Grandinroad 61334 Assembly Instructions Manual

7.5ft cienna fir tree
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

PLEASE READ INSTRUCTIONS BEFORE ASSEMBLYING YOUR TREE
Your 7.5' Cienna Fir Tree should contain the following:
If any piece is missing please contact a Grandinroad
Product Specialist
1. BEFORE STARTING TO ASSEMBLE YOUR TREE, CHOOSE A LOCATION NEAR AN 110V
ELECTRICAL WALL OUTLET FOR THE PRELIT TREE.
2. REMOVE THE TREE SECTIONS FROM THE CARTON. SECTION A IS THE BOTTOM,
SECTION B IS THE MIDDLE AND SECTION C IS THE TOP OF THE TREE.
3. PLACE THE TREE STAND ON A LEVEL SURFACE. INSTALL THE BOTTOM END OF THE
LOWER "SECTION A" INTO THE STAND. HOLD THE SECTION IN A LEVEL POSITION AND
TIGHTEN THE EYELET SCREWS IN THE STAND AGAINST THE TREE TRUNK SURFACE.
MAKE SURE THE SCREWS ARE TIGHTENED AS EVENLY AS POSSIBLE MAINTAINING A
SNUG AND SECURE POSITION. (FIG 1~2)
FIGURE 1
7.5ft CIENNA FIR TREE
ASSEMBLY INSTRUCTIONS
(3 SECTIONS WITH 2 EXTENSION CORDS)
(61334)
1 Tree stand
2 Eyelet screws
FIGURE 2
Replacement bulbs and fuses
3 Tree sections labeled A, B, C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 61334 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Grandinroad 61334

Summary of Contents for Grandinroad 61334

  • Page 1 PLEASE READ INSTRUCTIONS BEFORE ASSEMBLYING YOUR TREE Your 7.5’ Cienna Fir Tree should contain the following: 1 Tree stand Replacement bulbs and fuses If any piece is missing please contact a Grandinroad 2 Eyelet screws 3 Tree sections labeled A, B, C Product Specialist HOW TO ASSEMBLE AND SHAPE YOUR TREE: 1.
  • Page 2 4. INSERT THE MIDDLE (“SECTION B”) INTO THE BOTTOM (“SECTION A”) TREE POLE. FINISH BY INSERTING THE TOP (“SECTION C”) INTO THE MIDDLE (“SECTION B”) TREE POLE. (FIG 3~4) FIGURE 3 FIGURE 4 (RECEPTACLE HUB MARKER) 5. LOCATE THE PLUG FROM SECTION C AND PLUG INTO THE RECEPTACLE HUB LOCATED IN SECTION A.
  • Page 3 7.5ft CIENNA FIR TREE:...
  • Page 4 STORAGE GENTLY PRESS BRANCHES AGAINST THE TREE TRUNK AS YOU DISMANTLE THE TREE REMOVE THE TREE STAND FROM SECTION A CAREFULLY PLACE THE TREE SECTIONS AND TREE STAND BACK INTO THE CARTON(S) AND TAPE THEM CLOSED CAUTIONS AND WARNINGS o DO NOT LIFT SECTIONS OF THE TREE WITH THE BRANCHES. LIFT USING THE METAL POLE. o DO NOT STEP ON THE BRANCHES DURING THE ASSEMBLY PROCESS o DO NOT TWIST THE BULBS WHEN REPLACING AND ONLY USE THE SPARE BULBS PROVIDED IN THE CARTON AS REPLACEMENTS.
  • Page 5 PLEASE READ INSTRUCTIONS BEFORE ASSEMBLYING YOUR TREE Your 9’ Cienna Fir Tree should contain the following: 1 Tree stand Replacement bulbs and fuses If any piece is missing please contact a Grandinroad 3 Eyelet screws 4 Tree sections labeled A, B, C, D Product Specialist HOW TO ASSEMBLE AND SHAPE YOUR TREE: 1.
  • Page 6 4. INSERT THE LOWER MIDDLE (“SECTION B”) INTO THE BOTTOM (“SECTION A”) TREE POLE. FOLLOW BY INSERTING UPPER MIDDLE (“SECTION C”) INTO THE LOWER MIDDLE (“SECTION B”). FINISH BY INSERTING THE TOP (“SECTION D”) INTO THE MIDDLE (“SECTION C”) TREE POLE. (FIG 3~5) FIGURE 3 FIGURE 4...
  • Page 7 9ft CIENNA FIR TREE:...
  • Page 8 STORAGE GENTLY PRESS BRANCHES AGAINST THE TREE TRUNK AS YOU DISMANTLE THE TREE REMOVE THE TREE STAND FROM SECTION A CAREFULLY PLACE THE TREE SECTIONS AND TREE STAND BACK INTO THE CARTON(S) AND TAPE THEM CLOSED CAUTIONS AND WARNINGS o DO NOT LIFT SECTIONS OF THE TREE WITH THE BRANCHES. LIFT USING THE METAL POLE. o DO NOT STEP ON THE BRANCHES DURING THE ASSEMBLY PROCESS o DO NOT TWIST THE BULBS WHEN REPLACING AND ONLY USE THE SPARE BULBS PROVIDED IN THE CARTON AS REPLACEMENTS.
