Summary of Contents for Topview EB1927WSL
- Page 1 EB1927WSL LCD MONITOR USER'S MANUAL...
- Page 2 Before operating the monitor, please read this manual thoroughly. This manual should be retained for future reference. FCC Class B Radio Frequency Interference Statement WARNING: (FOR FCC CERTIFIED MODELS) NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 3 SPECIAL NOTES ON LCD MONITORS The following symptoms are normal with LCD monitor and do not indicate a problem. NOTES • Turn off the Power Switch and then turn it on again to make • • The LCD screen has effective pixels of 99.99% or more. It may include blemishes of 0.01% or less such as a missing pixel or a pixel lit all of the time.
- Page 4 OPERATING INSTRUCTIONS GENERAL INSTRUCTIONS Press the power button to turn the monitor on or off. The other control buttons are located at front panel of the monitor (See Figure 4). By changing these settings, the picture can be adjusted to your personal preferences. •...
- Page 5 ADJUSTING THE PICTURE The descriptions for function control Main Menu Item Main Menu Icon Sub Menu Item Sub Menu Description Contrast Contrast from Digital-register Brightness Backlight Adjustment Standard Standard Mode Text Text Mode Internet Internet Mode Luminance Eco Mode Game Game Mode Movie Movie Mode...
- Page 6 PLUG AND PLAY PLUG & PLAY DDC2B FEATURE This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities. The DDC2B is a bi-directional data channel based on the I2C protocol.
-
Page 7: Preset Display Modes
APPENDIX SPECIFICATIONS Model Name EB1927WSL EB2027WSL EB2227WSL Viewable Image Size 47.0cm (18.5") diagonal 49.5cm (19.5") diagonal 54.7cm (21.5") diagonal Pixel Pitch 0.27mm (Horizontal) × 0.27mm(Vertical ) 0.2482mm (Horizontal) × 0.2482mm(Vertical ) 0.300mm(Horizontal) x 0.300mm(Vertical) Active Display Area 409.8mm(Horizontal) x 230.4mm(Vertical) 432.0mm (Horizontal) ×...
