2460 Controller User Manual www.s-a-m.com Information and Notices 1. Information and Notices 1.1 Copyright and Disclaimer Copyright protection claimed includes all forms and matters of copyrightable material and information now allowed by statutory or judicial law or hereinafter granted, including without limitation, material generated from the software programs which are displayed on the screen such as icons, screen display looks etc.
Dispose of used batteries according to the manufacturers instructions. Batteries should only be replaced by trained service technicians The 2460 Controller card(s) contain a Lithium battery to provide non-volatile memory. • Used batteries should be disposed of in accordance with the manufacturers...
(labelled MOR-2460 and IQRCTL2460 respectively). The 2460 controller is a PC card where all the time critical commands for the system’s broadcast devices are stored and executed. Each card can control any combination of serial, IP, and GPI controlled devices.
16 slots available in an IQ enclosure. Rear panels are available for single controllers and dual-redundant pairs, and occupy three and four rear panels positions respectively. See Table 2 on page 13 for 2460 controller card combinations in a single enclosure.
2460 Controller User Manual www.s-a-m.com Controller Card Installation and Removal 4.2 Opening and Closing the Front Panel To open the front panel: Turn the locking screw approximately half a turn to release the panel. Pull the panel forward and downward using the handle that runs along the top edge of the panel.
Controller Card Installation and Removal Ensure correct orientation of the 2460 controller and that the left controller PCB is aligned with the upper and lower enclosure card guide slots, see Fig 5. Carefully slide in the new module until it fully mates with the rear connector panel.
Heatsink Connector Fig 6. 2460 Controller Card LEDs (Viewed from the Front Edge of the Card) Jumpers and Headers are present on the 2460 controller card and these are for SAM Use Note: Only. Issue 1 Rev 3 Page 10...
Single controllers: Pressing the reset on a single controller will cause the 2460 controller to reboot. All communication with the 2460 controller will be lost during the reset. Because of this no Important: switching outputs or status messages will be available during the reset.
A temperature and load sensitive cooling fan is fitted Humidity Range: 10 to 85% (non condensing) Power Rating Load Units (LU) 26 LU per 2460 Controller IQH3B enclosure; 165 LU Max. IQ3HB 3U Enclosure Capacity: 3 x dual-redundant pairs of controllers...
The rear connector panels provide different levels of connectivity for either single or dual-redundant cards and the number of ports required. The panels share many similar connectors. All connectors are detailed in the Connectors section. See “2460 Controller Card Rear Panel Connectors” on page 16.
2460 Controller User Manual www.s-a-m.com Specification 6.2.2 1494 Rear Panel (Automation and Router Control Systems) This rear panel variant provides 16-port capability and dual-redundancy. Only connect one Ethernet cable to each controller, either of the controller Ethernet Note: connectors can be used. Connecting two Ethernet cables to a controller will result in communication failure for that controller.
2460 Controller User Manual www.s-a-m.com Specification 6.3 2460 Controller Card Rear Panel Connectors 6.3.1 Timecode LTC signal input and balanced AES reference input available on the Timecode connector. The Timecode connector is a 9-way D-type socket (DE-9F) with the following pinouts:...
2460 Controller User Manual www.s-a-m.com Specification 6.3.5 GPIO The GPIO connector is a 25-way D-type socket (DB-25F) with the following pinouts: Signal Signal GPI_0 GPI_13 GPI_1 GPI_14 GPI_2 GPI_15 GPI_3 GPI_4 5V (0.5A max.) GPI_5 GPI_6 GPI_7 GPI_8 GPI_9 GPI_10...
2460 Controller User Manual www.s-a-m.com Specification 6.3.8 COMM 1-8 (37 Way) The COMM 1-8 connector is a 37-way D-type socket (DC-37F) with the following pinouts: 2460 Port Functioning as an: RS232 RS485/422 RS485/422 Device Controller Device (DCE) Rx 1+ Tx 1+...
2460 Controller User Manual www.s-a-m.com Specification 6.3.9 COMM 9-16 (37 Way) The COMM 9-16 connector is a 37-way D-type socket (DC-37F) with the following pinouts: 2460 Port Functioning as an: RS485/422 RS485/422 Controller Device Rx 9+ Tx 9+ Rx 9-...
For pin connections to the 37-way socket, see “COMM 1-8 (37 Way)” on page 18 and “COMM 9-16 (37 Way)” on page 19. Each of the eight 9-way D-type sockets has the following pinouts: 2460 Port Functioning as an: RS232 RS485/422...
