Mr. Drive In Complete Outdoor Home Theater User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Parts List:
Item
1
Projector
2
Adaptor for projector
3
Remote Control
4
Bluetooth speaker
5
USB wire for charging Bluetooth speaker
6
Audio wire for Bluetooth speaker
7
Screen
8
Bungie Cord
9
Stake
Made in China
User Manual
Description
Qty
Item
1
10
Strings with Hooks
1
11
Carrying Case
1
12
Pole A
1
13
Pole B
1
14
Pole C
1
15
Pole D
1
16
Mouse
6
4
Description
Page 1 of 15
Qty
4
1
4
2
2
1
1
