AAS EoC-10P User Manual

Ethernet over coax extender 10mbps

The EoC-10P has the advantage of extending span 200m / 650ft by a pair of Ethernet Over Coax

devices with 10Mbps / full duplexer. The EoC-10P saves money and time by using the existing

cables. The EoC-10P is both a transmitter and receiver (full duplex).

Features

•

10 Mbps / Full duplexer

•

Coax cable: RG59 video-grade coaxial cable or better

•

Transmission distance: 200m / 650ft @ RG59 ; 250m / 820ft @ RG6

•

IP Security Surveillance over existing coax cable

•

Very small compact packaging

•

Fast and easy to install

•

BNC connector / RJ45

•

Passive, no power required

www.AAS.com.tw

User Manual – Data Sheet

Ethernet Over Coax Extender

For VGA Resolution IP Camera

10Mbps

EoC-10P

N-4_

N-4a

R201302-V22

Table of Contents

Do you have a question about the EoC-10P and is the answer not in the manual?

Page 1 10Mbps EoC-10P The EoC-10P has the advantage of extending span 200m / 650ft by a pair of Ethernet Over Coax devices with 10Mbps / full duplexer. The EoC-10P saves money and time by using the existing cables. The EoC-10P is both a transmitter and receiver (full duplex).
Page 2 Please read the M anual before attem pting to use this product. Specifications and appearance are subject to change without notice. Disposal of Old Electrical & Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems). This symbol on the product or on its packaging indicates that this product shall not be treated as household waste.
Page 3: Package Contents
Absolutely No Returns will be accepted if any component is missing/damaged. Installation Use Ethernet Cable to connect the Ethernet Port of EoC-10P to the network. Connect a coaxial cable between the two pieces of EoC-10P. Use Ethernet Cable to connect the Ethernet Port to the computer / PoE IP camera.
Page 4: Limited Warranty
Failure to read this notice may result in damaging the camera or device in which the warranty will be voided due to installation error. Related Products Ethernet Over Coax Extender Kit EoC-100K EOC-10P MADE IN TAIWAN Copyright © 2013 by AAS Technology N-4_ N-4a www.AAS.com.tw R201302-V22...
