Summary of Contents for EZMAX Co., Ltd. EZMP-2000
- Page 1 Report No: BWS-03-EF-0026 FCC ID Q9JEZMP-2000 Date of Test : Jun 14, 2003 Appendix 6. User Manual Refer to the following pages EZMAX Co., Ltd. Digital Audio Player EZMP-2000...
- Page 2 (N.B.) Copyright © 2003 by EZMAX Co., Ltd. All rights reserved. The use of user's manual, pictures, software and other related documents of this product requires the prior permission of EZMAX, whose violation would be followed by a legal action or suit. The content of user's manual are subject to change without any prior notice due to improvements in the product.
- Page 3 Features Thank you for purchasing this product. Make sure to use it after carefully reading the user's manual. This device is small, light and easy to carry, and plays digital music that meets MP3 and WMA standards. This device has been so improved that It could last for 40 hours with only one small battery (AAA battery).
-
Page 4: Table Of Contents
Contents Getting Started 4. Set Equalizer ...... 16 1. What's in the box ....3 5. Set Play Order/Delete File .. 17 2. PC System Requirements .. 4 6. Format Flash Memory ..18 3. Cautions for Safety ..... 5 How to Use MP3 Player Name of Parts 1. -
Page 5: What's In The Box
What's in the box Necklace Earphone User’s Manual MP3 Player USB Cable Install Program CD AAA Size Battery... -
Page 6: Pc System Requirements
2. PC System Requirements There are basic requirements for PC to install software and use mp3 player. Make sure to check recommendations before use. Windows 98SE / ME / 2000 / XP Pentium 200MHz or above USB port supports CD-ROM drive 64 MB RAM or above Free space of hard disk over 20MB (Additional space required for saving music file) -
Page 7: Cautions For Safety
3. Cautions for Safety For Listening to Music Output level of this equipment guarantees quality sound at its middle volume. Since listening at its high volume for a long time may cause a serious damage to your hearing sense, listen at its proper volume. Keep away from Strong Impact or Vibration. -
Page 8: Name Of Parts
1. Name of Parts 1. Earphone Jack 5. MENU Switch 2. USB Port 6. Power( on/off /Play/Stop) button 3. Necklace connection hole 7. Volume button 4. Operation Status LCD window 8. Battery cover... -
Page 9: Name Of Lcd Window Display
2. Name of LCD Window Display 1. Name of song selected or in play. 2. Progress status ( ▶ : Play / ■ : Pause / : Fast Forward / : Rewind ) 3. Battery level... -
Page 10: Install Manager Program
1. Install Manager Program To install manager program, make sure that USB cable isn’t connected to PC while you follow the steps below Insert Install CD into CD-ROM drive, and the following screen will appear and installing will start. (This explanation is an example> of WIN XP. If you are a user of other OS, visit and refer to our website. -
Page 11: Install Usb Driver
1. Install Manager Program 3) Enter user information and 4) Click the “Next” button. then click the "Next" button. 6) Click the “Finish” button. 5) Click the “Next” button. -
Page 12: How To Connect Player To Pc
To download MP3 file from PC, you should use USB cable to connect PC USB PORT and MP3 player. ( You should use USB cable provided when you purchase EZMP-2000. ) 1) Connect the rectangle end of Universal Series Bus (USB) cable to USB port of PC. - Page 13 3. Install USB Driver The following explanation is an example> of WIN98. Since different figures may appear depending on OS of user PC, visit our website and find appropriate information. 1) Connect USB cable to MP3 player and USB port. 2) A message “New Hardware Found”...
- Page 14 3. Install USB Driver 4) When you press the "Finish" button after file is copied, installing USB driver is finished. 5) To check whether USB driver is properly set, double-click the "System" icon [Start] [Setting] - [Control Panel]. Click “Device Manager” Tab and click "+"...
-
Page 15: Description Of Manager Screen
1. Description of Manager Screen Click the [ezMAX] icon on the desktop or click [Start] [Program] [ezMAX] to execute program. When MP3 player is connected with USB connection cable, it automatically reads the memory and displays the files on the screen displaying the memory.. -
Page 16: Download
2. Download (Transmit Music File from PC to MP3 Player) 1) Click the “View Music File” icon ( ) in the menu bar. 2) Select [File]→[Download] in the menu bar. 3) Find the directory where MP3 / WMA file is located and select the file you want. 4) Click the [Open] button to copy the file to the player. -
Page 17: Save File
3. Save File You can save files(Ex. extension file, bmp, doc, zip, etc.) in the internal memory of MP3 Player without mobile storage device. 1) Click the "View File" icon ( ) in the menu bar. 2) Right-click the mouse, select “Download”, and then save the file you want to save from computer to MP3 Player. -
Page 18: Set Equalizer
4. Set Equalizer 1) Select Tool Equalizer in the menu bar. In Equalizer window, you can set various types of sounds such as TREBLE, BASS and DBB and save it in the name you want in the EDIT window. (The following example shows that user sets TREBLE, BASS and DBB in the EDIT window, and saves in the name of “User Mode 1”.) 2) You can select each type you set in TYPE-1, TYPE-2, TYPE-3, TYPE-... -
Page 19: Set Play Order/Delete File
5. Set Play Order and Delete 1) Set Play Order : Select the file you want and then click " " or " " button in the menu bar. 2) Delete MP3 / WMA File : Select the file you want and click " "... -
Page 20: Format Flash Memory
6. Format Flash Memory All files(MP3/WMA file, effect sound setting file and other files saved by user) are all deleted when you select Format button( ). If you delete MP3 file alone, select the file you want and click " "... -
Page 21: Power On / Play
1. Power ON / Play Power ON / Play( MP3, WMA ) If you press [POWER button] a little long, power will be turned on and automatically play music under the same as the environment where the previous music played(sound quality, music to be played, play mode, etc...). -
Page 22: Power Off / Pause
2. Power OFF / Pause Power OFF / Pause If you press [POWER button] a little long, power will be turned off. At this time, the environment is saved inside and will be applied when power is turned on in the next time. If you press [POWER button] while a file is played, it will become Pause ( ■... -
Page 23: Volume Control
3. Volume Control 1) Volume Up Press [ ＋ ] button to volume up while a file is in play(stop) status. 2) Volume Down Press [ － ] button to volume down while a file is in play(stop) status. ! Note: Volume consists of a total of 20 stages. -
Page 24: Select Next/Previous Track
Select Next/Previous Track (Fast Forward/Rewind) 1) Select Next Track (Fast Forward ) To select the next track, push it to [ ] direction while it is played. If you want to fast-forward, press [ ] a little long to select fast forward while it is played. At this time, effect sound you selected in Manager Program will come out. -
Page 25: Menu Mode
5. MENU MODE The following functions are in menu mode. If you press the MENU switch in the direction of the arrow as shown in the figure while it is in Play(Stop) status, the following screen will appear. Underline displays Progress(Selection) status. Selection is moved when you click in the direction of the arrow 1) PLAY Mode ( Default Setting : NORMAL ) - Page 26 5. MENU MODE 2) EQ Mode ( Default Setting : TYPE-1 ) You can save 5 types such that users could select one of them they want. ! Note: Users can directly enter each type at Edit window of Manager Program by adjusting TREBLE, BASS and DBB3.
- Page 27 5. MENU MODE 3) RESUME Mode ( Default Setting : TRACK ) : Listen from the song played last : Listen from the first song in the music file list : Listen from the beginning of the song played last. 4) SCROLL Mode ( Default Setting : LEV-3 ) It is to adjust the screen moving speed of LCD window.
- Page 28 5. MENU MODE 5) POWER Mode ( Default Setting : NORMAL ) :Operation status is always displayed on the LCD window. :LCD screen is turned off in 30 seconds after the last Key is input., when the next key is entered, operation status will be displayed on the LCD window.
- Page 29 5. MENU MODE 7) LIGHT Mode ( Default Setting : NORMAL ) : Light is turned on for 10 seconds and off, after the last Key is input : Light On/Off repeats itself at the interval of 1 second. : Always Light On : Always Light Off 8) KEY-MODE Mode ( Default Setting : MUSIC ) : Music Listening Mode...
- Page 30 5. MENU MODE 9) VERSION Mode Display the current version of Firmware 10) KEY LOCK Mode If you push the Menu button for a few seconds, all the keys is locked. If you push another time, they're unlocked.
-
Page 31: How To Insert Battery
6. How to Insert Battery Open the battery cover and insert a “AAA” battery in accordance with its proper polarity [ ＋ ], [ － ]. -
Page 32: Troubleshooting
1. Troubleshooting Check the followings if any problem occurs when you use products. Key does not work? ・ Check”+”, “-” polarity of battery. ・ Check the remaining level of battery. Cannot be downloaded? ・ Check whether USB cable is properly connected between player and PC. ・... -
Page 33: Specification
2. Specification Memory Capacity Internal memory 64MB/128MB/256MB PC Interface USB 1.1 Maximum speed of file 4Mbps transmission DISPLAY LED BACKLIGHTING GRAPHIC LCD Power DC 1.5V Maximum output of earphone 4mW + 4mW (16Ω) Signal to Noise ratio > 85dB Battery AAA size x 1 Range of frequency 20Hz ~ 20kHz... -
Page 34: Mp3/Wma Responding Music Format
3. MP3 / WMA Responding Music Format 1) MPEG1, MPEG2, MPEG2.5 ( all sampling frequencies, all bit rates ) 2) WMA ( High Rate defined by Microsoft ) Sampling Frequency Bit rate (bps) 48 kHz 128k, 160k, 192k 44.1 kHz 48k, 64k, 80k, 96k, 128k, 160k, 192k 32 kHz 48k, 64k... -
Page 35: Service Information(A/S)
4. Service Information (A/S) If you want latest information about updated Manager or MP3 player, visit our website. Homepage: www.ezmax.co.kr Address : # 302, Keumbong Techno Valley, 59-3 Dangjeong-dong, Gunpo city, Gyeonggi-do Tel : 031-457-9184 Fax : 031-457-9187 e-mail : webmaster@ezmax.co.kr ! Note: If you want A/S due to some breakdown, you can visit our main office and receive it, or send mail(registered mail and home delivery). -
Page 36: Warranty
Warranty We hereby certify as follows: 1. This product is manufactured through strict quality control and inspection process. 2. You can receive free A/S for 1 year after purchase if the product with warranty period is out of order. (If it falls under the case of paid service in this written warranty even if it is within warranty period, you should pay.) 3. - Page 37 NOTICES TO USER This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC WARNING This equipment generates or uses radio frequency energy.
