Summary of Contents for Adrenaline Technologies TouchFX TFX1
- Page 1 TFX1 TFX3 Operation & Service Manual *Read this manual before use...
- Page 2 General Remark If you encounter any difficulties or if you need support on how to update and/ or install your TouchFX product, we invite you to contact your local distributor or reach us at info@adrenalineamusements.com or by calling our support line +1.450.932.4205 Adrenaline Amusements Team 2 ...
-
Page 3: Table Of Contents
Table of Contents Chapter 01 – Introduction Preface Safety FCC Notice (United States) Chapter 02 – Product Features Features Voltage Dimensions Chapter 03 – Installation Machine Installation Chapter 04 – Operators’ Menu & Game Setup Operators’ Menu & Game Setup Product Default Settings Chapter 05 –... -
Page 4: Preface
Chapter 1 Preface Please read this page before preparing your TouchFX product for game play The following safety instructions apply to all game operators and service personnel. Specific warnings and cautions will be included throughout this manual. Use the following safety guidelines to help protect the system from potential damage and to ensure your personal safety: § ... -
Page 5: Safety
Chapter 1 Preface Safety Warning To avoid electrical shock, unplug the cabinet before performing installation or service procedures. If a power cord is damaged, it must be replaced by the equivalent power cord available from your distributor. Adrenaline Amusement Inc assumes no liability for any damages or injuries incurred while setting up or servicing the cabinet. -
Page 6: Fcc Notice (United States)
Chapter 1 Preface FCC Notices (United States) Electromagnetic Interference (EMI) is any signal or emission radiated in free space or conducted along power or signal leads, that endangers the functioning of radio navigation or other safety service, or that seriously degrades, obstructs, or repeatedly interrupts a licensed radio communications service. Radio communications services include, but are not limited to, AM/FM commercial broadcast, television, cellular services, radar, air-traffic control, pager, and Personal Communication Services (PCS). -
Page 7: Features
Chapter 2 Game Features Hardware features • Mini ITX INTEL computer • 46’’ FULL HD LCD monitor • Multitouch screen, detects 6 simultaneous touches Cabinet FACTS Height = 8 2’’/ 2 .08m Height = 9 1’’/ 2 .31m Weight ... -
Page 8: Machine Installation
Chapter 3 Machine Installation TFX3 Carefully remove the Cabinet from the shipping container giving yourself enough space. Move the cabinet to the desired location Some TFX3 are shipped in 2 parts, insert the top part. (see fig 1) Insert the 3 fluorescent kits in the blue tubes (see fig 2) Open the coin doors and plug in all 3 plugs from the fluoresrencent to the main power strip Locate the power cord, you have 2 options: insert the power cord to the bottom of the... -
Page 9: Operators' Menu & Game Setup
Chapter 4 Operator Menu & Game Setup This chapter describes how to use the Operator Control Panel to navigate through the Operator Main Menu to set up your product and adjust all the game play parameters. The Operator Menu To access the Operator Menu, use the Operator button located inside the coin door. This screen will appear. - Page 10 Chapter 4 Operator M enu se5ng What i t i s Credits p er G ame 4 Credits r equired t o p lay Game A udio V olume 8 ...
-
Page 11: Chapter 05 - Service & Repair
Chapter 5 Service & Repair Computer connections ADR-11-1002 USB t o I /O b oard Network t o R outer Power b uOon DC f rom P ower s upply Blue ... -
Page 12: Screen
Touch s creen t roubleshoo;ng a nd c alibra;on • Disconnect the USB cable between cabinet and screen, connect the keyboard. Press the letter Q, this should quit the game and fall back to the windows desktop. -
Page 13: Window Booth Error
Troubleshoo;ng-‐ W indows b oot e rror At machine start up if you get a windows error message “Windows b oot m anager” The boot selection failed because a required device is inaccessible. What you are required to do • ... -
Page 14: Troubleshooting
Chapter 5 Troubleshooting Video TroubleShooting No picture and no audio Power Problem, check the power to monitor loose or faulty connections between Monitor and computer, make sure HDMI cable is connected properly to both computer and LCD monitor No power to computer, Verify the computer is ON by the blue LED on the top of the computer. -
Page 15: Fluorescence Tube Replacement
Chapter 5 Fluorescent t ube r eplacement ( TFX3) • Open the coin door and unplug the power cable of the Fluorescent assembly • With a step ladder, lift the fluorescent assemblies from inside the blue tubes • ... -
Page 16: Screen Assembly
Chapter 5 Replacement Parts Screen Assembly TF-00-1010 REF PART NUMBER 1 Monitor b ack f rame TF-‐01-‐1020 2 46’’ M onitor ADR-‐10-‐1001 3 Tempered G lass TF-‐10-‐1220 ... -
Page 17: Door Assembly
Chapter 5 Door Assembly TF-00-1020 REF PART NUMBER 1 Door P anel KA-‐01-‐1130-‐00 2 Coin a ccepor ADR-‐10-‐001-‐00 3 Ticket f eeder Ka-‐01-‐1140-‐00 Blank p anel f or coin ... - Page 18 Chapter 6 I/0 board TF-04-1200 REF Link J4 To o perator b uOon J8 Not u sed J6 To l ow 2 cket s witch J10 ...
- Page 19 Chapter 6 19 ...
- Page 20 Chapter 6 20 ...
