LG-Ericsson ACT-50 Quick Install Manual

ACT-50 IP Audio Conference System
Quick Install Guide

Connections to ACT-50

Connect the Ethernet cable to RJ-45 LAN port and your Ethernet switch.
•
Connect the AC/DC power adaptor to DC input port and a standard AC power outlet.
•
(optional) RJ-11 port (Connection to a KTS/PBX analog phone line for analog phone
•
call when IP network is down)
(optional) TRS 3.5 mm stereo port (Connection to audio port on a PC; This allows
•
ACT-50 to work as speaker phone for softphone.)
*** Connect 3.5 mm stereo audio cable to AUDIO IN and PC headset port.
*** Connect 3.5 mm stereo audio cable to AUDIO OUT and PC MIC port.
Set up IP address for static IP address (*DHCP is default)
1. Press "Menu" (▼) key
and press "Enter" (
2. Select "1. Network Settings" menu and press "Enter" key
press "Enter" key
3. Select "2. IP Address" menu and press "Enter"
address and press "Enter" key.
4. Select "3. Subnet Mask" menu and press "Enter" key
subnet mask and press "Enter" key.
5. Select "4. Default Gateway" menu and press "Enter" key
default gateway and press "Enter" key.
6. Select "5. DNS Server" menu and press "Enter" key
server and press "Enter" key.
[Note] The IP address of ACT-50 must avoid the "system IP address range" of iPECS LIK
system. Please ask network administrator for proper IP address.

Setup SIP server

1. Use any Web browser and enter ACT-50's IP address in following format:
http://xxx.xxx.xxx.xxx
2. Click SIP Server "Enable" radio button to activate SIP mode.
3. Type SIP server IP address or SIP server name in "SIP Server Name" line.
4. Type SIP server IP address or SIP server name in second field of "SIP Address" line.
5. Type username or SIP account name in "SIP Unit ID" line and first field of "SIP Address"
line.
Press "Down" (▼) / "Up" (▲) key to select "1. Settings" menu
) key.
Select "2. Disable" menu and press "Enter" key.
Select "1. DHCP" menu and
Press numeric keys to enter IP
Press numeric keys to enter
Press numeric keys to enter
Press numeric keys to enter DNS
