- Page 1 USER MANUAL ACG4 60CM GAS COOKTOP www.arcappliances.com.au...
- Page 2 Preface Dear Customer, Congratulations on purchasing your new product from Home Appliances. To register your Parts and Labour Warranty, some conditions apply, please refer to your warranty card for more details and contact our Aftersales Support team on: 1800 444 357 and Select 1 Our Customer Care Centre is there to ensure you get the most out of your appliance.
- Page 3 Product - Installation Details For future reference we suggest that you staple a copy of your purchase receipt here and complete the below so the information is always Model Number ACG4 Description 60cm knob controlled gas cooktop Serial Number (Should be noted before installation)
-
Page 4: Table Of Contents
contents Preface Product - Installation Details Contents Safety Warning Safety Instructions Installation Child and People Safety During Use Cleaning and Service Environmental Information Instructions for use and maintenance Description of the appliance How to Use the appliance Safety and Energy saving advice Cleaning and Maintenance Technical instructions Instructions of USE... -
Page 5: Safety Instructions
safety instructions Please take the time to read this Instruction Manual before installing or using the appliance. Instruction Manual must be kept with the appliance for future reference. If the appliance is sold or transferred to another person, ensure the manual is passed onto the new user. The manufacturer declines any liability should these safety measures not be observed. -
Page 6: Installation
installation Warning This appliance shall be installed in Prior to installation, ensure that the accordance with regulations in force gas and electrical supply complies and only used in a well ventilated with the type stated on the rating space. plate. Where the appliance is installed in a The gas pipe and electrical cable marine craft or in caravans, it should... -
Page 7: Child And People Safety
child and people safety Warning The appliance gets hot when it is in use. Children should be kept away until it has cooled. Caution This appliance is designed to be operated by adults. sensory or mental capabilities or lack of experience and knowledge prevents them from using the appliance safety without supervision or instruction by a responsible person to ensure that they can use the appliance safety. -
Page 8: During Use
during use Warning Do not modify this appliance. Burner panel is not designed to operate food. from an external timer or separate remote control system. The use of a gas cooking appliance results Do not use this appliance if it comes in the production of heat and moisture in in contact with water. - Page 9 during use fl Perishable food, plastic items and aerosols may be a ected by heat and materials in the storage drawer should not stored above or below the near this appliance. appliance. Ensure the control knobs are in the this appliance while it is in operation. ‘...
-
Page 10: Cleaning And Service
cleaning and service Warning Never use abrasive or caustic cleaning repaired or serviced by an authorised agents. We recommend using Steel Power and Steel Kleen by Hillmark for Service Engineer and only genuine Cleaning stainless steel surfaces. approved spare parts should be used. -
Page 11: Description Of The Appliance
Model ACG4 Trivets Enamel Wok pan Support Work Top Stainless Steel Dimension (W*D*H) 590mm*500mm*95mm Ignition device Continuous Electric Ignition Type Gas Connection G1/2 thread - Natural Gas (LPG kit supplied) Electric supply 220~240 V ac, 50/60Hz , 0.6watt Burners Rapid - 10.8 MJ/h (1), Semi-rapid - 6.3 MJ/h (2), Auxiliary - 3.6MJ/h (1) -
Page 12: How To Use The Appliance
description of the appliance Accessories Gas-pipe elbow (1) Bracket (4) Sealing strip (4) NG regulator (1) & washers (2) ULPG Pressure test Auxiliary pan Instruction Screw (4) Inj ector (4) point (1) support (1) Manual (1) how to use the appliance The following symbols will appear on the control panel, next to each control knob: Black circle: gas o Large flame: maximum setting... - Page 13 how to use the appliance To ignite a burner: o Press in the control knob of the burner that you wish to light and turn it anti-clockwise to the maximum position. o If you keep the control knob depressed, the automatic ignition for the burner will operate.
-
Page 14: Safety And Energy Saving Advice
safety and energy saving advice - The diameter of the bottom of the pan should correspond to that of the burner. PANS BURNERS that min. max. overlaps the edge of the 200mm 240mm burner. Rapid 200mm 240mm Semi-Rapi 160mm 180mm Auxilliary 120mm 160mm... -
Page 15: Cleaning And Maintenance
cleaning and maintenance o o m m p p l l e e t t e e l l y y cool. commencing any cleaning process. l l i you should clean it using water and a little washing up liquid. Usable Unusable Metal Brush... - Page 16 cleaning and maintenance little detergent or washing up liquid . y l flame holes are clean and completely dry. fi fl cloth and wipe dry with a clean cloth. blocked. Re-assemble of the Rapid, Semi-rapid and Auxilliary burners as follows: Burner Lid Flame Spreader Burner Cup...
- Page 17 using instructions Warnings installer. s (nature of the gas and gas pressure) and the adjustment of the appliance are compatible. (or data plate). This appliance is not to be connected to a combustion product evacuation device. It should be installed and connected in accordance with current installation regulations.
-
Page 18: Positioning
positioning 600mm 600mm* 400mm 400mm *This 600mm measurement is based from the highest point of the cooktop in line with AS 5601-2004 to the bottom of a rangehood This appliance is to be built into a kitchen unit or 600mm worktop, providing the followng minimum distances are allowed for: o The edges of the hob must be a minimum distance of 60mm from a side or rear wall. - Page 19 positioning...
-
Page 20: Installing The Appliance
installing the appliance , s t d i l flame spreader and carefully turn the appliance upside down and place it on a cushioned mat. Take care that the Ignition devices and flame supervision devices are not damaged in this operation. -
Page 21: Gas Connection
gas connection ■ This appliance must be installed and connected in accordance with installa- tion regulations in force in the country in which the appliance is to be used. ■ This appliance is supplied to run on natural gas only and cannot be used on any other type of gas without modification. - Page 22 connection ■ Flexible Ho se: If installing with a hose a ssembly, it mu st comply with AS/NZS 1869, 10 m m ID, class B or D, no mo ore than 1 long and ins talled in accordance with AS/NZS 5601.1.
-
Page 23: Gas Specifition
6.3Mj/h 3.6 Mj/h 27 Mj/h Universal 0.88 0.68 0.53 2.75kPa 220 - 240V ACG4 50/60Hz Natural 1.50 1.12 0.83 1.0kPa NOTE Natural Gas maximum supply pressure is 5.0 kPa and minimum is 1.13 kPa Universal LPG maximum supply pressure is 2.75 kPa and minimum is 2.75 kPa... -
Page 24: Electrical Connection
electrical connection ■ This appliance must be earthed. ■ This appliance is designed to be connected to a 0~240V, 50/60Hz AC electricity supply. ■ The wires in the mains lead are coloured in accordance with the following code ; - Green/yellow = Earth - Blue = Neutral - Brown... -
Page 25: Gas Conversion
gas conversion ■ Take precautions on the operations and adjustments to be carried out when converting from one gas to another. ■ All work must be carried out by a qualified technician. ■ Before you begin, turn off the gas and electricity supply to the appliance. injector in place. -
Page 26: Troubleshooting
trouble shooting Repairs should be performed by a licensed technician only. Improper repair may result in considerable ■ danger to you and others. ■ However, some minor problems can be resolved as follows : Problem Probable cause Solution No Spark. Check the electricity supply Not ignited The gas supply is closed. - Page 27 This page has been left BLANK intentionally...
