Summary of Contents for Ramtech Electronics WES+
- Page 1 WES+ Installation and Operation Manual Page 1 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017...
-
Page 2: Table Of Contents
Inspection of other system units Cancelling a Silent Test Moving a unit on site Removing a unit from the site Advanced systems – Base Stations Menu Overview Alarm System Warnings Base Station Controls Page 2 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017... - Page 3 Heat Detector Technical Data Smoke Detector Technical Data Link Technical Data Interface Technical Data Heat Detector Maintenance Routine Inspection Operational Test Cleaning Smoke Detector Maintenance Routine Inspection Operational Test Cleaning Contact Us Page 3 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017...
-
Page 4: System Units
LCD Display LED indicators Navigation Pad Call Point Fire Point Base Station Antenna Heat Dectector Smoke Detector LED indicators Detector Units Detector Units Antenna LED indicators Cable Gland Interface Link Page 4 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017... -
Page 5: Wes+ Units
Detectors will not function correctly if installed in open spaces without alarm. They can also take an input from an external trigger and set off ceilings, walls etc. the alarm on the WES+ system. Page 5 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017... -
Page 6: Basic System
Contact the WES+ Helpline for 1 - Activate Units. details. Page 6 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017... - Page 7 M4 x 50mm pan head screws and wall plugs or other fixings selected for the particular wall or ceiling type. Ensure that all fixing points are secure and that the back tamper is fully depressed after installation. Page 7 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017...
-
Page 8: System Operation
If a detector has raised the alarm, its red LED indicator will flash during a fire alarm. a fire alarm. Page 8 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017... -
Page 9: Silent Tests
The silent test can be cancelled from any unit, except those which are indicating the Alive Indication, by pressing and holding the B button for more than 1 second. The silent test will automatically cancel 20 minutes after activation. Page 9 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017... -
Page 10: Advanced Systems - Base Stations
) goes to the main menu to allow settings to be Test Phone Flat Batteries changed or logs to be viewed. Number Latched Units Unit Removed Clear All Logs* * Acces Code Required ** Only for GSM Base Stations Page 10 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017... -
Page 11: Alarm
Some warnings, for example EXT, will self-clear if the fault is resolved. Select ‘Yes’, and enter your access code when requested. During the re-arming period the following message will be displayed for two minutes. Page 11 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017... -
Page 12: Base Station Controls
Menu items can be selected using the up and down arrows and then pressing enter (middle arrow button). Change characters using the up and down arrows while the character is highlighted. Page 12 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017... -
Page 13: System Logs
(+) or clearing (-) of an event. If there is a down arrow in the bottom right corner, there are further log entries which can be displayed by pressing the down arrow on the navigation pad. Page 13 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017... -
Page 14: Change Access Code
The amber LEDs on both units will illuminate and then the green LEDs will flash to confirm successful renumbering. To exit the Unit Numbering screen, press the left arrow when at the left most digit of the unit number. Page 14 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017... -
Page 15: Date And Time
The Base Station unit can be made mobile by pressing enter on the Mobile base option. A tick indicates that the Mobile Base option has been enabled. Page 15 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017... -
Page 16: Sim Card Installation - Gsm Base Station
1234 unless your change it. code is 1234 unless your change it. Now you are ready to reattach the fascia (19-way ribbon) to the PCB, and reattach the lid. Page 16 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017... - Page 17 ‘A:’ and press nate and then extinguish “B” three in quick succession. Low Signal Unit NNN has a low radio signal Silent Test Unit NNN initiated a Silent Test Page 17 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017...
-
Page 18: Communications
Select Edit User Name and enter the name of this user with the navigation pad. The site name is edited using the navigation pad and confirmed by pressing enter. Page 18 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017... -
Page 19: Test Phone Number
Unit NNN has been deactivated and removed removed from the fire alarm system The call point on unit NNN is still 10. latched latched in after the alarm has been reset Page 19 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017... -
Page 20: Sim Card Information
The selection of a mobile telephone network can be undertaken via the Network Scan option. Note this scan can take a few minutes to complete. The screen will initially display... Page 20 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017... -
Page 21: Interface
The input is unmonitored and connection of automatic or nanual fire detection devices is not recommended. Cable disconnection or damage could result in the alarm not activating when required without any fault or warning indication. Alarm NOT Triggered Alarm Triggered Page 21 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017... -
Page 22: Fire Point Technical Data
Estimated life (field usage): > 5 years RF Parameters Operating frequency: 868.3MHz Transmit power: 25mW max Duty Cycle: <1% Encryption: none Channel spacing: single channel Compatible with: other WES+ units Protocol: proprietary Page 22 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017... - Page 23 Alkaline primary cells, 7.6Ah RF Parameters Operating frequency: 868.3MHz Transmit power: 25mW max Duty Cycle: <1% Encryption: none Channel spacing: single channel Compatible with: other WES+ units Protocol: proprietary Page 23 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017...
-
Page 24: Base Station Technical Data
880 to 915 MHz 925 to 960 MHz 2 Watts EGSM 900 radio section DCS 1800 1710 to 1785 MHz 1805 to 1680 MHz 1 Watt GSM1800 radio section Page 24 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017... -
Page 25: Heat Detector Technical Data
Estimated life (field usage): > 5 years RF Parameters Operating frequency: 868.3MHz Transmit power: 25mW max Duty Cycle: <1% Encryption: none Channel spacing: single channel Compatible with: other WES+ units Protocol: proprietary Page 25 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017... - Page 26 Battery type: Alkaline primary cells,15.2Ah RF Parameters Operating frequency: 868.3MHz Transmit power: 25mW max Duty Cycle: <1% Encryption: none Channel spacing: single channel Compatible with: other WES+ units Protocol: proprietary Page 26 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017...
-
Page 27: Smoke Detector Technical Data
Estimated life (field usage): > 5 years RF Parameters Operating frequency: 868.3MHz Transmit power: 25mW max Duty Cycle: <1% Encryption: none Channel spacing: single channel Compatible with: other WES+ units Protocol: proprietary Page 27 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017... - Page 28 Battery type: Alkaline primary cells,15.2Ah RF Parameters Operating frequency: 868.3MHz Transmit power: 25mW max Duty Cycle: <1% Encryption: none Channel spacing: single channel Compatible with: other WES+ units Protocol: proprietary Page 28 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017...
-
Page 29: Link Technical Data
Estimated life (field usage): > 5 years RF Parameters Operating frequency: 868.3MHz Transmit power: 25mW max Duty Cycle: <1% Encryption: none Channel spacing: single channel Compatible with: other WES+ units Protocol: proprietary Page 29 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017... - Page 30 Alkaline primary cells, 7.6Ah RF Parameters Operating frequency: 868.3MHz Transmit power: 25mW max Duty Cycle: <1% Encryption: none Channel spacing: single channel Compatible with: other WES+ units Protocol: proprietary Page 30 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017...
-
Page 31: Interface Technical Data
770μW average Current Consumption: 150μW average Battery type: Alkaline primary cells, 23Ah RF Parameters Operating frequency: 868.3MHz Transmit power: 25mW max Duty Cycle: <1% Encryption: none Channel spacing: single channel Page 31 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017... -
Page 32: Heat Detector Maintenance
If the unit needs further cleaning, or is damaged or corroded, please return the complete detector to Ramtech Electronics for service. i) Testing the detectors will trigger the site wide alarm. To avoid unnecessary evacutation site personnel should be informed when testing starts and when testing is complete. -
Page 33: Smoke Detector Maintenance
The maintenance procedures described below should be conducted with the following frequency: The Functional Test checks the detector’s operation. These detectors One month after : Routine inspection may be returned to Ramtech Electronics for Functional Testing. installation and every 3 months thereafter Cleaning Every 6 months : Operational Test Note : The detector head should NOT be disassembled. - Page 34 Tel: +44 (0)115 822 3424 Email: wes@ramtech.co.uk electronics Web: www.wesfire.co.uk Abbeyfield House, Abbeyfield Road, Nottingham NG7 2SZ UK Page 34 WES+ Installation and Operations Manual V2.3 Ramtech Electronics 2017 V2.3- 08-2017...
