ini-Mod
Semi-Automatic Induction
Casting Machine
The Mini-Mod induction casting machine is used for casting partial frameworks
as well as crown and bridge. It has a self-contained air-cooling system that
enables continuous casting and does not require a water supply. The low
power rating makes it highly efficient, thus it is designed to run on a standard
20 amp, 110 volt circuit. Uses medium-frequency induction heating system.
•
Adjustable cradle for various ring sizes
•
Melts 30 grams in less than 1 minute
•
Variable power settings
•
Portable, on wheels
•
Safety features built-in:
•
Cover Safety Switch
•
Eye shield
•
CE rated
Specifications
Description: Semi-Auto. Casting Machine
Part #: 2008M
Electrical: 110/120 Volt, 50/60 Hz
Height: 37" (93 cm)
Width: 21" (52 cm)
Depth: 21" (52 cm)
Weight: 265 Lbs (120 Kg)
Shipping Weight: 286 Lbs (130 Kg)
TM
Compact Air Cooled
Centrifugal Casting
N O B I L I U M
T M
T M
NOBILIUM
Owner's Manual
TM
TM
Advertisement
Summary of Contents for CMP Mini-Mod 2008M
- Page 1 ini-Mod Compact Air Cooled Centrifugal Casting Semi-Automatic Induction Casting Machine The Mini-Mod induction casting machine is used for casting partial frameworks as well as crown and bridge. It has a self-contained air-cooling system that enables continuous casting and does not require a water supply. The low power rating makes it highly efficient, thus it is designed to run on a standard 20 amp, 110 volt circuit.
- Page 2 Equipment. It has been carefully quality-controlled and thoroughly tested for optimum performance and durability. If you have any questions regarding CMP’s quality line of dental laboratory equipment and supplies, please call toll-free: 800-833-2343 or 518-434-3147 (Fax: 518-434-1288) between the hours of 8:00 AM and 4:30 PM Eastern Time.
-
Page 3: Receiving And Unpacking
Identify the age claim procedure. After and only after the problem (voltage too high, too much metal carrier has been notified, should CMP in crucible, etc.) and try again. Industries be notified. If no damage has been found, proceed to remove your Mini- 5. - Page 4 1. Machine plugged into the proper recepta- 1. Turn the power switch “On” (“I”). cle. When the machine is receiving current 2. Choose the correct voltage by adjusting the red indicator light is lit (Figure __). the Voltage Selector according to the 2.
-
Page 5: Troubleshooting
Troubleshooting Fan works normally Cause If a problem occurs, follow Set-Up steps to identify and analyze the problem. Do not 1. The AC voltmeter is damaged or there is use the machine until the Set-Up steps are connections problem. successful. Solutions Problem Connect the power switch DK, AC... - Page 6 Troubleshooting (Continued) Solutions 1. Find out the return circuit connections of Solutions the melt operation and tighten them. 1. Measure C2, C11 using a multimeter while 2. Find out and replace the damaged parts. the power is off, find out and replace the broken capacitor.
- Page 7 Troubleshooting (Continued) Problem After press the Melt Button, there is DC Voltage but no DC current, RDA is melted. Cause Cause 1. Poor contacts caused by the loosening of the screws in the electrodes. 1. The power transistor or the reverse diode is damaged.
- Page 8 3/4 View of Mini-Mod ITEM & DESCRIPTION Cover Site Glass Voltage selector Knob...
- Page 9 Generator Board...
- Page 10 Inside View Right Panel ITEM & DESCRIPTION Fuse Fuse Fuse Main Power Relay Melt Relay Spin Relay...
-
Page 11: Inside View
Inside View ITEM & DESCRIPTION Crucible Holding Plate Crucible Casting Arm Locking Arm Counter Balance Cradle Adjust Locking Knob Adjusment Arm Spring Clip to Electrode Air Blower Vent... - Page 12 N O B I L I U M NOBILIUM 413 North Pearl Street • Albany, New York • 12207 • Toll-Free: 800 833-2343 • USA: 518 434-3147 • Fax: 518 434-1288 USA Email: info@cmpindustries.com • Export Email: export@cmpindustries.com Website: www.cmpindustries.com Form 40811...
