Specifications

Brand name: MAS

Product name: MAS‐DUO WIRELESS

Product model: BT‐Dual

Version: BT4.1

Operating Frequency Band: 2.4GHz~2.48GHz unlicensed ISM Band

Profile:

HSP1.2, HFP1.6, AVRCP1.4, A2DP v1.2

Support: SBC, AAC, APTX

Microphone: High quality mems mic

Output power: Class 2 power output

Distance range: 10 meter

Battery used: 100mAh (Rechargeable Lithium polymer)

Play back time: up to 5 hours

Standby time: up to 150 hours

Charge time: about 2 hours

MAS DUO

WIRELESS

Spec & User manual

Table of Contents

Need help?

Do you have a question about the MAS-DUO WIRELESS and is the answer not in the manual?

Questions and answers

Summary of Contents for MAS MAS-DUO WIRELESS

Page 1 MAS DUO WIRELESS Spec & User manual Specifications Brand name: MAS Product name: MAS‐DUO WIRELESS Product model: BT‐Dual Version: BT4.1 Operating Frequency Band: 2.4GHz~2.48GHz unlicensed ISM Band Profile: HSP1.2, HFP1.6, AVRCP1.4, A2DP v1.2 Support: SBC, AAC, APTX Microphone: High quality mems mic Output power: Class 2 power output Distance range: 10 meter Battery used: 100mAh (Rechargeable Lithium polymer) Play back time: up to 5 hours Standby time: up to 150 hours Charge time: about 2 hours ...
Page 2 Control Buttons Vol + Vol Up & FW MFB Button Vol – Vol Down & RW USB Charging Port B/R LED Indication Microphone ...
Page 3 Operation Turning ON/OFF Turn on MAS‐DUO WIRELESS When MAS‐DUO is under off mode, press and hold the “MFB” button 2 seconds until WIRELESS you hear a tone and blue LED light 3 times. Turn off MAS‐DUO WIRELESS Press and hold the “MFB” button 4 seconds until you hear a tone and red LED light 1 second. When losing the connection. MAS‐DUO will turn off in 10 minutes automatically. WIRELESS Pairing You are required to pair MAS‐DUO with your mobile phone before using it. WIRELESS 1) Under power off mode. Press and hold the “MFB” button 3 seconds to power on MAS‐DUO , and it will be in pairing mode after power on. ...
Page 4 2) Disconnect the MAS‐DUO in the phone menu. Answer Calls When incoming call, press the “MFB” button to answer the call. Ending Calls During the call, press the “MFB” button to end the call. Rejecting Calls When incoming call, press and hold the “MFB” button for 1 second to reject an incoming call. Answer or reject the second call： ‐Answer the second call: During a call, when another call is coming, short press the “MFB” to pick up the call and the first call will be hold. ‐Reject the second call: During a call, when another call is coming, press and hold “MFB” for 1second to reject the call. Swap the call ‐During the three way call, press “MFB” button twice to swap the call ‐During the three way call, short press “MFB” button to end the current call and another call will be answered automatically. Play/Pause If MAS‐DUO is connected to the phone or other audio device, short press the “MFB” WIRELESS button to starting the music playing. Short press the “MFB” button again to pause the music. Forward Under music mode, short press the “V+” button for 1 second to forward song. Backward Under music mode, short press the “V‐” button for 1second to backward song. Adjusting the Volume To increase the volume –During the call or music, press and hold “V+” button to increase volume by one level. Repeat this procedure until it reaches the desired level. To decrease the volume –During the call or music, press “V‐” button to decrease the volume by one level. Repeat this procedure until it reaches the desired level. Low battery indication and charging charging voltage via USB is 5V. When the battery voltage is lower than ...
Page 5 Red LED steady on Charging completed Red LED off Safety message Attention! Please read this user manual before using the product. Please do not use this product in radiation restricted area. Electrical Equipment forbid area Please turn off MAS‐DUO when seeing the “RF product prohibit sign”. WIRELESS Airplane Please turn off MAS‐DUO when boarding on the airplane aviation safety Medical facilities Please do not use MAS‐DUO in the hospital or near some medical equipment in case WIRELESS it may affect the electromagnetic interference. Please check with medical equipment ...
Page 6 FCC Compliance and Advisory Statement This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, according to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try correct the interference by one or more of the following measures: 1.Reorient the receiving antenna. 2.Increase the separation between the equipment and receiver. 3.Connect the equipment into and outlet on a circuit different from that to which the receiver is connected. 4.Consult the dealer or an experienced radio/TV technician for help. Any special accessories needed for compliance must be specified in ...
Page 7 Master Art of sound Consonance Technology Corporation Address: 4F, No. 150, Nan‐Jing East Rd., Sec. 4, Taipei City 105, Taiwan R.O.C. Website: www.mas‐listen.biz E‐mail: Service@mas‐listen.biz ...

This manual is also suitable for:

Bt-dual
