Summary of Contents for Rose electronics RackView RVR-LCDA17/DVI
- Page 1 RackView LCD Panel Rack Mount LCD Display Panel Installation Operation Manual 10707 Stancliff Road Phone: (281) 933-7673 Houston, Texas 77099 techsupport@rose.com...
- Page 2 RackView LCD Display Panel to be in good working order for one year from the date of purchase from Rose Electronics or an authorized dealer. Should this product fail to be in good working order at any time during this one-year warranty period, Rose Electronics will, at its option, repair or replace the Unit as set forth below.
- Page 3 DECLARATIONS OF CONFORMITY This is to certify that, when installed and used according to the instructions in this manual, the units listed and described here are shielded against the generation of radio interferences in accordance with the application of Council Directives 2014/30/EU and 2014/30/EU, as well as these standards: ■...
-
Page 4: Table Of Contents
TABLE OF CONTENTS Contents Disclaimer System Introduction Features RackView LCD Panel Options Package Contents Additional Items Required Before Installation RackView LCD Panel Models RackView LCD Panel - Rear Connector Layout RackView LCD Panel Chassis Dimensions Operating the RackView LCD Panel OSD Operation PIP and PBP Operation Safety... - Page 5 TABLE OF CONTENTS Appendices Appendix A — Specifications Appendix B — Part Numbers Appendix C — Weight and Dimensions Appendix D — Touchscreen Options Appendix E — RackView LCD Panel Video Options Appendix F — Multi LCD Panel Display Control Appendix G —...
-
Page 6: Disclaimer
(See limited warranty). System Introduction Thank you for choosing the Rose Electronics RackView LCD Display Panel. The RackView Panel is available in several different high-performance LCD display sizes. All RackView Display Panels are rack mounted and operation follows the same general procedure for each panel type. -
Page 7: Package Contents
Package Contents The package contents consist of the following: 1 × RackView LCD display panel unit 1 × External power adapter 1 × Power cable 1 × Manual Some RackView LCD panel units can include additional mounting accessories. Additional Items Required M6 mounting screws and cage nuts are normally provided as accessories with the rack cabinet and not with the RackView LCD panel. -
Page 8: Rackview Lcd Panel Models
MODELS RackView LCD Panel Models The RackView LCD panel is available in 10 different models. The main difference between each of the models is the display size and video resolution capabilities. There are several options available that can differ with each model of RackView LCD panel. -
Page 9: Rackview Lcd Panel Chassis Dimensions
RackView LCD Panel Chassis Dimensions The front, side and bottom dimensions of each of the RackView LCD panels are shown in millimeters RackView LCD Panel 17" RackView LCD Panel 19" RackView LCD Panel 20" RackView LCD Panel 17" Widescreen RackView LCD Panel Manual... - Page 10 RackView LCD Panel Manual...
-
Page 11: Figure 3. Chassis Dimensions And Lcd Panel Graphics
RackView LCD Panel 17" FHD RackView LCD Panel 19" Widescreen RackView LCD Panel 21" FHD Figure 3. Chassis dimensions and LCD panel graphics Please check Appendix C for a listing of all RackView LCD Panel dimensions and weights. RackView LCD Panel Manual... - Page 12 INSTALLATION AND OPERATION Installation Steps for RackView LCD Panels - 17", 19", 17" WS, 17" FHD, 19" WS Step 1 Mount the display panel with an M6 screw set. M6 screw x 4 pcs required (Left & right side). (M6 screw sets are not provided) Step 2 Fix the LCD into the rack.
-
Page 13: Figure 4. Installation Steps For Mounting The Rackview Lcd Panels
Installation Steps for RackView LCD Panel - 21" Step 1 Mount the rear bracket with an M6 screw set. 8 x M6 screw set are required. (M6 screw sets are not provided). Step 2 Insert the upper part of the RackView display panel into the rear bracket. -
Page 14: Operating The Rackview Lcd Panel
Operating the RackView LCD Panel OSD Operation The OSD (On-Screen Display) is activated by pressing the buttons on the front panel of the display frame. The push-button membrane control panel may be mounted horizontally or vertically on the display panel, however the OSD operation is the same for all models. -
Page 15: Figure 6. Osd Configuration And Settings
OSD Configuration and Settings Picture Picture mode: Standard / Vivid / Soft / User mode to choose Brightness: Adjust background black level of the screen image Contrast: Adjust the difference between the image background (black level) and the foreground (white level) Hue: Adjust the screen hue value Saturation: Adjust the saturation of the image color... -
Page 16: Pip And Pbp Operation
PIP and PBP Operation PIP (Picture-In-Picture) and PBP (Picture-By-Picture) settings are available for the following RackView LCD Panel models. PIP/PBP Function: RackView LCD Panel 17” Widescreen, 17” FHD and 21”, 24”, and 4K display models PIP and PBP Settings PIP Mode Display the Sub screen in the Main screen. -
Page 17: Figure 8. Pip And Pbp Video Sources
PBP Size Adjust the size of the Sub-screen (Large/Small) OSD Menu --- MISC --- PBP Mode --- Large/Small PIP / PBP Source To select an input signal for PIP / PBP Sub screen. OSD Menu → MISC → PIP Source → VGA / S-Video / Composite / DVI / HDMI / SDI / YPbPr / TV Figure 8. -
Page 18: Safety
PRODUCT SAFETY Safety The RackView LCD Panel, like all electronic equipment, should be used with care. To protect yourself from possible injury and to minimize the risk of damage to the Unit, read and follow these safety instructions. Follow all instructions and warnings marked on this Unit. ... -
Page 19: Maintenance And Repair
This Unit does not contain any internal user-serviceable parts. In the event a Unit needs repair or maintenance, you must first obtain a Return Authorization (RA) number from Rose Electronics or an authorized repair center. This Return Authorization number must appear on the outside of the shipping container. -
Page 20: Appendices
APPENDICES Appendix A — Specifications RackView LCD 17” LCD (7U) 17” Wide LCD (6U) 17” HI-RES LCD (6U) 19” LCD (8U) 19” Wide LCD (7U) 20” LCD (9U) Panel Dimensions (inch) 18.9 x 12.2 x 2.1 18.9 x 10.5 x 1.9 18.9 x 10.5 x 1.9 18.9 x 114 x 2.1 18.9 x 12.2 x 2.3... -
Page 21: Appendix B - Part Numbers
Appendix B — Part Numbers RVR-LCDA17/DVI/Kn 17" LCD Panel 1280×1024 RVR-LCDA17/DVI/DWS/HD/Kn 17" LCD Panel Widescreen, 1080p RVR-LCDA17/DVI/FHD/Kn 17" LCD Panel Full HD, 1920×1200 RVR-LCDA17-4K/Kn 17" LCD Panel 4K, 3840×2160 RVR-LCDA19/DVI/Kn 19" LCD Panel 1280×1024 RVR-LCDA19/WS/Kn 19" LCD Panel/Widescreen 1440×900 RVR-LCDA20/DVI/Kn 20"... -
Page 22: Table 1. Rackview Lcd Panel - Weights And Dimensions
Appendix C — Weight and Dimensions RackView Weight and Dimensions Product Dimension Packing Dimension Gross Model (W × D × H) approx (W × D × H) approx Weight Weight 18.9 x 2.1 x 12.2 inch 20.8 x 4.9 x 19.5 inch 17"... -
Page 23: Figure 9. Schematic Showing The Back Panel With The Touchscreen Option (Usb-A) Installed
Appendix D — Touchscreen Options RackView LCD Panel with Touchscreen The RackView LCD Panels can be ordered with optional touchscreen support. In most cases, the touchscreen can be either Resistive or Capacitive type, however, the RackView 20" and RackView 17" DWS Widescreen are only available with resistive type touchscreen. -
Page 24: Figure 10. Touchscreen Setup Procedure
Figure 10. Touchscreen setup procedure Appendix E — RackView LCD Panel Video Options RackView Video Options with HDMI, S-Video/BNC and 3G/SDI Video Interface The following video options are available with the range of RackView display panel products The RackView 17" 4K Display Panel and the RackView 23" 4K Display Panel have DisplayPort 4K and HDMI video interface as standard. -
Page 25: Figure 11. Back Panel Of The Rackview Lcd Panel Showing Standard And Optional Connectors
RackView LCD Panel Options – Rear Panel View RackView LCD Panel S-Video/BNC Option Resolutions up to 1920×1200 DVI and VGA with the S- Video/BNC option RackView LCD Panel HDMI/S-Video/BNC Option Resolutions up to 1920×1200 VGA with HDMI and S- Video/BNC option RackView LCD Panel HDMI/S-Video/BNC Option Resolutions up to 1920×1200... -
Page 26: Table 5. Dvi-D And Vga Video Formats
Video Formats (DVI-D and VGA) DVI-D / VGA Input PC Signal Resolution/Refresh Rate Applies to 21" model only Applies to 21" model only 1920 x 1080 x 60Hz Applies to 21" model only Applies to 21" model only 1360 x 768 x 60Hz Applies to 20"... -
Page 27: Figure 12. Multi Display Controller
Appendix F — Multi LCD Panel Display Control Multi LCD Panel Display Control The Multi Panel Display Controller enables up to 64 RackView LCD Display Panels to be controlled from a single PC. This is a very convenient option when the OSD and display settings need to be updated or changed on a regular basis. -
Page 28: Figure 14. Rackview With Dc Power Connector Fitted
Appendix G — RackView DC Power Options RackView DC Power The RackView LCD Panels can be ordered with optional DC power input as specified in the table below. Select the DC voltage required, then add the voltage to the RackView part number as /nnnDC For example, adding 48VDC to a RackView 17”... -
Page 29: Figure 16. Mil Type And Lockable Connectors
Appendix H — RackView MIL Type and Lockable Connectors MIL Type and Lockable Connectors MIL and Lockable type connectors are available for integration with the RackView LCD Panel. For further information on these connectors, please contact Rose Electronics Input Product... - Page 30 ▪ ▪ WWW.ROSE.COM sales@rose.com (800) 333-9343 ▪ ▪ Rose Electronics 10707 Stancliff Road Houston, Texas 77099 Rose USA (281) 933-7673 ▪ Rose Europe +49 (0) 2454 969442 ▪ Rose Asia +65 6324 2322 Rose Australia +61 (0) 421 247083 WWW.ROSE.COM...
