Custom Printing Available
R-3 COMMERCIAL
User HandBook
Warning:
KEEP ALL FLAME AND HEAT SOURCES AWAY FROM THIS GAZEBO FABRIC.
This Gazebo is made with fabric that meets CPAI-84 Specifications for
flame resistance. It is not fire proof. The fabric will burn if left in continuous
contact with any flame source. The application of any foreign substance to the
.
gazebo fabric may render the flame-resistant properties ineffective.
Made in China
Undercover
Littleton, CO
®
Advertisement
Summary of Contents for UnderCover R-3 COMMERCIAL
- Page 1 Custom Printing Available R-3 COMMERCIAL User HandBook Warning: KEEP ALL FLAME AND HEAT SOURCES AWAY FROM THIS GAZEBO FABRIC. This Gazebo is made with fabric that meets CPAI-84 Specifications for flame resistance. It is not fire proof. The fabric will burn if left in continuous contact with any flame source.
- Page 2 Must Be Securely Anchored At All Times RAIN WARNING Do not leave unattended in continuous precipitation as water can pocket and cause frame damage. Material is water resistant however we recommend using an occa- sional waterproof spray to help prevent minor seam drip-...
-
Page 3: Warranty
You have taken a giant step into a new world of Personal-Shelter ® The Best Choice in Popup-Shade ... wherever life-takes-you! Caution! Please read this before proceeding. As a new Undercover ® User it's your responsibility to be fully aware of the following warnings. The frame MUST-BE-STAKED or properly weighted down at all times. - Page 4 Continuous light rain can eventually collect on corner top sections causing eventual frame failure. This type of Align the (4) Velcro corners damage is not covered under warranty. All rights reserved Undercover ® 2015...
- Page 5 1) Remove spikes or weighted anchors. 2) Lower all four telescopic legs. 3) Release all four red corner-sliders 4) From middle position lift frame and walk inward until closed. Lock each corner. 5) Store in wheel bag. All rights reserved Undercover ® 2015...
- Page 6 Find wall center CUTOUT and Find Velcro Attachments to wrap wrap outside of each corner leg. corners as required. Attach the two clips located Mix-n-Match configuration as between the middle wall cutout desired. section. All rights reserved Undercover ® 2015...
-
Page 7: User Information
Apply seam sealer, when subjected to certain weather conditions the seams may wick/saturate eventually leading to dripping. To help minimize seam dripping Undercover highly recommends applying 303 Fabric Guard waterproof spray application on all seams from time-to-time. This can be found on Amazon.com Quick Tips: * Telescopic legs feature more than one height-adjustment. - Page 8 ANCHOR, even in no-wind conditions the shel- Once under the frame, gently ter can get airborne causing push up from bottom of peak pole damage or injury. (center pole) until fully expanded. All rights reserved Undercover ® 2015...
-
Page 9: Replacement Parts
CRS Wire Bolt Sleeve Corner Mold Corner-Slider Leg-Slider SRT™ Mold OUR CUSTOMER SERVICE Team Undercover is available to provide you with needed replacement parts and/or answer any questions, regarding setup, operation or troubleshooting. service@getundercover.com GetUndercover.com All rights reserved Undercover ® 2015... -
Page 10: Rules Of The Road
NEVER setup near overhanging or other electrical wires. NEVER setup in an electrical storm. CAUTION any unattended shelter can cause serious injury and or damage. CAUTION always properly anchor your Undercover ® CAUTION electrical wires can cause serious injury when in contact with frame. - Page 11 The Inner-Truss provides PVC tubes with quick-tie-straps. Fill with Undercover shades to release updrafts and unilateral side-and-peak support for sand, water or rock. Adds 160 LBS of promote cooler air circulation. lightweight durability and strength.
- Page 12 Popup-Shade Evolved ® R-3 User HandBook GetUndercover.com...
