Installation and Maintenance Instructions
Saf-T Liner
®
Stainless Steel Chimney Liner
Heat-Fab Inc. Saf-T Vent®
Stainless Steel Chimney Liner
Sizes: 4", 5", 6", 7", 8" Diameters
9", 10", 12", 14" Available
130 Industrial Boulevard
Turners Falls, MA 01376
Call (800) 772-0739
Fax (413) 863-4803
www.heat-fab.com
Advertisement
Summary of Contents for Heat-Fab Saf-T Liner
- Page 1 Installation and Maintenance Instructions Saf-T Liner ® Stainless Steel Chimney Liner Heat-Fab Inc. Saf-T Vent® Stainless Steel Chimney Liner Sizes: 4", 5", 6", 7", 8" Diameters 9", 10", 12", 14" Available 130 Industrial Boulevard Turners Falls, MA 01376 Call (800) 772-0739 Fax (413) 863-4803 www.heat-fab.com...
- Page 2 Saf-T Liner is a high quality U.L. tested and Listed stainless steel lining system designed for relining existing masonry chimneys. It satisfies code requirements as a substitute for 5/8" fireclay liners and has undergone extensive testing to make it the leader in the stainless steel chimney lining industry.
- Page 3 Hearth/Fireplace Insert Stove If installing a hearth or fireplace insert stove using an existing fireplace chimney, the length of rigid Saf-T Liner required will be the distance from the chimney top to the top of the smoke chamber. Listed stainless steel Chimney Liner components, an engineered Direct Connect Assembly or any other method approved by the local building authority will be required to pass through the smoke chamber/damper area to the appliance flue collar.
- Page 4 Saf-T Wrap is available in tee sections and 24" lengths, therefore two lengths will be required for each 4' section of Saf-T Liner. Saf-T Wrap must cover the Saf-T Liner from the appliance tee or the top of the smoke chamber area to within 8"...
- Page 5 INSTALLING YOUR SAF-T LINER AND SAF-T WRAP INSULATION CAUTION must be used when working on a roof. Proper and safe scaffolding should be used for a safe installation of the Saf-T Liner. Always use a respirator and eye protection when using Saf-T Wrap. Non-Fireplace Chimney...
-
Page 6: Installing The Appliance
Place the coverplate on the top of the masonry chimney to create a dead air space around the Saf-T Liner system. Trim the cover plate to 4" larger than the outside of the chimney. Using tin snips, notch each corner 2" and fold each corner under 90 degress. -
Page 7: Chimney Maintenance
Saf-T Liner Stainless Steel Chimney Liner Limited Warranty Heat-Fab, Inc. warrants to the original consumer purchaser that the Type 304 Saf-T Liner will be free from defects in material or manufacturer’s workmanship when properly installed with Saf-T Wrap insulation pursuant to these manufacturer’s... - Page 8 ATTENTION HOMEOWNER FOLLOW THESE CHIMNEY MAINTENANCE INSTRUCTIONS: The chimney connector and Saf-T Liner should be inspected frequently during the heating season and cleaned annually (more often if necessary) by a professional, certified chimney sweep. The chimney should be inspected at least every 6 to 8 weeks during the heating season and once prior to the season to determine if (1) a creosote or soot buildup has occured or (2) if some other mechanism has caused a failure of the liner system.
