MERYTRONIC ARIADNA ILF-12 User Manual

Phase and feeder identifier
Hide thumbs
Table of Contents

Advertisement

Quick Links

ARIADNA ILF-12
PHASE AND FEEDER
IDENTIFIER
USER GUIDE
V 3.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ARIADNA ILF-12 and is the answer not in the manual?

Questions and answers

Summary of Contents for MERYTRONIC ARIADNA ILF-12

  • Page 1 ARIADNA ILF-12 PHASE AND FEEDER IDENTIFIER USER GUIDE V 3.0...

  • Page 2: Table Of Contents

    INDEX 1. SYSTEM DESCRIPTION ......................6 1.1. COMMUNICATION BETWEEN CD AND LD IN AUTOMATIC MODE ......7 2. EQUIPMENT CONTENTS ...................... 8 3. DEVICE DESCRIPTION ......................9 3.1. CENTRAL DEVICE CD ....................9 3.2. LINE DEVICE LD ......................10 4. CENTRAL DEVICE (CD) EQUIPMENT CONNECTION ............11 4.1.
  • Page 3 4.2.1.3. STEP THREE: SELECT WORKING MODE, AUTO-FF OR MAN-FF MODES ... 25 5. LINE DEVICE (LD) CONNECTION ..................30 5.1. PHASE TO NEUTRAL NETWORK POINTS (STAR, B1 WITH NEUTRAL OR B2): ..30 5.2. PHASE TO PHASE NETWORK POINTS (DELTA OR STAR B1 WITH NO NEUTRAL AVAILABLE): ..........................
  • Page 4 Safety information, read these indications first: Used symbols: Earth terminal Caution, check the user guide explanation European conformity Supply cable connection to mains is OK Error on supply cable connection to mains CAT III measurement category: makes reference to the distribution level and permanent circuits inside a building Ariadna Network Identifiers meet European Low Voltage Directive 72/23/CEE and are compliant with:...
  • Page 5  Avoid working alone  Do not use the equipment in gas or explosive vapor areas.  Before using the equipment check cables and coils to see if there is any mechanical damage; if so replace them. Try to locate breaks or missing plastic components.

  • Page 6: System Description

    1. SYSTEM DESCRIPTION The purpose of this equipment is to achieve the maximum possible information regarding the low voltage network topology. This means knowing the connectivity of each accessible point of the LV network. In this document connectivity is defined as the existing connection relationship between a network point that is being analyzed, and the MV/LV transformer substation, feeder and phase that feeds it.

  • Page 7: Communication Between Cd And Ld In Automatic Mode

    1.1. Communication between CD and LD in Automatic Mode INFORMATION INFORMATION CD injects phase and CD If the network point where the LD is After receiving receives this signal number identification connected to belongs to the same phase through the sensor ring that signals through each...

  • Page 8: Equipment Contents

    2. EQUIPMENT CONTENTS Ariadna ILF12 equipment consists of: CD: Central Device that can identify up to 3 phases and 12 feeders 12 Sensor Rings (Rogowski Coils) 5 core supply cable to connect the CD to the transformer LV busbar LD: Line Device (UL-220) with graphic display. LD soft case Two cables, red (phase) and blue (neutral) to connect the device to the network points to be analyzed.

  • Page 9: Device Description

    3. DEVICE DESCRIPTION 3.1. Central Device CD Power ON Power OFF UC Number Selection Automatic / Manual mode selection UC restart...

  • Page 10: Line Device Ld

    3.2. Line Device LD...

  • Page 11: Central Device (Cd) Equipment Connection

    4. CENTRAL DEVICE (CD) EQUIPMENT CONNECTION Depending on the LV side of the transformer there can be different network configurations. 4.1. STAR Transformer: 3 phase + neutral LV output In this LV configuration the transformer will have a neutral cable. Depending on the network voltage it can be*: CD connection point LD connection point...

  • Page 12: Ld Device Connection Point Phase-Neutral

    4.1.1. LD device connection point Phase-Neutral: Whenever the network point where the LD device is going to be connected, has an accessible neutral point, the working procedure to connect the CD at the transformer side should be: 4.1.1.1. Step ONE: Connect sensor rings to feeders Sensor rings must be connected checking that each ring embraces all three phases of a feeder, never the...

  • Page 13: Step Two: Cd Supply Cable Connection

    4.1.1.2. Step TWO: CD supply cable connection Connect cables to MV/LV transformer’s output: F1, green conductor -> Phase F2, yellow conductor -> Phase F3, brown conductor -> Phase N, blue conductor -> Neutral GND, green-yellow -> Ground Connect the supply cable to the CD’s front panel. It is not possible to work with more than one transformer at a time, so if there is more than one transformer in the substation, work must be done with...
  • Page 14 The connection to the network should look like the following figure:...

  • Page 15: Step Three: Select Working Mode, Auto-Fn Or Man-Fn Modes

    4.1.1.3. Step THREE: select working mode, AUTO-FN or MAN-FN modes In AUTO mode, the communication between the Central Device and the Line Device is made automatic, and takes place as described in 1.1 (Communication between CD and LD). However, there are certain network points where, due to network topology, feeder length (over 1km), noise produced by harmonics, etc., it is not possible for signals from CD to reach the network point where LD device has been connected to.
  • Page 16  AUTO -FN mode: Action Display Observations The device will start to Turn ON the device perform a mains connection test In case of connection If any phase or neutral ERROR: check show an X symbol, it will corresponding supply not identify connectivity cable fuse and clamp data...
  • Page 17 This number will be *Select Central Device received and displayed on number the LD * Whenever there is more than one CD connected on nearby transformers, CD selection number may be used to differentiate between them.
  • Page 18  MAN -FN mode: Action Display Observations The device will start to Select MAN-FN perform a mains mode connection test In case of connection If any phase or neutral ERROR: check show an X symbol, it will corresponding supply not identify connectivity cable fuse and clamp data connection...
  • Page 19 Check CD front panel LEDs: If a sensor ring has been connected to the front panel connector its corresponding LED must turn ON. Otherwise check the sensor ring’s resistance with an ohm meter. It should be within 30 to 50 ohm range. If no sensor ring has been connected to a front panel connector its corresponding LED must be OFF.

  • Page 20: Ld Device Connection Point Phase-Phase

    4.1.2. LD device connection point Phase-Phase: If the LD connection point has no neutral, and transformer’s LV side is B1 type (Vphase-phase 230Vac, Vphase-neutral 130Vac) the working procedure should be as in Transformer LV side in DELTA mode. Refer to section 4.2 DELTA Transformer: 3 phase LV output (no neutral)

  • Page 21: Delta Transformer: 3 Phase Lv Output (No Neutral)

    4.2. DELTA Transformer: 3 phase LV output (no neutral) In this LV configuration the transformer will not have a neutral cable. The network voltage can be*: CD connection point LD connection point o V phase-phase: 230Vac phase-phase: 230Vac * See equipment working voltage ranges in 5. Technical Features...

  • Page 22: Ld Device Connection Point Phase-Phase

    4.2.1. LD device connection point Phase-Phase: Whenever the network point where the LD device is going to be connected does not have an accessible neutral point, the working procedure should be: 4.2.1.1. Step ONE: Connect sensor rings to feeders In this mode each Sensor Ring must embrace only one phase per feeder, which means that 3 rings will be needed for each feeder, always...

  • Page 23: Step Two: Cd Supply Cable Connection

    4.2.1.2. Step TWO: CD supply cable connection Connect cables to MV/LV transformer’s output: F1, green conductor -> Phase F2, yellow conductor -> Phase F3, brown conductor -> Phase N, blue conductor -> Ground GND, green-yellow -> Ground Connect the supply cable to the CD front panel. It is not possible to work with more than one transformer at a time, so if there is more than one transformer in the substation, work must be done with...
  • Page 24 The connection to the network should look like the following figure:...

  • Page 25: Step Three: Select Working Mode, Auto-Ff Or Man-Ff Modes

    4.2.1.3. Step THREE: select working mode, AUTO-FF or MAN-FF modes* In Automatic mode, the communication between the Central Device and the Line Device is made automatic, and takes place as described in 1.1 (Communication between CD and LD). However, there are certain network points where, due to network topology, feeder length (over 1km), noise produced by harmonics, etc., it is not possible for signals from CD to reach the network point where LD device has been connected to.
  • Page 26  AUTO -FF mode: Action Display Observations The device will start to Select AUTO-FF mode perform a mains connection test In case of connection If any phase or neutral ERROR: check show an X symbol, it will corresponding supply not identify connectivity cable fuse and clamp data connection...
  • Page 27 This number will be *Select Central Device received and displayed on number the LD *Whenever there is more than one CD connected on nearby transformers, CD selection number may be used to differentiate between them.
  • Page 28  MAN -FF mode: Action Display Observations The device will start to Select MAN-FN mode perform a mains connection test In case of connection If any phase or neutral ERROR: check show an X symbol, it will corresponding supply not identify connectivity cable fuse and clamp data connection...
  • Page 29 Check CD front panel LEDs: If a sensor ring has been connected to the front panel connector its corresponding LED must turn ON. Otherwise check the sensor ring’s resistance with an ohm meter. It should be within 30 to 50 ohm range. If no sensor ring has been connected to a front panel connector its corresponding LED must be OFF.

  • Page 30: Line Device (Ld) Connection

    5. LINE DEVICE (LD) CONNECTION 5.1. Phase to Neutral network points (STAR, B1 with neutral or B2): Connect red and blue probes the following way: o RED probe to phase cable o BLUE probe to neutral. Press (ON) to turn on the LD, it must beep and show the voltage between the red and blue probe connection points.

  • Page 31: Phase To Phase Network Points (Delta Or Star B1 With No Neutral Available)

    5.2. Phase to Phase network points (DELTA or STAR B1 with no neutral available): Connect red and blue probes the following way: o RED probe to one phase o BLUE probe to another phase Press (ON) to turn on the LD, it must beep and show the voltage between the red and blue probe connection points.

  • Page 32: Identification Process

    6. IDENTIFICATION PROCESS 6.1. AUTO mode Press (ON) to turn on the LD, the following screen will appear: Initially the LD is in automatic mode. If it were in manual mode select automatic mode by pressing the left or right arrow button. Proceed to connect red and blue probes to the network point to be analyzed, as explained on step 5.
  • Page 33 The LD will display the voltage measurement and start searching for the signal injected by the CD. When working on Phase-Neutral mode (PH-N), and as phase and CD number data is received, it will be shown on the display: INFORMATION...
  • Page 34 When working on Phase-Phase mode (PH-PH), and as phase and CD number data is received it will be shown on the display: INFORMATION * In this example ‘PHASE: P1-P2’ will mean red probe is connected to phase 1 and blue probe to phase 2. Once the LD has received phase information it will send a signal upstream towards the transformer that will be captured by the sensor ring which corresponds to the feeder where the LD has been connected to.
  • Page 35 When the CD receives the signal transmitted by the LD it will send the corresponding feeder information to the LD. INFORMATION The LD receives the feeder code and displays it in big letters, finishing the identification process. Examples of received messages depending on network configuration: ...
  • Page 36  Phase-Phase mode: ‘PHASE: P1-P2’ will means red probe is connected to phase 1 and blue probe to phase 2.  Parallel and ringed feeders: ‘FEEDER: 4, 9’ means the customer is connected to two feeders, numbered 4 and 9. Press ENTER button if the identification process needs to be repeated.

  • Page 37: Man Mode

    6.2. MAN mode In certain cases and due to distribution network characteristics, the codes injected by CD unit on each phase may not reach the network point where the LD is connected. Then if the LD does not receive this signal, it will not send any information to the CD, resulting impossible to identify that network point in Automatic Mode.
  • Page 38 INFORMATION If the LD is transmitting for a long time in hot conditions it could happen that the device overheats. In this case “OVERTEMPERATURE” message will appear, and the LD will stop injecting the signal until it gets cooled.

  • Page 39: Tips

    7. TIPS It is important to know that the red and blue probes must be connected to the network point to identify (phase to neutral or phase to phase) throughout the whole phase and feeder identification process. The Line Device will automatically start executing the identification algorithm and in a couple of seconds, typically 5 to 15 seconds, it will display phase and feeder data.
  • Page 40 Device is connected to. In this case we recommend using the Manual Mode. It displays phase information but it doesn’t display feeder information if: There is some noise in the network which doesn’t let the feeder signal injected by the Central Device get to the network point where the Line Device is connected to.

  • Page 41: Technical Features

    8. TECHNICAL FEATURES Central Device Size ..........343x327x152 mm Weight ..........4 kg Protection index while operating ....IP65 (with power supply cable connected) Identification indication LEDs and Graphic display ........operation 100-280Vac ........Phase-Neutral operation 220-480Vac ........Phase-Phase V max connection ........480Vac 50 or 60Hz 0.5Hz Frequency ..........
  • Page 42 Line Device Size 120 x 220 x 65 mm ............. Weight 0.75 Kg ............. Protection index while operating ....IP54 Identification indication Graphic display ........Batteries 4x1.5V AA ............. operation 100 - 280 Vac ........Phase-Neutral V max connection ........440 Vac 50 or 60Hz 0.5Hz Frequency ..........

  • Page 43: Quality Standards And Security

    9. QUALITY STANDARDS AND SECURITY When accessing to a MV/LV transformer substation you must follow your country’s security directive to this respect, however we recommend using the following protection equipment: - Insulating footwear. - A helmet with a dielectric face screen. - Three pairs of gloves: non-flammable gloves, dielectric gloves and another pair of gloves to avoid the mechanical breakage of the previous ones - Wear work clothes that cover arms and legs.

  • Page 44: Warranty And Technical Service

    WARRANTY AND TECHNICAL SERVICE From the date of purchase and throughout the warranty period, Merytronic 2012, S.L., will repair or replace free of charge any defective item under warranty. All inspections and repairs under warranty must be performed by authorized personnel from Ariadna Instruments, S.L.
  • Page 45 MERYTRONIC 2012, S.L. Parque Empresarial Boroa Parcela 2C-1 48340 Amorebieta - Spain tel: +34 946 052 462 e-mail: sat@merytronic.com www.ariadna-inst.com...
