Summary of Contents for Ecomobility Green World LIPO45

Page 1 LIPO45 USER’S MANUAL...
Page 2 Ecomobility Green World S.L. C/ Horizonte 8, Local 6, P.I.S.A. 41927 – Mairena del Aljarafe Sevilla, Andalucía, España, Europa, The World...
Page 3 WELCOME TO THE ELECTRIC REVOLUTION Dear LIPO45 owner: Congratulations, you are taking part of the electric revolution and from Ecomobility Green World we welcome you. The Twenty-First Century will be remembered as the biggest electrification process of urban mobility and this is only possible because of people like you, convinced of changing to a clean and sustainable riding.
Page 4 PAGE LEFT BLANK...
Page 5: Table Of Contents
CONTENTS TABLE Introduction Safety driving Scooter identification First start Display Controls Acceleration and braking Efficiently driving Battery indicator Battery recharge Technical specifications...
Page 6: Introduction
INTRODUCTION Your LIPO45 is a electric scooter that will turn your daily life easier. You can drive it with your car license and you will never worry again about traffic jams, gas stations or parking. We call it #instanttorque and we think it is addictive!
Page 7: Safety Driving
SAFETY DRIVING 4) Battery Check: Make sure your scooter is sufficiently General instructions before riding: charged for your ride and always check the battery 1) Tire pressures: Check the tires for correct inflation indicator while you are riding. Be sure that battery does and for any signs of physical damage.
Page 8 SAFETY DRIVING 10) Parking: Your bike should not be left in strong, direct 8) Safety notice: sunlight or heavy rain for extended periods of time as it will prematurely age and damage paintwork and the general 8.1. Key in “OFF”: To avoid the scooter moving away finish of the scooters appearance and some of the electric unexpectedly, always turn the key to the “OFF”...
Page 9: Scooter Identification
Dealer information: 00376 L1e-B Name of the Dealer: VIN number __________________________________ 3kW 45km/h max255kg Address of the Showroom: Identification Plate _______________________________________ (side) _________________________ ____________ Frame VIN Tlf:____________________________________ (steering column) E-mail: _______________________________________ Invoice date: ___________________________ Scooter information: LIPO45 Model: VIN: _______________________________________...
Page 10: First Start
FIRST START SAFETY CIRCUIT BREAKER KEY LOCK The scooter includes a safety The bike has 2 key locks: circuit breaker under the seat that disconnects all the electric system of the bike in case it detects an extreme overcurrent or overheat and it must be manually rearmed.
Page 11: Display
DISPLAY The display disposes the basic parameters for riding: 1. Turning lights: Right and left turning lights indicator LEDs 2. High beam: High beam indicator LED 3. READY: Indicates that the HV system is connected while 0km/h (ready to ride). 4.
Page 12: Controls
CONTROLS CONTROL ACTION Fixed light: Push the switch up High beam Burst light: Push the button down Right lights: Slide right Turning signal Turn blinkers OFF: Push central button switch Left lights: Slide left Claxon button Sound the claxon: Push The accelerator will be interrupted while any brake lever is pushed.
Page 13 CONTROLS CONTROL ACTION Throttle grip Torque : Twisting the throttle grip Riding backwards: Press the Reverse button and twist the Reverse throttle to ride backwards. Disables traction: Interruptor “OFF” Killswitch Enables traction: Interruptor “ON” The accelerator will be interrupted while any brake lever is pushed.
Page 14: Acceleration And Braking
ACCELERATION AND BRAKING Acceleration tips: 1. Turn the key “ON” and check the killswitch is in “ON” position. Remove the side stand and then your bike will be ready to ride as soon as you twist the throttle. 2. Your scooter has a great acceleration capability. To avoid loosing control you must twist the throttle slowly while speed increases gradually.
Page 15: Efficiently Driving
EFFICIENTLY DRIVING Tips for increasing efficiency (maximum range) : 1. Accelerate gradually and smoothly. Avoid quick unnecessary accelerations. 2. Avoid hard braking, try to anticipate to the brake necessity with time enough to stop the scooter by reg. braking when possible. 3.
Page 16: Battery Indicator
BATTERY INDICATOR 10 bars display BARS VOLTAGE DESCRIPTION INDICATOR 10/10 More than 78V Full battery 5/10 Less than 74V Half battery Less than 2/10 Less than 72V Low battery LOW BATTERY: Under 72V the controller will limit the output current to the motor, therefore the top speed will be reduced to save energy.
Page 17 BATTERY INDICATOR That’s an example about how your battery gets discharged: stage: Exponential area. From 84V to 78V You will notice that first run after charging will easily burn the first battery indicator bar. Don’t worry, it won’t be proportional! stage: Nominal area.
Page 18: Battery Recharge
BATTERY RECHARGE GRID ● The battery must be charged through original external charger (AC-DC converter) for maximum longevity and to preserve warranty. NEVER PLUG THE BATTERY DIRECTLY TO THE GRID (AC). ● Turn the circuit breaker disconnected while charging the battery connected to the 220VAC controller.
Page 19 PAGE LEFT BLANK...
Page 20: Technical Specifications
TECHNICAL SPECIFICATIONS BATERÍA MOTOR Motor type BLDC 12-3000 Battery type Li-ion NMC Motor location Rear Wheel hub motor Nominal voltaje 72 V Field Oriented Control (FOC) Motor controller 150A max – 45A continuos Max voltaje 84 V Torque (max/nominal) 120Nm / 50Nm Power (max/continuous) 3.9 kW / 3 kW Nominal Capacity...
Page 21 TECHNICAL SPECIFICATIONS CYCLE PARTS / BRAKES Aluminium rim Front Wheel 90/90-12 Hub motor Rear Wheel 90/90-12 Front suspension Telescopic fork Rear suspension Dual shock absorber Front brake Disc brake 220mm Rear brake Disc brake 220mm Total lenght 1900mm Seat height 796mm Wheelbase 1300mm...
Page 22 PAGE LEFT BLANK...
Page 23 PÁGINA EN BLANCO...
Page 24 Ecomobility Green World C/ Horizonte 8, Local 6 41927 Mairena del Aljarafe Sevilla – Andalucía – España info@ecomobilitygreenworld.com www.ecomobilitygreenworld.com...
