Steamers India SI-PRO-LM200K User Manual

For all types of infrared saunas
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
Applicable for all types, regardless which
kind of heaters or which kind of wood.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SI-PRO-LM200K and is the answer not in the manual?

Questions and answers

Summary of Contents for Steamers India SI-PRO-LM200K

  • Page 1 User Manual Applicable for all types, regardless which kind of heaters or which kind of wood.

  • Page 2: Table Of Contents

    Thanks for choosing our infrared sauna. Please take the time to read through this manual carefully. Keep this manual and your proof of purchase for future reference and services. Table of Content TABLE OF CONTENT....…………………………………………………..………. .…..….…. 2 INSTALLATION GUIDE .....…………………………………………………..…… ..….…..

  • Page 3: Installation Guide

    Installation Guide Please read the following directions carefully. The sauna installation requires at least 2 people, and more people if the sauna cabin is big and heavy. You should not try to install the sauna on your own as damage will easily occur. Electrical Requirements Each sauna will require a exclusive circuit when plugged in an outlet.

  • Page 4: Where To Start

    Where to Start Lay the cartons flat on the ground and open them carefully. Open all the cartons, take the floor (bottom panel) from carton A firstly, start to install your sauna pleasantly. Tips: Before the start of installation, or at least before installation of the top panel, please remove the dust-proof cover from the top panel to take out the accessories and screws etc.

  • Page 5: Installation Procedure

    Installation Procedure Connecting Methods of Panels (Walls) There are mainly through buckle locking system to fix sauna panels (walls): Figure C-1: Buckle Locking System Tips: Refer to “Connecting Method of Panels (walls)” on how to assemble the panels together for the following installation procedures. 5 General User Manual for All Types of Infrared Saunas...

  • Page 6: Installation Procedure Section A

    Section A Installation 2 persons carbon heater infrared sauna room. 1, Floor Panel 2, Rear Panel 3, Side Panel 1 4,Bench Supporting and Seat Panel 5, Side Panel 2 6, Front Panel 7, Top Panel & Connect All the Requested Wires and Cables 6 General User Manual for All Types of Infrared Saunas...
  • Page 7 Tips: After assure all the connections done well, assemble the dust-proof cover. Match the hole to the vent, and draw the main power supply cord out. Section B Installation 4 persons carbon heater infrared sauna room. 1, Floor Panel 2, Rear Panel 3, Side Panels 4, Bench Supporting and Seat Panels 5, Front Panel...
  • Page 8 Section C Installation Mixed sauna room (infrared sauna+steam sauna) 1, Floor Panel 2, Rear Panel 3, Side Panel 1 4,Bench Supporting and Seat Panel 5, Side Panel 2 6, Stove Installation 7, Front Panel General User Manual for All Types of Infrared Saunas...
  • Page 9 8, Top Panel & Connect All the Requested Wires and Cables 9, Connect stove cables N, L, GND and assembling stove protector 9 General User Manual for All Types of Infrared Sauna...

  • Page 10: Accessories

    Accessories (Suitable for Infrared and Mixed sauna) Oxygen Ionizer Locate the ionizer plug that is extended out of the sauna ceiling (1-pin plug). Connect the oxygen ionizer and screw it on the back panel. Oxygen Ionizer and Connections The oxygen ionizer is used to refresh the air inside the sauna by killing odor causing bacteria and removing airborne particles.
  • Page 11 Magazine Holder (optional) The magazine holder can be installed on either of side walls, but Do NOT install the magazine holder in front of the heaters. If you don’t like or there is no anywhere suitable to install it, just ignore it.
  • Page 12 Thermo-hygrometer & Sandy timer You can fix them on the walls as per the punched holes or on your desired locations. Wooden bucket & Scoop Firstly install wood supporter and put Wooden bucket and scoop on top of this supporter. 12 General User Manual for All Types of Infrared Saunas...

  • Page 13: Operation Instructions Of Control Panel

    Operation Instructions of Touch Switch Control Panel *If your sauna is with such a control panel, refer to this Operation Instructions. Power Button (On/Off) This button turns the sauna on or off. Temperature Set Button Press this button the temperature icon flash and ready to set temperature.
  • Page 14 Time Button Press this button the time icon flash and ready to set temperature. FM/Bluetooth Switch Button Press this button to switch to FM (Radio) mode. If press this button more than 3s will enter into Bluetooth function. Open the Bluetooth function of your mobile phone and search this device.

  • Page 15: Operation Instructions Of Sawo Stove

    Optional Button Additional functions can through this button to operate. Explosion proof lamp Button Press this button to open/close explosion proof lamp. Operation Instructions of SAWO Stove *If you use mixed sauna with SAWO stove please do as below: The stove with interior controller---rotary switches. 1, The left switch is timer to set working time of the stove.

  • Page 16: Operation Instructions Of Chrome Therapy Light

    3, If the timer doesn’t come to 0, but the temperature reaches the setting value, the stove also will stop working. But timer won’t stop counting down. When the temperature in sauna cabin is lower than the setting value, and timer doesn’t come to 0, the sauna will restart to work.

  • Page 17: Usage Guide

    Usage Guide Conditions to use the sauna: 1, Temperature range: +5~+40 ℃(41-104 F degrees). 2, Relative humidity: ≤85% 3, Depression: 700-1060 Pa 4, Main supply: AC 110V or 220V-240V Frequency 50Hz ±1 or 60Hz ±1 Allow your sauna to warm up for 15-20 minutes or until it reaches 43℃ (110 F degrees).

  • Page 18: Precautions To Use

    Precautions to use  If the temperature becomes unbearable, decrease the temperature or shut off the sauna immediately.   Do not use if pregnant or have serious inflammation, a fever, a communicable disease, acute bleeding, or intoxicated.   Concern the temperature if using the sauna with the elderly or children.

  • Page 19: Cleaning And Maintenance

     Do not bring wet towels into your sauna or any substances that could harm the interior of your sauna.   Do not install a lock on your sauna.   All repairs need to be authorized by the supplier‘s representative; otherwise product warranty may be voided....

  • Page 20: Troubleshooting

    Troubleshooting (Infrared sauna) The sauna does not power on  Make sure the main power plug of the sauna is connected to the socket at your home.   Make sure the main power plug is connected to the electric box on the top of sauna....
  • Page 21 One or a few heaters do not work  Make sure the heaters’ plugs are connected on top of the sauna.   Make sure the heaters’ plugs under the bench are connected.   Floor heater and bench heater are not as hot as other heaters (by design)....
  • Page 22 For more troubleshooting advice or to report a problem, please contact with your supplier. 22 General User Manual for All Types of Infrared Saunas...
