Temperature alert TM-ZP05 Series User Manual

TM-ZP050X Modules
ZPoint OEM Modules
The TM-ZP05X is the 8
Temperature@lert and the first module on the market to feature Temperature@lert's patented
private sensor network management system that enables secure turn-key wireless sensor network
deployment.
As with all Temperature@lert ZPoint devices, the
TM-ZP05X series devices are designed to be
easily integrated into designs without the need for
RF or embedded expertise. Using the latest
version of Temperature@lert's ZPoint wireless
communications platform, the TM-ZP05X family of
modules allows designers to add wireless remote
monitoring and sensor network management
technology without complex software engineering.
Modules send data via cellular or Ethernet
gateways back to Temperature@lert's cloud-
based sensor management and analytics system.

Overview

The Temperature@lert TM-ZP05X modules are low
power 2.4GHz wireless transceivers based on the
ARM Coretex M3 SoC.
Available both in PCB trace antenna and external
antenna via U.FL connector form, Temperature@lert
modules have been designed to be integrated into
any devices without the need for RF experience and
expertise. The TM-ZP05X enables one to add
powerful wireless networking and private sensor
network management to any product and quickly
bring it to market.
The Temperature@lert unique serial command
interface allows designers to quickly integrate
wireless technology without complex engineering.
For custom application development, the TM-ZP05X
series integrates with ease into Temperature@lert's
proven remote monitoring cloud platform.
U.S. Patent Nos. 7,952,485; 8,547,226; 8,248,252; 8,599,012; 8,779,926; and 9,092,967. Additional patents pending.
PRIVATE AND CONFIDENTIAL
th
generation of advanced wireless communication modules from
© 2015 Temperature@lert. All Rights Reserved. Doc 8.7.1.2015.002

Suggested Applications


Connected Gauges

Private Sensor Networks

Industrial Monitoring Solutions

M2M Wireless Solutions

Data Center Monitoring

Energy Monitoring

Facility and Business Monitoring

Production and Manufacturing Solutions

Supply Chain
Enterprise Solutions

White Label Solutions

API Integration Services

Custom Hardware & Software

Analytics Solutions
