4CH / 8CH DVR
Quick Start Guide
1. Packing.............................................P.2
2. Front Panel Controls......................P.3
3. Rear Panel Connectors..................P.4
GPL
This product contains codes which are developed by
Third-Party-Companies and which are subject to the GNU Public
License("GPL") or the GNU Lesser Public License("LGPL"). The GPL
Code used in this product is released without warranty and is subject
to the copyright of the corresponding author. Further source codes
which are subject to the GPL-licenses are available upon request. We
provide our modifications to the Linux Kernel, as well as new
commands, and tools to get you into the code. The codes are provided
on the FTP site, and please download them from the following site or
you can refer to your distributor:
FTP site ：http://icatch.azurewebsites.net/GPL/
If you need more GPL source code, please contact us via email.
tech.support@icatchinc.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Masial 8CH
-
Page 1: Quick Start Guide
4CH / 8CH DVR Quick Start Guide 1. Packing..........P.2 2. Front Panel Controls......P.3 3. Rear Panel Connectors....P.4 This product contains codes which are developed by Third-Party-Companies and which are subject to the GNU Public License(“GPL”) or the GNU Lesser Public License(“LGPL”). The GPL Code used in this product is released without warranty and is subject to the copyright of the corresponding author. - Page 2 PACKING 1. DVR 2. Screws 3. Power Adapter 4. SATA Cord 5. Mouse/ Remote Controller Quick Start Guide P.2...
-
Page 3: Front Panel Controls
FRONT PANEL CONTROLS ① ② ③ ④ ⑤ USB port 1. USB port Power is on. 2. Power LED Hard disk is in use. 3. HDD LED Connected to the internet. 4. LAN LED Recording. 5. Record LED Quick Start Guide P.3... -
Page 4: Rear Panel Controls
REAR PANEL CONTROLS 4CH REAR PANEL CONNECTORS ⑧ ⑨ ⑩ ① ④ ⑤ ⑥ ⑦ ② ③ 1. VIDEO IN BNC input ports. 2. A-OUT RCA output port. 3. HD-OUT HDMI port. 4. AUDIO IN RCA input port. USB port. 5. -
Page 5: 8Ch Rear Panel Connectors
8CH REAR PANEL CONNECTORS ⑧ ⑩ ⑨ ① ② ③ ④ ⑤ ⑥ ⑦ 1. VIDEO IN BNC input ports. 2. A-OUT RCA output port. 3. HD-OUT HDMI port. 4. AUDIO IN RCA input port. 5. USB USB port. 6. RS-485 RS-485 port.
