PRECAUTIONS
•
Read and understand all instructions before beginning installation.
• NOTICE: For installation by a licensed electrician in accordance with National and/or local Electrical Codes and the following
instructions.
•
Disconnect switch or a circuit breaker must be provided and marked as the disconnecting device.
•
Disconnect switch / circuit breaker must be within reach of operator.
• CAUTION: RISK OF ELECTRICAL SHOCK. Turn power off at service panel before beginning installation. Never wire energized
electrical components.
• CAUTION: USE COPPER CONDUCTOR ONLY
•
Confirm device ratings are suitable for application prior to installation. Use of device in applications beyond its specified ratings or
in applications other than its intended use may cause an unsafe condition and will void manufacturer's warranty.
• NOTICE: Do not install if product appears to be damaged.
SAVE THESE INSTRUCTIONS!
DESCRIPTION
Hubbell Controls' wiSCAPE™ Gateway is used to combine up to 1000 wiSCAPE Fixture Modules into a single wireless network. Although
each Fixture Module is functionally autonomous, the Gateway also acts as an access point through which the modules can be managed,
monitored, and metered through wiSCAPE View™ software. Using the robust 2.4GHz ISM (Industrial, Scientific and medical) radio
frequency, the wiSCAPE Gateway wireless control technology adapts easily to complex automation situations for quick, simple and
economical commissioning and operation.
SPECIFICATIONS
Operation range
Power consumption
Fused supply
Surge protection
Ambient temperature range
Relative humidity
Dimensions
Construction
Certifications
Warranty
9601 Dessau Road, Building One | Austin, TX 78754 Toll Free: 888-698-3242 | Fax: 512-450-1215 | www.hubbell-controls.com
wiSCAPE™ GATEWAY
TM
Installation INSTRUCTIONS
120-240V; 50/60Hz
277/347 required use of step down transformers WIR-STPDNXFMR-277 or 347
18 watts
5 amps
190 Joules (10,000 surge current rating measured using industry standard 8/20 μSec wave)
50/60 HZ, Consumption: max 26 VA
-40
F to 185
F (-40
C to 85
0
0
0
Up to 99% non-condensing (fully waterproof enclosure (NEMA 4x)
12"L x 14"W x 6"H
Compression molded fiberglass reinforced polyester construction with flush,
solid/opaque cover, IP66 Rated
FCC/IC Certified, RoHS Compliant
Five-year limited warranty
C)
0
4501B 07.15.2016
Rev B
Advertisement
Table of Contents
Summary of Contents for HUBBELL LIGHTING wiSCAPE GATEWAY
- Page 1 Fixture Module is functionally autonomous, the Gateway also acts as an access point through which the modules can be managed, monitored, and metered through wiSCAPE View™ software. Using the robust 2.4GHz ISM (Industrial, Scientific and medical) radio frequency, the wiSCAPE Gateway wireless control technology adapts easily to complex automation situations for quick, simple and economical commissioning and operation.
- Page 2 INSTALLATION Turn power off at the service panel. Use appropriate hardware to mount the GATEWAY to the intended structure. Drill or punch an appropriate hole for the power cable. A weatherproof strain relief should be used (customer-supplied) . Mount the GATEWAY in the installation site. Secure the enclosure to prevent any damage.
