Angerole GARMIN 796 Installation Notes

Thank you for buying this mount from Angerole. We try to take great care
with, and are proud of, the fit, finish, and build quality of our products.
If you find that the the quality of anything you see in this kit is not
satisfactory, we would like to know about it.
These notes are intended to accompany the exploded parts diagram. Please
read them thoroughly and review the diagram before beginning to
assemble your mount.
We suggest the following assembly sequence:
1. Before you begin, please make sure your kit is complete: There
should be 5 aluminum pieces, some bolts and washers, a rubber o-
ring and 2 allen keys
2. Hook the o-ring (part #14) over the lips of the yoke arm adaptor
(Part #1). It's easy to do with your fingers. The o-ring is the seal to
keep dust and dirt out of your control yoke
3. Attach the retainer (part #2) to the yoke arm adaptor with the two
10-32 socket cap head screws (part #13) and washers (part #12).
Thread the screws in just far enough that their end is flush with
the back face of the retainer.
4. Sitting in your airplane, remove the factory spring steel cover from
the inspection hole on the back of your yoke. You can probably do
this with your fingernail (it's not in there very tight) but it might be
easier to lever it off with a small screwdriver. No force should be
necessary.
5. Hold the yoke arm adaptor so that the wider end of the tapered
center hole is facing up. Thread one end of the retainer through the
inspection hole and slide the whole assembly to that side until the
bolt touches the hole's edge. The other end of the retainer will now
be clear of the other end of the hole and can be inserted. Settle the
adaptor into the hole and tighten the two 10-32 screws with the
large allen key. This is much easier to do than describe and should
take only a few seconds.
6. When the retaining screws are tight, the whole assembly will be
firm and rigid. Looking down from above, you should see the adaptor
will be settled completely into the inspection hole. Because the
yoke arm's back face is curved, the adaptor will only touch at the
centre. The top and bottom edges will be clear of the yoke casting
and the gap will be filled and sealed by the o-ring.
7. If you ever want to remove the mount from your yoke, undo the
screws just enough to wriggle the retainer out of the hole. You

INSTALLATION NOTES

GARMIN 796 MOUNT FOR BARON
MODEL 241 053
