MODEL Number: W85747
30" Electric Warming Drawer, Rated 120V, 60 Hz, 4
Electrical:
120 Volt, 60 Hz, AC Only 15- or 20- amp.
Use copper wire only. A time-delay or circuit breaker
And separate circuit is recommended.
TABLE OF CONTENTS
SAFETY INSTRUCTIONS ... ............ ..... .... ........ ........ ................ ............ ......... ........... ...... ..... ...... ......
INSTALLATION INSTRUCTIONS ......... ... . ............ ..... ... ... ......... ............. .................... .... ....... ... ..........
OPERATING INSTRUCTIONS..........................................................................................................
CLEANING & MAINTENANCE..........................................................................................................
TROUBLE SHOOTING GUIDE ...... ..... ... ........... ........ .... ... ................. ........... ............. ............ ......... .... 5
PARTS LIST .. . . .. . . . . . . . . .. . . . . .. . . . . . . . . . . . . . . . . . . ......... ..... . . . .. . . .. . . . . . . . . . .. . . . . . . ... . ... ... .. . .. . . . . . . . . . . .. . ... . . . . . ... .. . . .. . . ..
WARRANTY....................................................................................................................................
READ THE FOLLOWING INSTRUCTIONS CAREFULLY AND BE SURE YOUR WARMING DRAWER IS PROPERLY INSTALLED,
ASSEMBLED AND CARED FOR. FAILURE TO FOLLOW THESE INSTRUCTIONS MAY RESULT I N SERIOUS BODILY INJURY
I
AND/OR PROPERTY DAMAGE. IF YOU HAVE QUESTIONS CONCERNING ASSEMBLY OR OPERATION, CONSULT YOUR
DEALER OR APPLIANCE SERVICE REPRESENTATIVE.
NOTE TO INSTALLER:
LEAVE THESE INSTRUCTIONS WITH THE CONSUMER AFTER INSTALLATION.
NOTE TO THE CONSUMER
RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
