" Cage Machine
5
/
8
WARNING!
Read this Operator's Manual
carefully before using this tool.
Failure to understand and fol-
low the contents of this manual
may result in extensive prop-
erty damage and/or serious
personal injury.
K-750R
Manual
99 Washington Street
Melrose, MA 02176
Phone 781-665-1400
Toll Free 1-800-517-8431
Visit us at www.TestEquipmentDepot.com

Advertisement

Table of Contents
loading

Related Manuals for RIDGID K-750R

Summary of Contents for RIDGID K-750R

  • Page 1 K-750R Manual ″ Cage Machine WARNING! Read this Operator’s Manual carefully before using this tool. Failure to understand and fol- low the contents of this manual may result in extensive prop- erty damage and/or serious 99 Washington Street personal injury.

  • Page 2: Table Of Contents

    K-750R " Cage Machine Table of Contents Recording Form for Machine Model and Serial Number....................1 General Safety Work Area Safety ................................2 Electrical Safety................................2 Personal Safety ................................2 Tool Use and Care ..............................3 Service ..................................3 Specific Safety Information Drain Cleaner Safety ..............................3 Description, Specifications and Standard Equipment Description ..................................4...

  • Page 3: Recording Form For Machine Model And Serial Number

    K-750R K-750R ″ Cage Machine K-750R 5/8″ Cage Machine Record Serial Number below and retain product serial number which is located on nameplate. Serial...

  • Page 4: General Safety

    K-750R " Cage Machine General Safety Information extension cord marked “W-A” or “W”. These cords are rated for outdoor use and reduce the risk of elec- WARNING! Read and understand all instructions. Failure trical shock. to follow all instructions listed below may result in electric shock, fire, and/or serious •...

  • Page 5: Tool Use And Care

    Read this operator’s manual carefully before using conditions. the RIDGID K-750R Drain Cleaner. Failure to under- stand and follow the contents of this manual may Tool Use and Care result in electrical shock, fire, and/or severe per- •...

  • Page 6: Description, Specifications And Standard Equipment Description

    • T-413 3″ Cutter (Figure 4) • T-414 4″ Cutter (Figure 4) • Only use the K-750R to clean drain lines 3″ to 6″ in • Safety & Instruction Card diameter. Follow instructions on the use of the •...

  • Page 7: Machine Assembly

    K-750R " Cage Machine Drain Cleaner is required. The following proce- dures should be followed: Instructions For Mounting Handles and Belt Guard Handles – Assemble handles to machine frame and Figure 4 – T-411 2″, T-413 3″ & T-414 4″ Cutter: Used for secure with two (2) belt guard screws.

  • Page 8: Machine Inspection

    The following procedures GFCI and Plug should be followed to set-up the machine: Foot Switch Figure 6 – K-750R Drain Cleaner 1. Check work area for: • Adequate lighting 2. Make sure the foot switch is present and attached to •...

  • Page 9: Operating Instructions

    K-750R " Cage Machine • Clear path to the electrical outlet that does not To avoid electric shock and electrical WARNING fires, never use an extension cord that is damaged or contain any sources of heat or oil, sharp edges or does not meet the following requirements: moving parts that may damage electrical cord.

  • Page 10: Main Sewer Or Septic Tank Overrun

    K-750R " Cage Machine WARNING Do not allow tension to build up in the cable. This will happen if the cutting tool hits a snag and stops turning, but the motor and its drum continue to rotate. Torque builds until the cable suddenly twists, potentially wrapping around your hand or arm.

  • Page 11: Loading Machine On Vehicle

    K-750R " Cage Machine FOR/OFF/REV switch in FOR (forward) position and follow normal operating procedure. Never operate this machine in REV (reverse) for any other purpose. Operating in reverse can damage a cable and cause serious injury. Loading The Machine On Vehicle Tip machine backwards and rest handles on truck bed.

  • Page 12: Accessories

    WARNING Motor-driven equipment must be kept WARNING been designed to function with the K-750R Drain Cleaning indoors or well covered in rainy weather. Store the Machine. Other accessories suitable for use with other machine in a locked area that is out of reach of children tools may become hazardous when used on the K-750R.

  • Page 13: Troubleshooting

    K-750R " Cage Machine Chart 1 Troubleshooting PROBLEM POSSIBLE REASONS SOLUTION Do Not Force Cable! Let the cutter do the work. Cable is being forced. Cable kinking or breaking. ″ cables in 3″ to 6″ lines. Cable used in incorrect pipe diameter.

  • Page 14: Wiring Diagram

    K-750R " Cage Machine Wiring Diagram...
  • Page 15 No other express warranty applies This FULL LIFETIME WARRANTY is the sole and exclusive warranty for RIDGID ® products. No em- ployee, agent, dealer, or other person is authorized to alter this warranty or make any other warranty on behalf of the RIDGE TOOL COMPANY.
