Barksdale UTA 2 Operating Instructions

Dimensions – Electronic temperature sensor UTF 2
in mm (inch)
8
M12x1
Ø27 (1.06)
A
B
ØG1/4"
Ø6 (0.74)
Operating Instructions
Electronic Pressure and Temperature Transducers
UPA 2, UTA 2 and UTF 2
1 Intended Applications ................................................................................................... 2
2 Safety Instructions ......................................................................................................... 2
3 Standards ....................................................................................................................... 3
4 Warranty/Guaranty ......................................................................................................... 3
5 Installation/Commissioning .......................................................................................... 3
6 Maintenance/Cleaning ................................................................................................... 5
7 Technical Data ................................................................................................................ 5
Barksdale GmbH
Dorn-Assenheimer Straße 27
D-61203 Reichelsheim
Phone: +49 (6035) 949-0
Fax: +49 (6035) 949-111 and 949-113
eMail: i nfo@barksdale.de
H H H H
Internet: www.barksdale.de
Art. no. 923-1910
Index: C, 15.08.2018
Specifications are subject to changes
without notice!
1
