T&R Sports CT100BSTX User Manual

Once a person on the trampoline max.user weight 6ft(80kgs) 8ft /10ft(100kgs) max.user weight 12ft /13ft/14ft/15ft/16ft(120kgs)
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL
Thank you for purchasing our product.
IN CASE OF MISSING OR BROKEN
PARTS, PLEASE CONTACT PLACE OF
PURCHASE FOR ASSISTANCE.
Warning: The supplier is not liable for any injuries that may
occur when using the trampoline.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CT100BSTX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for T&R Sports CT100BSTX

  • Page 1 USER MANUAL Thank you for purchasing our product. IN CASE OF MISSING OR BROKEN PARTS, PLEASE CONTACT PLACE OF PURCHASE FOR ASSISTANCE. Warning: The supplier is not liable for any injuries that may occur when using the trampoline.

  • Page 2: Table Of Contents

    CONTENTS GENERAL SAFETY--------------------------------------------------------------1 SAFE USE INSTRUCTIONS........................1 USE OF TRAMPOLINE...........................2 TIPS TO REDUCE THE RISK OF ACCIDENTS..................3 ADVISORY PRECAUTIONS WHILE USING THE TRAMPOLINE............4 DANGER IDENTIFICATION........................5 TRAMPOLINE TECHNIQUES-------------------------------------------------6 BASIC SKILLS............................6 ADVANCED SKILLS..........................7 TRAMPOLINE ASSEMBLY----------------------------------------------------8 NET ASSEMBLY----------------------------------------------------------------14 CARE AND MAINTENANCE-------------------------------------------------18 Once a person on the trampoline Max.User weight 6FT(80kgs) 8FT /10FT(100kgs) Max.User weight 12FT /13FT/14FT/15FT/16FT(120kgs)

  • Page 3: General Safety

    GENERAL SAFETY SAFE USE INSTRUCTIONS BEFORE YOU BEGIN USING YOUR TRAMPOLINE: Read and understand the information provided in this manual. As with all physical sports and activities there is the risk of participants receiving an injury. To ensure your future enjoyment and the prevention of injury, be sure to follow appropriate safety rules and tips.

  • Page 4: Use Of Trampoline

    GENERAL SAFETY USE OF TRAMPOLINE INITIALLY, you should get accustomed to your trampoline and understand how much spring is in each bounce. The focus at this point should be body position and technique until each skill can be completed with ease and control. ...

  • Page 5: Tips To Reduce The Risk Of Accidents

    GENERAL SAFETY TIPS TO REDUCE THE RISK OF ACCIDENTS In order to reduce the risk of accident the "TRAMPOLINE USER" should: Always remain in control of their jumps and body position at all times.  Not attempt to perform skills that are beyond their own level of competence. ...

  • Page 6: Advisory Precautions While Using The Trampoline

    GENERAL SAFETY ADVISORY PRECAUTIONS WHILE USING THE TRAMPOLINE Do not use trampoline if you have consumed alcohol or narcotic substances.  You should climb on and off the trampoline in a controlled and careful manner. Never  jump onto or off the trampoline and never use the trampoline as a means to bounce onto or into another object.

  • Page 7: Danger Identification

    GENERAL SAFETY DANGER IDENTIFICATION MOUNTING AND DISMOUNTING: Be very careful when getting on and off the trampoline. DO NOT mount the trampoline by grabbing the frame pad, stepping onto the springs or by jumping onto the mat of the trampoline from an object (e.g. a deck, roof, or ladder).This is considered highly dangerous.

  • Page 8: Trampoline Techniques

    TRAMPOLINE TECHNIQUES BASIC SKILLS BASIC SKILL 1: The Basic Bounce Start from a standing position, with feet shoulder width apart head up  and eyes on the trampoline bed. Swing arms forward and up above head in a circular motion. ...

  • Page 9: Advanced Skills

    TRAMPOLINE TECHNIQUES ADVANCED SKILLS ADVANCED SKILL 1: The Basic Bounce Start with a low basic bounce (BASIC SKILL1) in the normal position.  Land on your hands and knees at the same time, ensure that back is  horizontal to the bounce mat and hands & legs are shoulder width apart also.

  • Page 10: Trampoline Assembly

    TRAMPOLINE ASSEMBLY To be assembled by adults ONLY. To assemble this trampoline all you need are the tools provided, including our special spring tool. During periods of non-use this trampoline can be easily disassembled and stored. Please read the assembly instructions before beginning to assemble the product. Please refer to the table below for part descriptions and numbers.
  • Page 11 TRAMPOLINE ASSEMBLY PARTS LIST Ref. Part Description Unit 6’ Number Number Trampoline Mat,stitched with TR800 D-Rings TR801 Frame Pad TR802 Top Frame with leg sockets TR803 Leg Base TR804 Vertical Leg Extension TR805 Springs TR806 Safety Instruction Placard TR807 spring tool TR808 Bolt Pack TR809...
  • Page 12 TRAMPOLINE ASSEMBLY Frame layout Lay out all the frame parts as shown in the pictures below. 10’,12',14' Trampolines (4 Legs) 16'Trampoline(6 Legs) 6' Trampoline ( 3 Legs ) 8',10' Trampolines (3 Legs) ASSEMBLY TIPS Assembly should only be done by adults. Minimum of two people are needed for the assembly.
  • Page 13 TRAMPOLINE ASSEMBLY STEP 1: - Top Frame and Leg Extension Assembly  Using one T Connector (TR809) connect two frame pieces (TR802).  Insert one leg extension pole (TR804) into each leg socket in the T Section. Secure extension pole using a bolt washer and nut.
  • Page 14 TRAMPOLINE ASSEMBLY STEP 4: ATTACHING THE SPRINGS TO TRAMPOLINE MAT To install the mat the tension needs to be evenly applied. The diagram on the right shows the position of the first four springs to be connected. The table below shows the corresponding location of the springs depending on trampoline size.
  • Page 15 TRAMPOLINE ASSEMBLY STEP 5 - Safety Placard Attachment Using the tie wrap, attach the Safety Instruction Placard (7) to the trampoline. The tie wrap should go around the Vertical Frame joint and the Top Rail to ensure that it doesn’t slide off the trampoline.

  • Page 16: Net Assembly

    Net Assembly PARTS LIST Ref. Part Description Unit 6/8” Number Number TR810 Bottom tube TR811 Top tube TR812 Top cap TR813 Bolts TR814 TR815 Fiberglass rod TR816 Galvanize connector STEP 1 -Net Pole Assembly A. Connect the bottom tube and top tube. Insert these into the black PVC sleeve (see pictures).
  • Page 17 Net Assembly STEP 2 - Top Ring Assembly A. Assemble two even lengths of fiberglass rods using the galvanize connectors as shown below. B. Lie the net flat as shown. C. Run the two even lengths of the rods through the loops at the top of the net. - 15 -...
  • Page 18 Net Assembly D. Have one person stand on two of the ends of the rods while someone else pushes forward and connects one side of the net as per picture. E. To make the last connection have one person stand on the opposite side. Push the rods towards the centre of the ring until they are in line with each other and make the last connection.
  • Page 19 Net Assembly STEP 3 – Securing Net. A. Raise the net up into position and clip the ring into the Top Caps. Top Cap B. Starting by the door connect one loop to a spring as per the picture below this is point Using the table and graphic below count the number of loops and springs attach loops at points B, C and D.

  • Page 20: Care And Maintenance

    CARE AND MAINTENANCE This trampoline was designed and manufactured with quality materials and craftsmanship. If proper care and maintenance is provided, it will provide all jumpers with years of exercise, fun, and enjoyment as well as reduce the risk of injury. Please follow the guidelines listed below: This trampoline is designed to withhold a certain amount of weight and use.

This manual is also suitable for:

Ct140bstxCt130bstx
