Page 1: Table Of Contents
Contents ■ CHAPTER 1. INTRODUCTION..............1 ................1 ACKAGE ONTENTS Wireless LAN Card PC C ..............1 ESCRIPTIONS ............... 2 YSTEM EQUIREMENTS ..............2 ETWORK ONFIGURATIONS CHAPTER 2. INSTALLING DRIVERS & CLIENT UTILITY ..... 4 User’s Manual 95/98/ME/2000/XP......... 4 NSTALLATION FOR INDOWS ............
Page 2: Chapter 1. Introduction
Chapter 1. Introduction System Requirements This chapter describes the package contents, PC Card description, system Installation of the PC Card requires: requirements, features & benefits, applications and network configurations 1. PC/AT compatible computer with PCMCIA Type II slot. of our wireless LAN products. 2.
Page 3: Chapter 2. Installing Drivers & Client Utility
Infrastructure Mode The infrastructure mode requires the use of an access point (AP). In this Chapter 2. Installing Drivers & Client Utility mode, all wireless communications between two computers have to be via This chapter describes how to install the PC Card drivers and client utility the AP no matter the AP is wired to Ethernet network or stand-alone.
Page 4 4. Clicking Continue button to start driver installation shown as following figures. 6. Click Finish button to complete setup and then restart your computer. 7. Insert the PC Card into the PCMCIA slot of your computer. 8. A warning message would pop up while installation, the message shows this driver need the “digital signature”, and click the Yes button.
Page 5: Hecking After Installation
9. Make sure that the network protocol parameters are set correctly for Checking after Installation your computer. These include the IP address, subnet mask, gateway After installing the driver and utility, follow the steps below to check that and DNS. If you are unfamiliar with how to set network protocol the PC Card is operating correctly.
Page 6: Wireless Lan Client Utility
5. If you find the Yellow (?) sign on the adapter or the above message is Wireless LAN Client Utility not displayed, it shows the installation is not successful or the wireless Wireless LAN Client Utility is used to display or change the PC Card LAN PC Card is not operating properly.
Page 7 1. Link Info 2. Configuration State Network Type Shows status information about the radio link, as shown in Figure 2-5 Selects one of the following network type, as shown in Figure 2-6. Associated BSSID – means the wireless client is connected to an access point.
Page 8 You can set this to Fully Automatic, 1Mbps, 2Mbps, Auto 1 or 2Mbps, 5.5Mbps, or 11Mbps. (Default setting is Fully Automatic) Peer-to-Peer Channel Select the operating radio frequency channel in 802.11 peer-to-peer mode. 3. Encryption If you require high security in transmission, you can select 64 or 128-bit WEP (Wired Equivalent Privacy) key to encrypt data (Default setting is Disable) as shown in Figure 2-7.
Page 9: Uninstalling Driver And Utility
Chapter 3. Connecting to a Network This chapter describes how to prepare for connection to network after install the PC Card drivers and utility. The following is required for all computers if you want to connect to a network. 1. Check Client for Microsoft Networks is installed. 2.
Page 10: Checking And Adding Netbeui
Checking and Adding NetBEUI NetBEUI is a protocol you can use to connect to Windows NT, Windows for Workgroups, or LAN Manager servers. If you work on Microsoft network environment, you need to set up NetBEUI protocol. Repeat the step 2 and 3 of Chapter 3-1 Checking and Adding Client for Microsoft Networks.
Page 11: Checking And Adding File And Printer Sharing For Microsoft Networks
Checking and Adding File and Printer Sharing for Microsoft Networks File and printer sharing for Microsoft networks gives you the ability to share your files or printers with Windows NT and Windows for Workgroups computers. If you want to share your files or printers with Microsoft networks, you need to set up this service.
Page 12: Chapter 4. Troubleshooting
configured correctly. Chapter 4. Troubleshooting Nonfunctioning card LED The PC Card is not powered on. The cause may This chapter describes the problems and corresponding solutions that may --No Driver loaded or installed. occur when installing a PC Card. --Card – Driver mismatch which prevented the driver from loading.
Page 13: Chapter 5. Product Specifications
Spain, 4 for France particular installation. If this equipment does cause harmful interference to RF Output Power 19dBm (WPC-8110), 13dBm (WPC-2110) radio or television reception, which can be determined by turning the Sensitivity @FER=0.08 11 Mbps <-85dBm (WPC-8110), 83dBm(WPC-...
Page 14 +886 2 2228 7748 exceeds the following technical standards: Declares that the product: EN 300 328-2 EN 301 489-1 Date：November 29, 2002 Brand Name：SendFar Technology Co., Ltd. EN 301 489-17 Model Number：WPC-8110 EN 60950 Equipment Type：Wireless LAN Card Marking by the symbol：...
