Summary of Contents for Dassault AT ARTEMA
- Page 1 ² DASSAULT AT AUTOMATISMES & TELECOMMUNICATIONS ARTEMA Portable & Mobile Installation guide Oct 28, 2000 NT 332 588 Rev 1.6...
-
Page 2: Table Of Contents
NT 332 588 Rev.1.6 ARTEMA Portable & Mobile Installation guide Table of contents Artema presentation ..................2 Installation and connections ................3 2.1 Warning ....................... 3 2.2 Lithium batteries ................... 3 2.3 Environment ....................3 2.4 Battery pack installation ................4 2.5 Optional battery pack installation in base unit (portable version only) ..... -
Page 3: Artema Presentation
NT 332 588 Rev.1.6 ARTEMA Portable & Mobile Installation guide 1 ARTEMA PRESENTATION Paper cover Paper output Printer Magnetic stripe card reader "Power on" Pin Pad* Smart card reader* To phone line** * depending on configuration ** ARTEMA portable only THIS INFORMATION IS PROPRIETARY INFORMATION OF DASSAULT A. -
Page 4: Installation And Connections
Installation guide 2 INSTALLATION AND CONNECTIONS 2.1 Warning Artema is an electrical device. It must be used in normal conditions as described in this manual. DASSAULT A.T. cannot be held responsible for : Damages due to using or servicing Artema other than in the conditions described in this guide. -
Page 5: Battery Pack Installation
NT 332 588 Rev.1.6 ARTEMA Portable & Mobile Installation guide 2.4 Battery pack installation It is important to switch off the terminal before changing the battery pack. Position the battery pack in the back of the handset. Press on the upper part of the battery until a "click" noise is heard. -
Page 6: Installing The Paper Roll
NT 332 588 Rev.1.6 ARTEMA Portable & Mobile Installation guide Installing the paper roll To obtain the highest printing quality, and to ensure maximum printer life span, only use recommended paper rolls 2 x 80 Ft. Open the printer casing by pressing simultaneously on both sides, and by pulling upwards. -
Page 7: Connecting To The Mains Supply
NT 332 588 Rev.1.6 ARTEMA Portable & Mobile Installation guide The printer will work only if the casing is closed and battery is charged. Switch on the terminal, by pressing the "power on" key, and draw an inch of paper to check the roll is correctly placed in its casing. -
Page 8: Radio Link Setup (Portable Version Only)
Other RS232 peripherals such as external Pin pads, Check readers 2.11 Charging ARTEMA Before using Artema for the first time, leave the handset to charge for 8 hours in order to fully charge the battery pack. This should allow you to use Artema in good conditions. -
Page 9: Trouble Shooting & Spare Sparts
Technical maintenance operations should only be done by approved servicing centers … however some problems can easily be solved : Artema stops during display or printing : Recharge the battery by placing the handset on the base for several hours Check the battery is correctly set in the handset... -
Page 10: Technical Specifications
NT 332 588 Rev.1.6 ARTEMA Portable & Mobile Installation guide 4 TECHNICAL SPECIFICATIONS 4.1 Handset specifications Weight 680 g (23.9 OZ) Size 243 x 90 x 65 mm (8.57 x 3.2 x 2.3 inch) Printer Thermal printer Display Liquid Crystal Graphical, Backlit 40 x 132... - Page 11 NT 332 588 Rev.1.6 ARTEMA Portable & Mobile Installation guide COMPLIANCE INFORMATION GENERAL NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 12 REN's, contact the telephone company to determine the maximum REN for the calling area. If the terminal equipment ARTEMA PORTABLE causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required.
- Page 13 NT 332 588 Rev.1.6 ARTEMA Portable & Mobile Installation guide COMPLIANCE INFORMATION MOBILE version This equipment complies with part 22 of the FCC rules. On the hand held unit is a label that contains, among other information, the FCC authorization number (FCC ID) for this equipment.
- Page 14 NT 332 588 Rev.1.6 ARTEMA Portable & Mobile Installation guide Notes THIS INFORMATION IS PROPRIETARY INFORMATION OF DASSAULT A. T. DASSAULT A.T. AND MAY NOT BE USED, COPIED, DISCLOSED OR DIVULGED, IN WHOLE OR IN PART, FOR ANY PURPOSE BY ANY PERSON WITHOUT THE WRITTEN...
