Specified Air Solutions VIRTUAL WALL Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
WARNING
Improper installation, adjustment, alteration, service
or maintenance can result in death, injury or
property damage. Read the Installation, Operation
and Service Manual thoroughly before installing or
servicing this equipment.
Installation must be done by an electrician qualified
in the installation and service of control systems
for heating equipment.
© 2017 Specified Air Solutions
Installation Manual
Installer
Please take the time to read and understand
these instructions prior to any installation.
Installer must give a copy of this manual to the owner.
Owner
Keep this manual in a safe place in order to provide
your service technician with necessary information.
Specified Air Solutions
1250 William Street
Buffalo, New York 14206
Telephone: +1.716.852.4400
Fax: +1.716.852.0854
Toll Free: 800.828.7450
www.specifiedair.com
P/N 1010100NA Orig

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VIRTUAL WALL and is the answer not in the manual?

Questions and answers

Summary of Contents for Specified Air Solutions VIRTUAL WALL

  • Page 1 Installation must be done by an electrician qualified in the installation and service of control systems for heating equipment. Specified Air Solutions 1250 William Street Buffalo, New York 14206 Telephone: +1.716.852.4400 Fax: +1.716.852.0854 Toll Free: 800.828.7450 www.specifiedair.com © 2017 Specified Air Solutions P/N 1010100NA Orig...

  • Page 3: Table Of Contents

    6.8 Trending ..............25 6.9 Alarms ............... 29 6.10 Reports ..............30 6.11 Refining the System ..........33 SECTION 7: Replacement Parts .......... 34 7.1 VIRTUAL WALL™ Controller Replacement Parts ..35 ™ SECTION 8: The VIRTUAL WALL Controller Limited Warranty............36 ©...

  • Page 5: Section 1: Introduction

    1.2 California Proposition 65 In accordance with California Proposition 65 require- The VIRTUAL WALL™ Controller series of control- ments, a warning label must be placed in a highly lers are supplied pre-configured for use with Speci- visible location on the outside of the equipment (i.e.,...
  • Page 6 VIRTUAL WALL™ C ONTROLLER NSTALLATION ANUAL FIGURE 1: Connected Components...

  • Page 7: Carton Contents

    SECTION 1: I NTRODUCTION 1.6 Carton Contents VWCCPXX: VIRTUAL WALL™ Controller Central Controller VIRTUAL WALL™ Controller VIRTUAL WALL™ Controller Installation Manual (P/N 1010100NA) POWER IN 120V 60HZ 1Ø 20A Power Without Keypad: 24Vac 24Vac, 50VA 2A, 50-60 Hz Port 1 Tx 26Vdc 26Vdc, 23W, 0.9A...
  • Page 8 VIRTUAL WALL™ C ONTROLLER NSTALLATION ANUAL FIGURE 2: Example Site Layout NOTE: Conceptual drawing, not to scale. Venting not shown.

  • Page 9: Section 2: Specifications

    SECTION 2: S PECIFICATIONS SECTION 2: SPECIFICATIONS or 4-wire). Network protocol selectable for BACnet (MS/TP or PTP), Modbus, N2, LonWorks SLTA, or 2.1 VIRTUAL WALL ™ Controller modem. 2.1.1 Standard Enclosure Rnet port: Interface with a BACview5, BACview6, RS Construction: 16 gauge painted steel, hinged sensors, ZS sensors or local laptop.
  • Page 10 VIRTUAL WALL™ C ONTROLLER NSTALLATION ANUAL FIGURE 3: VIRTUAL WALL ™ Controller Specifications...

  • Page 11: Section 3: Installation

    3.2.1 Choose a mounting location for the controller. One twisted pair of 22 AWG minimum or equivalent The Virtual Wall controller may lie at any node along shielded high speed, low capacitance cable. Maxi- the MS/TP daisy chain. For serviceability, it is conve- mum network length: 4000' (1219 m) at 19.2K Baud...

  • Page 12: Electrical Installation Requirements Of Virtual Wall™ Controller

    Controller must be properly grounded to an electrical source. Failure to follow these instructions can result in death or electrical shock. • VIRTUAL WALL™ Controller must be feeding from a local fused isolator for a total amperage not exceed- ing 20A.

  • Page 13: Section 4: Wiring Diagram

    SECTION 4: W IRING IAGRAM SECTION 4: WIRING DIAGRAM DANGER Electrical Shock Hazard Disconnect electric before service. Controller must be properly grounded to an electrical source. Failure to follow these instructions can result in death or electrical shock.
  • Page 14 VIRTUAL WALL™ C ONTROLLER NSTALLATION ANUAL FIGURE 4: VIRTUAL WALL™ Controller Wiring Diagram...

  • Page 15: Section 5: Communications

    The Virtual Wall Con- troller acts as the IP connection point to the local net- work.See Section 6 for WebCTRL® details.

  • Page 16: Setting Baud Rate

    VIRTUAL WALL™ C ONTROLLER NSTALLATION ANUAL FIGURE 5: MS/TP Communications Between Controllers Power Without Keypad: Power Without Keypad: 24Vac 24Vac, 50VA 24Vac 24Vac, 50VA Port 1 Tx Port 1 Tx 2A, 50-60 Hz 2A, 50-60 Hz 26Vdc 26Vdc 26Vdc, 23W, 0.9A Port 1 Rx 26Vdc, 23W, 0.9A...
  • Page 17 SECTION 5: C OMMUNICATIONS used, 76.8 K, a REPEATER is required after 2000 ft (609 m) and terminating resistors put in line. Set switch 4 to OFF and switch 5 to ON for 19.2K. DIP switch set up is complete. Only switch 5 should be ON.
  • Page 18 The repeater can also be used to install in different methods: • To extend communications beyond the standard 4000' (1219 m) limitation. See Page 14, Figure 7. • To add parallel branches of VIRTUAL WALL ™ Controller communications bus wiring.

  • Page 19: Sequence Of Operations

    5.5 Sequence of Operations All control equipment shall operate in stand-alone mode according to its sequence of operation in the absence of the Virtual Wall Controller. Occupancy WebCTRL® shall centrally coordinate the monitoring and control of all equipment. WebCTRL® allows the user to create plant wide schedules, trend graphs, and reports as well as adjust heating setpoints, pressure control, cooling and more.
  • Page 20 VIRTUAL WALL™ C ONTROLLER NSTALLATION ANUAL IRH and OAHU Setpoint Coordination The IRH shall maintain the space temperature heating setpoint (occupied and unoccupied) according to its sequence of operations as performed by the IRH controller. Should the IRH be operating at 100% capacity and not be able to achieve or maintain the space temperature heating setpoint after the prescribed adjustable runtime (15 min), the discharge air temperature setpoint of the OAHU shall be raised to supplement the heating capacity of the IRH system.

  • Page 21: Section 6: Webctrl

    Password: admin 6.1 Touchscreen Gestures When using the Virtual Wall touchscreen, certain gestures are required to replace keyboard functionality. The use of a stylus is recommended. A virtual keyboard can be brought up by clicking in a desired field you wish to type in. A keyboard icon will appear.

  • Page 22: Graphics

    A custom, interactive plant layout graphic is included with the Virtual Wall system. This graphic displays the comfort level within each zone of the plant as well as a link to specific area graphics. Color coding of zones is relative to the setpoint; therefore, multiple regions of the same color may be different temperatures.

  • Page 23: Managing Connections

    The View and Configure tabs are used for managing connections. To set up a new connection select Add under the Configure tab. For the Virtual Wall, a new BACnet/IP con- nection is required. Select this as the type and input the Server IP Address and Server IP Subnet Mask.

  • Page 24: Miscellaneous Actions

    6.5.2 Global Modify The number of programs to manage within the Virtual Wall system can be quite large. Instead of going into each program to modify the same parameter, global modify is a tool which allows the user to modify a pro- gram's parameter across all instances of that program.

  • Page 25: User Login & Operator Access

    SECTION 6: W CTRL® Click Find All. In this example, WebCTRL® finds instances of this parameter across all zone 1 programs. Enter each New Value individually if different values are desired or enter one value at the bottom and click Set All To. Apply Changes before closing the window.

  • Page 26: Scheduling

    VIRTUAL WALL™ C ONTROLLER NSTALLATION ANUAL edit settings later). Fill in the login information, and Personal Information if desired. Select a Privilege Set for the operator and Accept when finished. 6.6.1 Creating Privilege Sets Creating custom privilege sets is a useful tool when many operators of various positions want access to WebCTRL®.
  • Page 27 SECTION 6: W CTRL® Click Add to create new schedule and more options appear below. Select a Priority and Type, then fill in all appropriate fields. To finish, click Accept at the top of the screen. The schedule has been added to all areas beneath the top level system. 6.7.1 Modify Schedules To Add/Modify schedules for specific areas, select area in Geographic tree, then Schedules and Configure tab.
  • Page 28 VIRTUAL WALL™ C ONTROLLER NSTALLATION ANUAL Supplementing the Plant Wide Schedule For areas which are occupied beyond the plant wide schedule, add additional Normal priority schedules. Overlapping Normal priority schedules result in occupied time beginning and ending at the most extreme values from either one.

  • Page 29: Trending

    SECTION 6: W CTRL® 6.8 Trending The WebCTRL® system can read and store data from equipment over time and display this information in a trend graph for monitoring purposes. Trend data can be collected from many points within the equipment. Data is initially stored within the controller itself, however, the controller has limited memory.
  • Page 30 VIRTUAL WALL™ C ONTROLLER NSTALLATION ANUAL 6.8.1 Creating a Custom Trend Graph A custom trend graph can be created for individual pieces of equipment, areas, etc. In the Geographic tree, select the area or equipment where you wish to see the graph. On the Trends action button click the dropdown menu and New Trend Graph.
  • Page 31 SECTION 6: W CTRL® For each parameter under Points, the tree beneath shows the associated object. Organize trends points and subgraphs as desired. It is helpful to group like points on subgraphs such as: Zones 1 - 4 temperatures on one subgraph, Zones 1 - 4 Burner on/off status on another.
  • Page 32 Navigate to the local C drive and find the WebCTRL_for_OEMs_XX folder. Then, webroot  database name (i.e. Virtual Wall)  databases (at the top)  trend  log Right click the log folder  properties. This should display the size of the folder. If it is desired to store data for longer periods of time (i.e.

  • Page 33: Alarms

    SECTION 6: W CTRL® 6.9 Alarms An alarm is a message sent from the controller to the WebCTRL® application to notify the user that certain conditions exist, such as a piece of equipment has stopped running or a temperature is too low. Information about the alarm is displayed on the Alarms button.

  • Page 34: Reports

    VIRTUAL WALL™ C ONTROLLER NSTALLATION ANUAL Acknowledge Alarms Acknowledge alarms that have been set up to require acknowledgment. The alarm indicates when acknowledgment is necessary. Further action after acknowledgment may be necessary to clear alarm. The table in the upper left corner shows how many alarms need acknowledgment at the current location (Here) and the entire system (Total).
  • Page 35 SECTION 6: W CTRL® 6.10.1 Creating an Equipment Summary Report This report can provide information on zone color, active alarms, locked values, current value of selected points, and effective schedule. The report is created for equipment at or below the location selected in the Geographic or Network trees.
  • Page 36 VIRTUAL WALL™ C ONTROLLER NSTALLATION ANUAL 6.10.3 Trend Usage Report A Trend Usage Report is a helpful tool to analyze setup and history of trending points throughout the system. To run this report, first select the system, area or equipment within the Geographic tree. Within the drop-down menu for Reports select Equipment, then Trend Usage.

  • Page 37: Refining The System

    The most important concept of the Virtual Wall is 'comfort where you need it'. This is an energy saving technique which keeps unoccupied spaces at a lower temperature than occupied areas. This implies using Roberts Gordon Infrared Equipment only when and where necessary.

  • Page 38: Section 7: Replacement Parts

    VIRTUAL WALL™ C ONTROLLER NSTALLATION ANUAL SECTION 7: REPLACEMENT PARTS WARNING DANGER Electrical Shock Hazard Explosion Hazard Carbon Monoxide Hazard Fire Hazard Use only genuine ROBERTS GORDON ® replacement parts per this installation, operation and service manual. Failure to follow these instructions can result in death, electric shock, injury or property damage.

  • Page 39: Virtual Wall™ Controller Replacement Parts

    SECTION 7: R EPLACEMENT ARTS 7.1 VIRTUAL WALL™ Controller Controller Replacement Parts Caution: Use only genuine SPECIFIED AIR SOLUTIONS ™ replacement parts. Use of parts not specified by Roberts-Gordon voids warranty. FIGURE 9: VIRTUAL WALL™ Controller Controller Components Description Part Number...

  • Page 40: Section 8: The Virtual Wall

    Parts or have additional questions, call or write: Specified Air Solutions will require the part in question to Specified Air Solutions be returned to the factory. Specified Air Solutions will, at its 1250 William Street sole discretion, repair or replace after determining the nature of the defect and disposition of part in question.
