Summary of Contents for Adwa Instruments AD1030
- Page 1 USER MANUAL AD1030, AD1040, AD1200 pH /mV/ISE/Temperature Bench Meters ADWA INSTRUMENTS Kft. Alsókikötõ sor 11, 6726 Szeged, Hungary Tel. +36 62 317 878 Fax +36 62 550 610 e-mail: sales@adwainstruments.com www.adwainstruments.com w w w . a d w a i n s t r u m e n t s . c o m...
- Page 2 Dear Customer, Thank you for choosing an Adwa product. Please read carefully this manual before starting operations. This instrument is in compliance with the EMC Directive 89/336/EEC and Low Voltage Directive 73/23/EEC for electrical equipments. For additional technical information, please e-mail us at sales@adwainstruments.com.
-
Page 3: Table Of Contents
WARRANTY TABLE OF CONTENTS Adwa warrants this product to be free of defects in Introduction ............4 material and workmanship as stated in the operating Technical Data ............. 6 manual. If repair or adjustment is necessary and has Front and Rear Panels .......... 8 not been the result of abuse, misuse or improper han- dling within the warranty period, please contact your Operational Guide ..........13... -
Page 4: Introduction
• HOLD feature to freeze the stable reading on the • GLP feature (not for AD1030) to view last calibra- tion data for pH, ISE and relative mV ranges... - Page 5 TROUBLESHOOTING GUIDE Each model is supplied complete with: SYMPTOM PROBLEM SOLUTION • A1131B refillable pH electrode with glass body, Slow response/ Dirty pH Soak the electrode BNC connector and 1 m cable excessive drift. electrode. tip in deionized water for 30 min. •...
-
Page 6: Technical Data
TECHNICAL DATA ELECTRODES, PROBES AND SOLUTIONS A1131B Refillable pH electrode with glass body, Range -2.00 to 16.00 pH / -2.000 to 16.000 pH tip protection bottle, BNC connector ±2000 mV and 1 m cable 0.001 to 19999 ppm (AD1200 only) A1230B pH electrode with Epoxy body, tip pro- - 20.0 to 120.0°C (- 4.0 to 248.0°F) - Page 7 Refill the electrode reference chamber with fresh A7071S electrolyte solution. Allow the electrode to stand upright for 1 hour. Follow the storage procedure above. pH Calibration Up to 3 point calibration, with 2 custom and 7 standard buffers CLEANING PROCEDURE (pH 1.68, 4.01, 6.86, 7.01, 9.18, 10.01, 12.45) Soak in deionized water for approximately 30 minutes.
-
Page 8: Front And Rear Panels
FRONT AND REAR PANELS For refillable electrodes: If the filling solution (electrolyte) is more than 2.5 cm Keyboard for AD1030 below the fill hole, add A7071S electrolyte solution. For faster response, unscrew the fill hole screw during measurements. STORAGE PROCEDURE... - Page 9 pH ELECTRODE CONDITIONING & 5. Up arrow key, to manually increase temperature value or other parameters MAINTENANCE 6. CLEAR key, to clear calibration data 7. RANGE key, to select measurement unit or switch focused data 8. SHIFT key, to activate the second function key 9.
- Page 10 Keyboard for AD1040 and AD1200 ANALOG OUTPUT For the full range of each measurement, the analog out- put varies from - 2000 to 2000 mV. 1. HOLD key, to freeze the stable reading on the LCD 2. Numerical keys only 3.
- Page 11 • Set the simulator to 600.0 mV. When the reading is 5. Up arrow key, to manually increase temperature stable and close to the selected calibration point, the value or other parameters CFM tag starts blinking. 6. CLEAR key, to clear calibration data 7.
- Page 12 Front Panel mV CALIBRATION (for technical personnel only) The instruments are factory calibrated for mV range. Adwa’s ORP electrodes are interchangeable and no mV calibration is needed when they are replaced. If measurements are not accurate, a mV recalibration should be performed. For an accurate recalibration, contact your dealer or the nearest Adwa Customer Service Center, or follow the instructions below.
-
Page 13: Operational Guide
• Press CFM to confirm. The instrument OPERATIONAL GUIDE returns to normal measurement mode. CONNECTIONS Note: If the reading is not close to the selected cali- bration point, the WRONG tag will blink. Change the temperature probe and restart calibration. •... - Page 14 INSTRUMENT START-UP • Immerse the temperature probe into the vessel with ice and water as close as possible to the reference Turn the instrument on by pressing the ON/OFF button. thermometer. Allow a few seconds for probe thermal All LCD tags are displayed and a beep is heard (if beep stabilization.
- Page 15 TEMPERATURE CALIBRATION • Immerse pH electrode tip and tempera- ture probe approximately 4 cm into the (for technical personnel only) solution to be tested. Allow for the elec- The instruments are factory calibrated for temperature. trode to stabilize and put the tempera- Adwa’s temperature probes are interchangeable and no ture probe tip as close as possible to the temperature calibration is needed when they are replaced.
- Page 16 To use the ATC (Automatic Temperature Compensa- HOLD tion) capability of the instrument, connect the A7662 To freeze a stable reading on the LCD, press HOLD temperature probe, immerse it into the sample as close key from normal measurement mode. as possible to the pH electrode and wait for a few The “Auto”...
- Page 17 Note: Pressing SHIFT and then SETUP key, the in- ORP (mV) MEASUREMENTS strument toggles between lot and record num- Oxidation-reduction potential (REDOX) measurements ber or all lots. provide the quantification of the oxidizing or reducing • Press CLEAR to delete the selected lot/record or all power of the tested sample.
- Page 18 RELATIVE mV MEASUREMENTS Press RANGE or right arrow key to scroll all logged parameters, displayed as shown in the table below: To enter relative mV mode, press RANGE. The relative mV reading will be displayed on the primary LCD and the current temperature value on the secondary LCD.
- Page 19 VIEWING LOGGED DATA ISE MEASUREMENTS (AD1200 only) To retrieve the information stored, press MEMRCL from To measure the ion concentration, enter measurement mode. If no data were logged, the “no rEC” the ISE mode by pressing RANGE. message blinks on the LCD. •...
-
Page 20: Ph Calibration
pH CALIBRATION If there are less than 6 memory locations left, the record number and the “Lo” message will blink for a few sec- The instrument should be recalibrated: onds to alert the user, and then the number of free loca- •... - Page 21 LOG-ON-DEMAND (AD1040 and AD1200) PROCEDURE If 0.001 pH resolution is selected, each selected stan- This feature allows the user to log pH, ISE (AD1200 dard buffer value can be updated accordingly with the only) and Rel mV measurements, together with tem- value of the production lot certificate at 25°C (77°F).
- Page 22 A new calibration will override existing stored calibra- • If both alarm items are set, the instrument will beep tion data. The slopes adjacent to the calibration points when the reading is above alarm high limit or below will be reevaluated. alarm low threshold.
- Page 23 ALARM SETUP THREE-POINT CALIBRATION • Select one of the alarm items. The displayed value • Immerse the pH electrode and the tem- will be the one previously set. perature probe approximately 4 cm into a buffer solution of your choice (pH •...
- Page 24 • The hourglass tag will blink on the LCD until the read- Notes: ing is stable. • The custom buffers can be set only with 0.001 • When the reading is stable and close to resolution. If 0.01 pH resolution is selected dur- the selected buffer, the CFM tag ap- ing calibration, the displayed custom buffer value pears.
- Page 25 The table below lists all available setup parameters, their • When the reading is stable and close to the selected valid values and the factory settings (default). buffer, “CFM” tag appears. • Press CFM key to confirm. The cali- brated value is then displayed on the Item Description Valid values...
- Page 26 TWO-POINT CALIBRATION • Use the arrow keys to scroll the available values or insert the desired value with the numerical keys. Proceed as described in the “Three-point calibration” section and press CAL after the second calibration point Note: To activate the numerical keys, press NUM is accepted.
- Page 27 SETUP • Each time a buffer is confirmed, the new calibration parameters replace the old data of the corresponding Setup mode allows viewing and modifying the following buffer. parameters: • If current confirmed buffer has no correspondence in • Calibration time-out alarm the stored calibration, it will be added to the existing •...
-
Page 28: Relative Mv Calibration
CUSTOM BUFFERS Use the up arrow key to view all logged calibration pa- rameters in the following sequence: If at least one custom buffer was set in SETUP menu, it can be selected for calibration using the arrow keys. • Relative mV calibration offset and time (hh:mm) as in Press SHIFT and then SETUP key if you want to adjust pH GLP mode. - Page 29 • Second ISE calibration buffer on the primary LCD CLEAR CALIBRATION and corresponding mV value on the secondary LCD. If the CLEAR key is pressed at any time during calibration, the “CLEAR CAL” tag lights up and the “donE” message is displayed on the secondary LCD. All previous calibrations are cleared and the instrument continues the procedure.
- Page 30 • Press NUM LOCK again to leave the numeri- LAST ISE CALIBRATION DATA (AD 1200 only) cal keys. Last ISE calibration data are stored automatically after • When the reading is stable and the relative mV offset a successful calibration. is within the offset window (±2000 mV), the CFM tag To view the ISE calibration data, from ISE measure- will be displayed.
- Page 31 Notes: PREPARATION • The “OLd” message displayed beside a buffer • Set the proper ion charge through the setup item value means that this buffer was not used dur- “IonCG”. ing last calibration. Press SHIFT and then Note: If the “undF” option is selected in setup menu, SETUP key to see the old calibration date (or the calibration must be a two-point procedure.
- Page 32 TWO-POINT CALIBRATION • pH calibration offset value. • Immerse the ISE electrode approxi- mately 4 cm into the first standard so- lution and stir gently. • Press CAL key. The primary LCD will display the ppm value using current off- set and slope.
- Page 33 LAST pH CALIBRATION DATA • Press CFM to confirm calibration. The last pH calibration data are stored automatically after • The calibrated value will be displayed a successful calibration. on the primary LCD and the second expected standard solution on the sec- To view the pH calibration data, from pH measurement ondary LCD.
-
Page 34: Good Laboratory Practice
Notes: ONE-POINT CALIBRATION • If the mV value is out of the ±2000 mV range, • To perform a single point calibration, the “WRONG” and “BUFFER” tags are dis- press CAL after the first calibration played. Check if the correct standard has been point has been confirmed.
