Table of Contents Principle of Receiver Operation __________________________________________ 4 Principle of Controller Operation ________________________________________ 4 Description of Controls _________________________________________________ 6 Installing the LoPro Receiver ____________________________________________ 7 Filter Cleaning or Replacement __________________________________________ 9 MCP & 3 Party Pump _________________________________________________10 Wiring Diagrams _____________________________________________________ 11...
Page 3
The information contained within this manual including any translations thereof, is the property of Maguire Products Inc. and may not be reproduced, or transmitted in any form or by any means without the express written consent of Maguire Products Inc.
A unique feature of this LoPro unit is the vertical height. While many other material loaders and receivers can protrude 2 to 3 feet out the top of a hopper lid, the LoPro stands only 7-5/8” (193 mm) out of a hopper lid. Despite its low clearance, it maintains a respectable capacity.
Page 5
An operator can adjust this as many times as they feel necessary. Operational Modes Out of the box, the Lopro receiver is set to run anytime a demand signal is present. This demand signal is determined by the hanging position of the dump flap. For conveying applications where material may not always available (such as regrind), the operator may want to set the receiver to one of the 4 additional non-continuous, or “regrind”...
The status indicator will provide information about the LoPro during standard operation. This can be a useful tool for troubleshooting. At any point when the LoPro is turned on, the status indicator should be displaying 1 of 4 conditions. The following list describes each, and explains what each one means: •...
3. Install 5/32” (4 mm) air line into the fitting and connect to clean, dry 80 psi (5.5 bar) compressed air supply. DO NOT apply direct air pressure to the LoPro fitting. Damage or an air leak could result. A compressed air filter (sold separately) is recommended for protection of pneumatic components.
2) Disconnect the material line, signal cable, and compressed air. 3) Release spring latches, and remove controller portion. 4) Remove / replace filter (Maguire part #: ashffd4). Dome side of filter facing toward the material portion. 5) When reinstalling the controller portion of the receiver, make sure that the material inlet is lined up and slides in smoothly into the respective grommet.
Page 9
P R O D U C T S , I N C . Accessing electronics, valves for service To access the electronics of the Lopro receiver, remove the (7) sheetmetal screws holding in the front panel. Remove only the front panel. Replacement Parts:...
MCP Pump & 3 Party Control Options Maguire MCP The MCP pump is a simple, compact vacuum system specifically designed for LoPro recieivers systems. Features a brushless motor which last 4 to 5 times as • long as equivalent motors with brushes.
