Newport SMC-RC Quick Start

SMC-RC Remote Control for SMC100CC
High jog deceleration:
Low jog velocity:
Low jog acceleration:
Low jog deceleration:
Any jog motion always respects the software limits (see settings in the
software utility or with the SL and SR commands). When approaching a
software limit, the controller decelerates with the programmed accelera-
tion even if the jog buttons are pressed.
Pressing the Exec. button when the three most right letters are DIS, gets
NOTE
the controller to the DISABLE state. In DISABLE state the motor is not ener-
gized and the control loop is open. But the encoder is still read and the cur-
For a complete description
of all commands, please rent position gets updated. The DISABLE state can be used for instance for
refer to the SMC100CC manual adjustments or to make sure that no energy goes to the motor. To
go from DISABLE state to the JOGGING state, press the Exec. button again.
User's Manual.
The buttons of the keypad can get disabled by the JD command.
The keypad does not allow stopping any motion started from a computer
(all buttons are disabled when the controller is in MOVING state). To
take computer control when the controller is in JOGGING state the con-
troller must first get to the READY state (change state from the software
utility or by using the JD command).
