User Manual
Heavy-Duty Hose Reel Cart | Models: 3570 / 3571
Before you begin
This product has been packaged to ensure it arrives in the best possible condition. Please be careful when
unpacking. This kit contains parts that can be damaged if incorrectly assembled. Please follow instructions.
For more information visit www.hoselink.com.au or call 1300 900 617
Advertisement
Table of Contents
Related Manuals for Hoselink 3570
Summary of Contents for Hoselink 3570
- Page 1 User Manual Heavy-Duty Hose Reel Cart | Models: 3570 / 3571 Before you begin This product has been packaged to ensure it arrives in the best possible condition. Please be careful when unpacking. This kit contains parts that can be damaged if incorrectly assembled. Please follow instructions.
- Page 2 Box Contents Hoselink’s Heavy-Duty Hose Reel Cart has been designed and manufactured using the highest quality materials to take all the work out of watering, gardening and cleaning. Product Features: • Cam-lever braking helps with the drag of the Rear Drum...
- Page 3 User Manual Heavy-Duty Hose Reel Cart | Models: 3570 / 3571 Cart Assembly Step 4 Place crank handle into correct position, secure included Step 1 screw in place using the Installation key (9) Place the Front Drum (2) on top of the Back Drum (1).
- Page 4 Step 7 Step 10 Remove the Screws, Flat Washer and Lock Nuts from each Install the Serrated Lock Nuts onto the Screws. Tighten with of the Cart Legs (8). the installation key (9). Insert the Front Cart Frame (5) into each of the Left and Right Cart Legs (8).
- Page 5 User Manual Heavy-Duty Hose Reel Cart | Models: 3570 / 3571 Step 13 Step 16 Install the Flange Assembly onto the axle ensuring the crank Attach the Swivel (10) to the leader hose. handle is on the outside. Step 14 Step 17 Install the Cam-lever Brake (13) onto the axle.
- Page 6 Hose Installation Step 4 Hand tighten your garden hose to the brass swivel. Step 1 If you are right handed: Install the hose as per images. If you are left handed: Install the hose in the opposite direction. The hose will then wind up from the right hand side.
- Page 7 User Manual Heavy-Duty Hose Reel Cart | Models: 3570 / 3571 How to adjust the Cam-Lever Brake Warranty Hoselink’s mission is to offer excellent products and Step 1 exceptional after sales support. Your hose reel carries a 3 years warranty from the date of purchase. Should you Place the Cam-Lever in the ‘ON’...
- Page 8 Website www.hoselink.com.au Email hello@hoselink.com.au Telephone 1300 900 617 Office address 1/108 Old Pittwater Rd, Brookvale NSW 2100, Australia Mailing Address PO Box 6671, Frenchs Forest NSW 2086...
