TrickleStar TS1811 Manual

7 OUTLET TIER 2 ADVANCED
ZIGBEE MULTI-SENSOR
®
Premium quality, fireproof surge protection that reduces standby and active power waste from electronics
OVERVIEW
The Tier 2 ZigBee Multi-Sensor Advanced PowerStrip+ (APS+)
®
provides premium quality surge protection and reduces the amount
of standby and active power wasted by electronics.
The APS+ is designed for use with set-top box systems.
The APS+ includes a low voltage RJ11 port which supports the
connection of a Zigbee -enabled multi-sensor that senses radio
®
frequency (RF), infrared (IR), and motion.
The APS+ includes advanced power measurement and patented
auto-threshold detection. This allows the APS to accurately support
all types of televisions from old to new high efficiency types. It
provides automation to reduce wasteful standby and active power,
and it is suitable for TV/home theater applications.
In addition to standard power switching, the APS+ also supports "soft
switching" via high-level CEC commands from the multi-sensor to an
HDMI port on the TV; this feature is known as TAV-Link and will result
in placement of connected HDMI devices into a power-saving state
by high-level commands.
The best way to save energy is to stop wasting it.
TIER 2 ZIGBEE MULTI-SENSOR
ADVANCED
POWERSTRIP+
KEY FEATURES
FIREPROOF SURGE PROTECTION
Traditional surge suppression products use standard MOV (metal oxide
varistor) components. TrickleStar Tier 2 APS+ incorporates advanced
surge protection technology. The MOVs are encased in ceramic and
are capable of suppressing more energy and dissipating heat faster
than traditional MOVs. More importantly, the ceramic casing is fireproof
and therefore is capable of preventing fire during surge conditions.
PRODUCT WARRANTY
10-year product warranty
$20,000 connected equipment warranty
TM
POWERSTRIP+
7 Outlets
2 Always On Outlets (1 outlet transformer spaced)
5 Switched Outlets (1 outlet transformer spaced)
15A resettable circuit breaker
Auto threshold detection
Intelligently adjusts to new equipment
True RMS power sensing
72,000 Amps/1080 Joules
Ceramic surge protection
Low-voltage, optically-isolated RJ11 input
LED status indication (ground, surge status, switched)
<40dB noice filtering
Angled space saver plug
ZigBee enabled multi-sensor
CEC TAV-Link function
TS1811
