Spycentre Security 1080P Action Camera Glasses Quick Start Manual

SpyCentre.com Spy Shop - Since 1993

How to Charge the Battery:

•
Connect the glasses camera to a PC or USB power adapter with the provided Micro USB to USB cable
•
3-4 hours to fully charge
•
Red Light ON = Charging
•
Red Light OFF = Fully charged
•
NOTE: A blue light will flash while the device is recording

How to Set Date/Time

•
Make sure device is turned off before using the provided Micro USB to USB cable to plug it into a computer's
USB port.
•
In the File Folder, double-click on the "SportDV" file, which is a Text Document. Inside, change the line that
reads "Update:N" to "Update:Y" so that the device will accept the alterations.
•
After that, adjust the time in the spaces below in 24-Hour format.
•
Once finished, click on "File" in the top left of the Text File window and click "Save".

How to Record a video file:

•
Make sure the charging/data cable is unplugged from the Charge Port
•
Insert a Micro SD Card (max 32GB) into the Micro SD Card slot, located next to the Charge Port.
•
To turn on the camera press the button on the left side of the glasses frame for about 2 seconds
•
A light will start to flash, indicating a recording has begun, and the light will continue to flash while it is record-
ing.
•
When finished recording, click the same On/Off button quickly to end the recording and go into Standby Mode,
where you can quickly click the button again to start a new recording, or hold the On/Off button down for about 2
seconds while recording or while in standby to turn it off.

How to Playback files:

•
While the device is OFF, plug the Micro USB side of the cable into the glasses, and plug the USB side into a
computer's USB port.
•
Open the File Folder, and you should see files titled "SportDV" and "DCIM." Double-click the "DCIM" and in-
side will be another folder titled "100VIDEO," and all the recordings will be inside there. Double-click on a file to
use your standard media player to play the files, or download VLC Media Player, QuickTime or iTunes.

How to Delete the files on a PC:

•
Open the "DCIM" folder, then the "100VIDEO" folder.
•
Right click on the file you wish to delete and select Delete in the pop up menu

How to Delete the files on a Mac

•
Open the "DCIM" folder, then the "100VIDEO" folder.
•
Right click on the file you wish to delete and select Delete in the pop up menu
•
While the device is still plugged into the Mac go to your trash folder and empty trash.
•
Note: If the above step is not completed the files will not be fully deleted from the device and you will
have a phantom folder that will contain the deleted files that can only be seen by a Windows Computer

How to Reset the Device when Frozen

•
Next to the Charge Port is little hole with a button inside. If the device ever becomes frozen and holding the
On/Off button to turn it off doesn't do anything, press this button for a few seconds and it will reset the device back
to presets, and it should now allow for normal operation.

Specifications:

•
Memory capacity: 32GB SD (not included)
•
Recording format: .MOV
•
Battery power consumption: about 1 & ½ hours
1080P Action Camera Glasses
