level diagram of the circuitry on the Digital T1/E1 PCIe board. Any components located within the large dashed lines indicate components located on the board. -
Page 13: Board Dimensions And Component Layout
PIKA T1/E1 (HMP) PCIe Board The heart of the Digital T1/E1 PCIe board is the Altera EP2C20 FPGA that streams data to and from the host processor through its DMA controller providing a minimum amount of latency. The FPGA also controls and monitors the line reference clocking in conjunction with the DPLL. -
Page 14: Jumper Settings
Jumper Settings The Digital T1/E1 PCIe card has four jumpers that correspond to the four T1/E1 digital line interface jacks, as shown in the following figure. If a line is going to be used for digital logging, the corresponding jumper must be removed from the card. For example, Jumper 1 must be removed if Span 1 is going to be used for digital logging. - Page 15 The Digital T1/E1 PCIe board digital line interface connectors are terminated with an industry-standard RJ-48C connector. Each connector provides access to a T1/E1 digital line interface. the following figure shows the RJ-48C digital line interface jack pinouts. The Transmit and Receive lines are with respect to the Digital T1/E1 PCIe card, not the Telco line.
-
Page 16: Technical Specifications
PIKA T1/E1 (HMP) PCIe Board Technical Specifications Main Board Host Interface PCIe Bus Interface Based on PCIe revision 1.0a specifications PCIe Bus Speed 2.5 GHz, single lane link PCIe Slot Compatibility • x1 - 1 lane • x4 - 4 lanes •... - Page 17 PIKA T1/E1 (HMP) PCIe Board Telephony Interface Digital Line (T1/E1) Physical Connection 4 x RJ48C Digital Framing Software-selectable as T1 or E1 Impedance Software selectable Line build out Software selectable (T1)
-
Page 18: Glossary
PIKA T1/E1 (HMP) PCIe Board Glossary Term Definition Decibel - A logarithmic unit used to describe a ratio. An abbreviation for the power ratio in decibel (dB) of the measured power referenced to one milliwatt (mW). dBm0 An abbreviation for the power in dBm measured at a zero transmission level point. -
Page 19: Index
PIKA T1/E1 (HMP) PCIe Board Index Block Diagram 8 Board Description 8 Board Dimensions and Component Layout 9 Compliance 5 Connector Pinouts 10 Contacting PIKA Technologies 2 Copyright Information 1 Expansion Boards 10 Glossary 14 Introduction 5 Jumper Settings 10...
