1. Phone Overview

Center key
Left soft key
Dial/Answer key
Earpiece
Display
Navigation key
Right soft key
Ending/Power key

2. Getting started
2.1 Installing the SIM Cards, T‐flash card and battery.
SIM card carries useful information, including your mobile phone number, PIN
(Personal Identification Number), PUK (PIN Unlocking Key), IMSI (International
Mobile Subscriber Identity), network information, contacts data, and short messages
data.
1) Remove the back cover and lift the battery away.
2) Insert  the  SIM  card  into  the  SIM  card  slot  lightly  with  the  corner  cutting  of  the
card  aligning  to  the  notch  of  the  slot  and  the  gold  plate  of  the  card  facing
downward, till the SIM card cannot be pushed in further.
9
10
11
12
13
14
15

Keypad
Microphone
Charge/Headset port
Headset port
Camera
Speaker
Torch


Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AM86 and is the answer not in the manual?

Questions and answers

Summary of Contents for AMGOO AM86

  • Page 1 1. Phone Overview      1  Center key  Keypad 2  Left soft key  Microphone  3  Dial/Answer key  Charge/Headset port  4  Earpiece  Headset port  5  Display  Camera 6  Navigation key  Speaker 7  Right soft key  Torch 8  Ending/Power key    2. Getting started    2.1 Installing the SIM Cards, T‐flash card and battery.  SIM card carries useful information, including your mobile phone number, PIN  (Personal Identification Number), PUK (PIN Unlocking Key), IMSI (International  Mobile Subscriber Identity), network information, contacts data, and short messages  data.  1) Remove the back cover and lift the battery away.      2) Insert  the  SIM  card  into  the  SIM  card  slot  lightly  with  the  corner  cutting  of  the  card ...
  • Page 2   3) To install the T‐Flash card, open its latch, place its indented side downward, insert  the card into the card slot, and then close the latch.    With the metallic part of the battery facing the metallic part in the battery slot,              press the battery down until it locks into place,then fix its back cover                               2.2 Linking to the Network    After the SIM card and the mobile phone are successfully unlocked, the mobile  phone automatically searches for an available network.  3. Input methods    This mobile phone provides multiple input methods, including India, English input in  both upper and lower case, and numeric input method.    1) Press # key to switch between input methods.  2) Press the * key to enter the Select symbol interface and select a symbol you  want. ...
  • Page 3   With Bluetooth, You can use the Bluetooth to send images, video clips, music, sound  clips and notes, and transfer files from your compatible pc.   4.4 Camera  Use this function to take picture.   4.5 Messages  Messaging is a service provided by your network provider, you may need to apply to  your network operator before sending and receiving messages.  If the short message memory is full, a blinking message icon appears on the top of  the screen.    4.6 Fun & Games     The Mobile phone has two game for the user to play,name Sokoban ,Snake. For  specific operation, please refer to ‘help’ option of the game.   4.7 Tools  Alarm    You can activate one, or multiple as needed. For each alarm clock, the ringing date  and the ringing time can be set.  Calculator    The calculator can add, subtract, multiply and divide.  Calendar    Once you enter this menu, there is a monthly‐view calendar for you to view the date;  you can go to any day you want.    Torch  Select on or off as you per requirement. Long press “0” key to switch on or off in the  standby interface.  World clock  This function allows you to check the standard time in different areas of the world.  Backup  You can choose the options you need to back up.  SIM toolkit    STK service is the tool kit of SIM card. This phone supports the service function .The ...
  • Page 4    You can choose Hide ID display mode.   5) Hide ID:    You can according to their own preferences, to set the menu. 6) Others: Phone Settings    1) Time and date: set the home city, date format, the time format, and detail time  of the location.  2) Language settings: Select the display language for the mobile phone.  3) Dedicated keys: Customize the shortcut functions of the Up, Down, Left, and  Right direction keys.    4) Shortcuts: You can edit shortcut and add shortcut.  5) Scheduled power on/off: Set the time when the mobile phone will be  automatically powered on or off.  Display settings  You can set wallpaper, Idle display, Backlight etc. through this function.  Security settings  1) SIM PIN security PIN code is the personal identification number for SIM card. If  never be modified, the initial password set by network operator should be 1234.  If activated the power‐on PIN code, then you have to input the PIN password  each time you switch the phone on. You can modify the PIN code to prevent your  SIM card being used by others.  2) Phone locked: Secured by phone password, the phone will be protected from  other unauthorized users. After activated this function, you should input  password each time you switch on the phone. The defaulted when you entered.  3) Privacy protection: In this menu, you can set password‐protected on the need of  menu, For the menu open the private protection, need to input a password when ...
  • Page 5  5. Addendum  Common fault diagnosis  Fault phenomenon possible reasons  Cannot turn on The battery is discharged. Charge it with electricity  Wrong SIM Card  SIM card smudgy, clean the SIM card. Reinstall the SIM card. SIM card has been  damaged, replace the SIM card。  Reception bad  Check on the screen of the signal strength indicator, and this is the number of sy mbols in this for 5 case said the strong signal, 2 case said the weak signal  Phone can't dial  you may set the hide the machine number, but your network operator does not  provide this service;  may have a strong interference environment around signal;  may you activate the call barring function;  may you activate the line 2, but your network operator does not provide this ser vice  Battery can’t charge  may have excessive discharge battery, charger needed to connect after a period  of time to charge;  battery performance have been worse;  Unable to connect to the network  signal is too weak, or around the radio interference  SIM card is installed correctly, whether contact undesirable or SIM card has bee n damaged? Such as the SIM card is damaged, please you consultation network s ervice operators  Photographs too dark brightness set low;  environment light around a dark;  Photographs too vague Shooting in a state of motion object   Press the shutter moment cell phone has a slight shaking   Dark  Can't enter service menu May be your SIM card does not support services  Safety precautions:  •Use a wireless hands‐free system ( Headphone, headset) with a low power Blue tooth emitter  • Make sure the cell phone has a low SAR  •Keep your calls short or send a text message (SMS) instead. This advice applies  especially to children, adolescents and pregnant women ...
  • Page 6 •Separate the packaging material according to responsible waste disposal option s and sorting for recycling.   •Always remove the battery from the product, when you do not intend to use th e product anymore it in future.   Don’ts:  • Do not Dismantle your Symphony Product on your own  • Do not give your e‐waste to KabbadiWala / Scrap Dealer/ Rag Pickers.   • Do not dispose‐off the e‐waste in landfills   • Never dump E‐waste in garbage bins.   • Do not dispose of your product at municipal waste bins or rooms.   • Do not throw used batteries into household waste.   Consequences of improper handling and disposal of E‐Waste  • Improper disposal of waste prevents natural resources from being re‐used.   •Some waste contains hazardous chemicals and if not disposed of properly may  release toxins into the soil and water, and also releases greenhouse gases into th e environment   •If e‐waste is not properly disposed of, it can threat to the health and well‐being  of humans and animals and it also has adverse effect on the environment.   •Placing of batteries or devices on or in heating devices, such as microwave, ove ns, stoves, or radiators and improper disposal of batteries may lead to explosion.  • If the battery terminals are in contact with metal objects, it may cause a fire.     Any Changes or modifications not expressly approved by the party responsible for  compliance could void the user's authority to operate the equipment.         This device complies with part 15 of the FCC Rules. Operation is subject to the  following two conditions: (1) This device may not cause harmful interference, and  (2) this device must accept any interference received, including    interference that  may cause undesired operation.            ...
