Summary of Contents for ESi Ergo E-CMT-SLV
- Page 1 E-CMT MONITOR ARM ADAPTER FOR STEELCASE C:SCAPE Model E-CMT-SLV ® E-CMT Rev A 2/17 ASSEMBLY/ADJUSTMENT...
- Page 2 E-CMT MONITOR ARM ADAPTER PLEASE REVIEW these instructions before beginning the installation. Check that all parts shown below were provided with your order. Contact your supplier product operates to your satisfaction. The E-CMT monitor arm adapter enables attachment of select Edge and Evolve monitor arms to Steelcase C:Space benching systems.
- Page 3 E-CMT MONITOR ARM ADAPTER Assemble the E-CMT Base • Remove the clamp assembly from the Edge or Evolve base. Use a 4mm Allen key to remove the three screws securing the assembly. • Attach the E-CMT rail mount bracket to the monitor arm base with the three screws previously removed.
- Page 4 E-CMT MONITOR ARM ADAPTER • Insert the nuts into the slot of the 4mm Allen Key assembly into the slot. • Screw down the nuts from the top of the bracket. Tighten the Screw nuts lock into the rail. Rail Attach the Brace (Straight Plate) •...
- Page 5 E-CMT MONITOR ARM ADAPTER Proceed with Monitor Arm Assembly • Install the Evolve pole or Edge monitor arm(s) into the base assembly and proceed according to the instructions that came with the system.
- Page 6 NOTES...
- Page 8 800.833.3746 esiergo.com © 2017 ESI Ergonomic Solutions. All rights reserved. E-CMT Rev A 2/17...
