Summary of Contents for ESTeem Radius+/195M TNB
- Page 1 Radius+/195M (TNB) High Output Power System User’s Manual ESTeem Industrial Wireless Solutions...
- Page 2 Date: Name: Eric P. Marske Title: Product Manager Approved by: Date: Name: Michael Eller Title: President Electronic Systems Technology, Inc. dba ESTeem Wireless Modems 415 N. Quay Street Building B1 Kennewick, WA 99336 Phone: 509-735-9092 Fax: 509-783-5475 E-mail: market@esteem.com Web Site: www.esteem.com...
- Page 3 2,400 to 115,000 bps. RS-422 – The ESTeem 195M has a single RS-422 data port (Port 2). The RS-422 data port is shared on the front panel with the 10/100 Mbps Ethernet interface. The RS-422 interface is typically used for long distances to 4,000 feet at bauds rate software configurable from 2,400 to 115,000 bps.
- Page 4 RADIUS+ /195M (TNB) USER’S MANUAL Diagrams The following diagrams show the ESTeem Model 195M to Radius+ interface and details on the front panel. Figure 1: Connection Diagram Throughout this tutorial “Technical Tips” have been added to help in programming and answer some common questions.
- Page 5 RADIUS+ /195M (TNB) USER’S MANUAL Figure 2: Front Panel Diagram Figure 3: 195M Front Panel Revised: 30 Jan 2018 3 of 10...
-
Page 6: Installation
ESTeem Narrowband Configuration Utility will be used throughout the remainder of the User’s Manual. 4. The ESTeem 195M will be displayed (Figure 5). If the ESTeem is not on the same IP subnet as the computer, double click on the IP, Netmask or Gateway and make the necessary changes. Press the Apply Changes button when complete. - Page 7 RADIUS+ /195M (TNB) USER’S MANUAL Figure 5: Discovery Found Radio 5. If changes were made to the IP address, you will need to press the Discover EST Radios button again to show the changes. Right-mouse click on the radio and select Configure Radio button to begin programming. Figure 6: Opening Radio Configuration Software 195M Configuration Page The Configuration Page is the default page entered...
- Page 8 USER’S MANUAL Using Utility Program The ESTeem Narrowband Configuration Utility will open on a Radius+ amplifier to the command console menu (Figure 8). This direct interface to the Radius+ will display status information such as the forward and reflected power ratio and allow modification of the software commands.
- Page 9 RADIUS+ /195M (TNB) USER’S MANUAL Figure 9: Firmware Update Advanced Configuration The Radius+ amplifier will display the status of all software commands if Read Config button is pressed (Figure 10). Figure 10: Advanced Configuration Revised: 30 Jan 2018 7 of 10...
- Page 10 RADIUS+ /195M (TNB) USER’S MANUAL Operational Monitoring When the Radius+ amplifier is in normal operation, the console will output the forward and reflected power ratio for every transmission in the following format: fwd/rev ratio, 1815.7 fwd/rev ratio, 1210.0 fwd/rev ratio, 930.3 fwd/rev ratio, 1632.6 fwd/rev ratio, 490.5 fwd/rev ratio, 577.0...
-
Page 11: Software Commands
RADIUS+ /195M (TNB) USER’S MANUAL Software Commands Listed below in alphabetical order are the definitions of the ESTeem Radius+ software commands. All software commands are entered lowercase. ? or help help Displays the modem information and sub help menus. help all Displays all commands switches and arguments. -
Page 12: Specifications
RADIUS+ /195M (TNB) USER’S MANUAL Specifications Radius Plus/Model 195M (TNB) System VHF Specifications Transmitter/Receiver Frequency of Operation 150 to 174 MHz Tx Output Power (Maximum) 25 Watts Tx Output Impedance 50 ohms Rx Insertion Loss 0.7dB FCC ID ENPRADPVHF LED Indicators Power, Transmit, Ethernet Activity / Link Power Requirements Receive...
