Altox Timer-2 Operating Manual

Technical specification
Rated supply voltage of the device
Current consumed in standby mode
Maximum current of the control output LINE
Maximum analogue output current OUT
Connection diagram
— Connect the power wires through the 500 mA fuse to the battery
terminals or to the OBD-II connector wires (16pin is +12V, 4pin is common).
— The INPUT is connected to an external control source. Waits for a pulsed
GND signal of at least 200 ms duration or a signal with a constant level of
GND (fixation after 10 seconds).
— The OUT output commutes GND. The output is designed to control the
climate control unit in P0 mode or the coolant circulation pump in modes
P1 and P2 using a power relay.
RED +12V / 24V (via the fuse 500mA)
BLACK GND (common)
GREEN INPUT
YELLOW LINE (digital and analogue signal)
WHITE OUT
— LINE is connected to the parking heater control input (digital or analog,
the type of heater is changed through the settings of the mini-timer)
Attention!
By default, the device is configured to automatically detect the digital
type of the heater - setting "A0". To control the heater with an analogue
signal, it is necessary to manually set this type of heater - "A1" in the
device settings.
Note: The device is fixed at the installation site using double-sided tape or
other fasteners.
Authorized service:
Installation date:
— 10V–28V
— 4-5mA
— 50mA
— 150mA
Altox
O p e r a t i o n a l M a n u a l
ALTOX TIMER-2
