Bluetooth car kit manual
Features
ò Embedded Audio Gateway profile
ò Plug in existing mobile phone via 2.5 φ phone jack
ò User-friendly interface that can be used with Bluetooth enabled
headset devices.
ò Support DC output function for charger
ò 10 meter working distance
Front panel
1. Car kit power in plug
2. Status LED
3. Charger output plug
4. Audio cable
5. Holder eject
6. Pair key
Pair with Headset
1. Plug-in the car kit to the car cigar slot and you will see the green LED
flash per 2 seconds
2. Please let car kit into the pairing mode.
3. You can press the 'Pair Key' 3 seconds continually.
You will see the green LED is flashing per 0.5 second then you can
release the press.
(*1)
.
HBK-001
Advertisement
Table of Contents
Summary of Contents for Human Interface Technologies HBK-001
- Page 1 HBK-001 Bluetooth car kit manual Features ò Embedded Audio Gateway profile ò Plug in existing mobile phone via 2.5 φ phone jack ò User-friendly interface that can be used with Bluetooth enabled headset devices. ò Support DC output function for charger ò...
- Page 2 (*2) 4. When pair is finished , the device will enter standby mode. The green LED is flashing per 2 seconds. (*1) Only in standby mode, you can do pair procedure. If you don’t sure which state is. You can plug-out and plug-in of car kit plug again and wait the green LED flash once per 2 seconds.
- Page 3 FCC Statement 1.THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. 2.
