PNEUMATIC HACKSAW
Please read this manual carefully before you attempt to use
your tool so that you may use it properly and safely.
SUPER SAW
PROFESSIONAL TOOL
Due to continuous product development/improvement the specifications and configurations in
this document are subject to change without prior notice.
Keep the manual handy – so you can use it whenever necessary.
Specifications
Model
Maximum Operating Pressure
Air Consumption (No Load)
Stroke Speed (No Load)
Stroke Length
Mass (Weight)
Sound Pressure Level
Sound Power Level
Vibration Level [Uncertainty K]
Thread Size of Air Inlet
Model SSW-110
SSW-110
0.6 MPa
3
0.29 m
/min
7000 min
11 mm
0.62 kg
71 dB(A)
82 dB(A)
2
9.3 m/s
[2.7 m/s
Rc1/4
Manufactured by :
NITTO KOHKI Co., Ltd.
2-9-4, Nakaikegami, Ohta-ku,
Tokyo, 146-8555, Japan
Tel
: (81)-3-3755-1111
Fax
: (81)-3-3753-8791
E-mail : overseas@nitto-kohki.co.jp
URL
: www.nitto-kohki.co.jp
Original Instructions
-1
2
]
Advertisement
Table of Contents
Summary of Contents for Nitto Kohki SSW-110
- Page 1 Thread Size of Air Inlet Rc1/4 Due to continuous product development/improvement the specifications and configurations in this document are subject to change without prior notice. Manufactured by : NITTO KOHKI Co., Ltd. 2-9-4, Nakaikegami, Ohta-ku, Tokyo, 146-8555, Japan : (81)-3-3755-1111 : (81)-3-3753-8791 E-mail : overseas@nitto-kohki.co.jp...
-
Page 2: Table Of Contents
7. ORDERING SERVICE PARTS …………………………… 5 German : Bitte fragen Sie lhren Händler ・ 8. STORAGE ………………………………………………… 5 nach eine Betriebsanleitung in 9. EXPLODED DIAGRAM : SSW-110 ……………………… 6 Landessprache. French : S'il vous plait, veuillez demandez ・ PICTOGRAM á votre foumisseur de manuel instruction en langue locale. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY BEFORE OPERATION INSTRUCTIONS Inspect tool before use. ● Before using, check that screws are securely When using the tool, please observe the safety tightened, that any protective cover or guard is precautions below to prevent possible accident or injury. securely in place, other parts are free from damage GENERAL: TOOLS and that the tool runs as it should. -
Page 4: Instructions For This Tool
When a label/nameplate gets damaged, worn or Do not pull the air hose to disconnect. becomes missing, contact the sales agent through which you have purchased your tool or Nitto Kohki INSTRUCTIONS FOR Co. Ltd, directly for a replacement. THIS TOOL... -
Page 5: Usage
Loosen Hex. Socket Set Screw 6×6 with Hex. Package Contents Check Socket Screw Key 3. Insert the grip of a new Blade SUPER SAW SSW-110 1set into the groove on Guide Shaft as far as it stops, and Bushing R1/4xNPT1/4 retighten the Screw with Hex. -
Page 6: Thread Size Of Hose Fitting
6. OPTIONAL PARTS In addition to standard accessory parts, the following parts are available for your applications and needs. Part No. Description TA9A005 Saw Blade 32 Ass’y (10pcs) Fig.3 TA9A011 Saw Blade 24 Ass’y (10pcs) TB00193 Saw Blade 18 Ass’y (10pcs) 4-3. -
Page 7: Exploded Diagram : Ssw-110
9. EXPLODED DIAGRAM : SSW-110 Warning This diagram is for refrence only. Do not attempt to service or repair the Tool. Do not take the Tool apart. Contact an authorized Nitto dealer for all service and repair of the Tool. - Page 8 Lerchenstr.47 D-71144 Steinenbronn, Germany Tel: (49)-7-157-22436 Fax:(49)-7-157-22437 NITTO KOHKI CO., LTD., SHENZHEN REPRESENTATIVE OFFICE NITTO KOHKI CO., LTD., SINGAPORE BRANCH 2005C Shenzhen ICC Tower, Fuhuasanlu 168, Futian District, 10 UBI CRESCENT #01-62, Shenzhen, Guangdong, 518048 China UBI TECHPARK LOBBY D, SINGAPORE 408564,...
