Summary of Contents for Humes Oasis Clearwater Z54 DELUXE
- Page 1 OWNER OPERATION MANUAL CLEARWATER Z54 DELUXE...
-
Page 2: Table Of Contents
CONTENTS PLEASE READ We urge you to fully read this Manual. The contents are important to your safety and the CLEARWATER Z54 DELUXE SYSTEM OPERATION ..............2 operation of the Clearwater Z54 Deluxe Treatment System. INTRODUCING PRODUCTS INTO THE SYSTEM................ 3 Keep this Manual with other important household manuals for future reference. -
Page 3: Introducing Products Into The System
INTRODUCTION INTRODUCING PRODUCTS INTO The system normally comprises 2 or 3 separate chambers (gravity or pumped system). THE SYSTEM The system comprises a pre-treatment chamber (of 3,560 litres) gravity feeding to a secondary treatment chamber (1,280 litres) incorporating a Zabel A100/300 filter. If a pump is incorporated into the system, the pump well has a capacity of 700 litres. - Page 4 Chemicals Waste Food The following chemicals are prohibited substances and should not be poured into the Some food waste, whether or not it is run through a waste grinder will not be treated by the Treatment System: system, but will remain in solid form and fall to the bottom of the septic tank. Therefore, you should consider not using a waste grinder system, or disposing of these food items through •...
-
Page 5: System Maintenance, Monitoring And Servicing
SYSTEM TROUBLE MAINTENANCE, SHOOTING - MONITORING AND PROCESS FAILURE SERVICING Problem Possible Causes Solutions Remove pump from system The Clearwater Z54 Deluxe is available as either a gravity fed or dosed pump system. The Audible alarm on control The pump has failed, or is and determine if inlet is owner should determine the status of the system, substances introduced into the system, panel is ringing... -
Page 6: Limited Warranty
LIMITED WARRANTY INSTALLATION AND EXCAVATION Oasis Clearwater Systems warrants each Clearwater Z54 Deluxe Treatment System to be free DETAILS from defects in material and workmanship for a period as follows: (a) Concrete structure = 10 years (b) Electrical and mechanical componentry = 12 months (c) Zabel filter = Lifetime Warranty Excavation Dimensions Clearwater Z54 Deluxe Unit 4 metres x 2.5 metres x 1.5 meters From the date of the sale to the ultimate consumer when properly registered with Oasis... -
Page 7: Electrical Requirements
ELECTRICAL Mute Options There are three different mute options; Continuous, Chirp and Auto. REQUIREMENTS Continuous – The buzzer will sound continuously until the mute button is pushed. It will stay muted until the next alarm state occurs Chirp – The buzzer will sound continuously until the mute button is pushed. Once the mute button is pushed, the buzzer will sound for one second every 10 minutes until the fault is cleared. - Page 8 SYSTEM Alarm Light MAINTENANCE, MONITORING AND Z54 Tank SERVICE Auto Chirp Continuous Within the greater Canterbury area, Oasis Clearwater Systems offer an annual service and maintenance contract to ensure your system functions correctly. Switch Service procedure includes the following: (4A Inductive Load) Visual inspection of system to ensure correct biological function of system.
- Page 9 oasisclearwater.co.nz Head Office PO Box 16276 Hornby, Christchurch 8441 0800 48 48 49 03 344 0267 office@oasisclearwater.co.nz W oasisclearwater.co.nz...
