Summary of Contents for eProdigy Bikes Banff
- Page 1 Banff Front & rear basket light assembly eProdigy...
- Page 2 RECOMMENDED TOOLS Our very own eProdigy technical team recommends the following tools to for this task 2.5mm, 3mm, 4mm, and 5mm Allen keys Phillips screw driver Crescent wrench WARNING Keep small parts away from children during assembly Note Do not dispose the carton or packaging until the assembly of the bicycle is complete.
- Page 3 after you remove the stem Instal th Hea Se Moun Replace spacer with head set mount Remove the lug nut from the head tube Remove the spacer Reattach the lug nut Note The spacer is no longer needed...
- Page 4 Secure the wire basket to the head after you reattach the stem Instal th Fron Wir Baske set mount using a Cresent wrench and Philips screw driver On a at surface attatch the axel bracket to the bottom of the front wire basket...
- Page 5 Once you’ve inserted the Front Wicker Basket into its wire frame, its time to ... Insert the cadjustable basket bracket mounts on the back rack. Squeeze the arms of the adjustable basket bracket mounts together till the holes align. Secure the axel bracket to the axel Note...
- Page 6 Place the bottom basket brackets in the Using a at headed tool, adjustable basket bracket mounts. gently push apart the wicker to create four holes aligning to the holes in the bottom basket bracket mounts Note Use the end holes on the brackets for aligment Note Use a back and forth...
- Page 7 Congradulations! Thats it for the basket! You should end up with something like this. Secure the base of the wicker basket between top basket bracket and the bottom basket bracket...
- Page 8 Now its time to ... Instal th Fron Ligh Loosen the rst bolt securing the base of 10 12 the front wire basket making room for the basket bracket Secure the light bracket to the front wire basket...
- Page 9 Plug the light into the input on the hub Note light will be activated once the wheel is in motion. Light can be adjusted to always be on...
- Page 10 12 16 Secure the light Secure the light onto bracket extention onto the light bracket extention the light bracket...
- Page 11 Version 2015.05.05...
